PROSECURE EASY MOTION STEREO
—
Technical data
Operating principle Microwave module
Detection speed min. 0.1 m/s (measured in
sensor axis)
Approvals CE
Detection field angle 0° - 90° in 5° increments (10°
increments at inclination)
Sensing range at installation (WxD)
height of 2200 mm and Wide:
30° angle: Narrow: 2000 x 4500 mm
Operating frequency 24,05 ... 24.25 GHz, K band
Status display Red LED
Operating controls Potentiometer for adjusting the
detection area size.
DIP switch for selecting the
operating mode.
Operating voltage 12 - 36 V DC/ 12 - 28 V AC
No-load current < 50 mA at 24 V DC
Power consumption < 1.7 W at 36 V DC
< 1.2 W at 28 V AC
Signal output Relay, 1 NO/NC contact
Operating mode Active/passive
Switching voltage Max. 48 V AC / 48 V DC
Switching current Max. 0.5 A AC/ 1 A DC
Switching power Max. 24 W/ 60 VA
Off-delay time 1 s
Ambient temperature -20° C to 60° C
Relative humidity Max. 90 %, not condensing
Installation height Max. 4000 mm
Degree of protection IP 54
Connection 4-pin connecting plug
(connecting cable with plug
included with delivery)
Housing material Polycarbonate (PC), ABS
Weight: 130 g
Transmitting power < 20 dBm EIRP
Dimensions without weather 101 mm x 61 mm x 59 mm
cap (WxHxD)
Dimensions with weather 120 mm x 73 mm x 74 mm
cap (WxHxD)
EC conformity
The product is compliant with Directive 1999/5/EC, device
class 1 and harmonized standards EN 62311, EN 60950-1,
EN 301 489-1, EN 301489-3, EN 300 440-2.
0682
4500 x 2000 mm
