7.6 Display in multiple configuration

55
56
Loss of link on one sensor

7.6.1 Multiple Display menu

The elementary and advanced functions are accessible as in the case on single display.
The menu navigation and usage principle is the same irrespective of the number of associated sensors.
59
No action
ESC
No action
Select an icon and enable the
available options
Select an icon and enable the
available options
57
3-sensor display
Confirm the selection
ESC
Return to standard display
Move clockwise from icon to
icon
Move anticlockwise from icon
to icon
33
Two-sensor display:
Displays the signed measurement.
Displays the total .
The sensor icons indicate their
battery levels.
58
4-sensor display
Navigation:
By pressing on either of the two arrows,
all available functions are displayed.
Move from icon to icon using the
arrows.
+ = By modifying the measurement
sign, the value can be added or
subtracted from the total.
0 = the measurement will not be taken
into account.
T = individual tare.
TARE and MAX acting on total.
ID = Sensor identification.
