6.3.1.2 Parameter setting menu

Display
23

6.3.1.2.1 Date and Time

24
GB

6.3.1.2.2 Coefficients

25

6.3.1.2.3 Available memory check

26
Action
Confirm selection
ESC
Return to previous display
Select an icon and enable the
available options
Select an icon and enable the
available options
Return to main display
ESC
Return to main display
Select an icon and enable the
available options
Select an icon and enable the
available options
No action
ESC
Return to main display
No action
No action
Return to main display
ESC
Return to main display
No action
No action
22
Comments
Parameter setting menu:
Select the sub-menu.
Confirm with
For + and +
multiple configuration chapter 7.
Date and hour:
Select the parameter to be
modified.
Confirm with
Modify the parameters, using the
arrows.
Confirm again with
Exit and confirm modifications bu
validating V at the bottom of the
screen.
COEFFICIENTS:
These parameters can only be
modified by the manufacturer.
Hysteresis of the trigger points;
50% of the adjusted value.
ZERO auto < 10 % of the capacity
Gravity acceleration: coefficient
used for the conversion N / kg.
PARIS value by default.
Memory:
Indicates the memory fill rate.
Point: Saved values (Max. 99).
Total: accumulated values
(Max. 99).
For reset see sections 6.3.1.1.1
and 6.3.1.1.2.
