IV Pole and Mounting bracket
Art. nr. 69760 and 69755-1 / 69755-2
Intended use
IV pole and mounting bracket are intended to be used with HD Motion. Using an IV pole with the
wheelchair can make it easier for the user to be more mobile for certain treatments and examinations.
IV Pole and Mounting bracket are ordered separately. Note that neither product is intended to be used
with equipment from other manufacturers.
Parts included
(IV pole)
1 x IV pole
1 x IV hook
1 x screw M5x14
Assembly of Mounting bracket
Screw the mounting bracket
1
in place on the back frame
tube with the included
screws and washers.
MD
Parts included
1
HD Rehab AB
, Tryffelslingan 4, 181 57 Lidingö, Sweden
tel. +46(0)8-767 04 80 info@hdrehab.se www.hdrehab.se
User manual /
Assembly instructions
Doc. nr. 96814-1 Rev A 2021-09-27
(Mounting bracket)
1 x mounting bracket
(LH model shown)
Page 1 (2)
Advertisement
Table of Contents
Related Manuals for HD Rehab HD motion 69760
Summary of Contents for HD Rehab HD motion 69760
- Page 1 1 x screw M5x14 Assembly of Mounting bracket Screw the mounting bracket in place on the back frame tube with the included screws and washers. HD Rehab AB , Tryffelslingan 4, 181 57 Lidingö, Sweden tel. +46(0)8-767 04 80 info@hdrehab.se www.hdrehab.se...
- Page 2 User manual/Assembly instructions - IV pole & Mounting bracket Page 2 (2) Assembly of IV pole Push the hook into the top bushing. Note the alignment of the hole. Secure the hook in place with the screw. Lower the pole through the mounting bracket to the desired height. Note: The tip protectors limit how low the IV pole can be mounted.
