Controls
(on some models)
Not all features are on all models. Your controls may be similar to the following:
The temperature controls are preset in the factory
recommended settings.
The temperature controls can display both the SET
temperature as well as the actual temperature in the
vary slightly from the SET temperature based on usage
and operating environment.
setting until the display flashes (off) will stop cooling
setting until the display flashes (off) will stop the
NOTE: Turning the refrigerator off via the controls on
the touch panel does not shut off electrical power to
the refrigerator.
NOTE: The refrigerator is shipped with protective film-
removed during installation, remove it now.
Performance Air Flow System
consists of the Air Tower along the back wall of the
refrigerator and the Air Tunnel on the bottom portion of
49-1000471 Rev. 1
OR
Placing food in front of the louvers on these components
will not affect performance. Although the Air Tower and
the Air Tunnel can be removed, doing so will affect
on-line, 24 hours a day, contact us at
GEAppliances.com
contact us at geappliances.ca or call 1.800.561.3344.)
5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GSS23GSKSS and is the answer not in the manual?

Questions and answers

Related Manuals for GE GSS23GSKSS

Summary of Contents for GE GSS23GSKSS

  • Page 1 Controls (on some models) Not all features are on all models. Your controls may be similar to the following: The temperature controls are preset in the factory recommended settings. The temperature controls can display both the SET temperature as well as the actual temperature in the vary slightly from the SET temperature based on usage and operating environment.
  • Page 2 Controls (on some models) The temperature controls are preset in the factory at 37°F (2.8°C) for the refrigerator compartment and 0°F (-17.8°C) the preset recommended settings. Filter Status The temperature controls can display both the SET temperature as well as the actual temperature in the refrigerator environment.
  • Page 3 ClimateKeeper2™ (on some models.) How it Works The ClimateKeeper2™ is the industry’s most advanced Moisture sensitive foods such as fresh fruit, salads, refrigeration system, delivering optimum temperature and rice, etc., can now be stored on open shelves without humidity performance to keep food garden fresh longer excessive moisture loss.
  • Page 4 ExpressChill™ (on some models) How it Works The ExpressChill™ feature is a system of dampers, a fan and a temperature thermistor. The pan is tightly sealed to prevent the pan’s temperature from causing temperature fluctuations in the rest of the refrigerator. The controls for this pan are located in the top of the refrigerator or on the dispenser with the temperature controls.
  • Page 5 (appearance may vary) and quality that are important for products that are filtering your water. GE Appliances has not qualified 2. On models ithout a replacement indicator light, apply non-GE Appliances branded filters for use in GE the month and year sticker to the new cartridge to Appliances and Hotpoint refrigerators and there is no remind you to replace the filter in six months.
  • Page 6 GE Appliances and Hotpoint refrigerators and there is no assurance that non-GE Appliances- branded filters meet GE Appliances standards for quality, performance and reliability. If you have questions, or to order additional filter cartridges, visit our website at gewaterfilters.com or call GE Appliances Parts and Accessories, 877.959.8688. (Canada 1.800.661.1616 or GEAppliances.ca/en/products/ parts-filters-accessories) 49-1000471 Rev.

  • Page 7: Shelves And Bins

    Shelves and Bins Not all features are on all models. Refrigerator Door Bins and Freezer Door Tilt-Out Bins Large Bins Snugger bins are adjustable. To remove: Lift the front of the bin straight up, then lift up and out. To replace or relocate: Engage the back side of the bin in the molded supports of the door.
  • Page 8 Shelves and Bins Not all features are on all models. Freezer Baskets Door Wine/Beverage Rack (on some models) (on some models) To remove, slide out to the stop This rack holds up to 5 cans, one position, lift the front past the stop bottle of wine or one 2-liter bottle position, and slide out.

  • Page 9: Refrigerator Doors

    Refrigerator Doors Refrigerator Doors (on some models) The refrigerator doors may feel different than the ones feature makes sure the doors close all the way and are securely sealed. When opening and closing the door you will notice a stop door will remain open to allow you to load and unload food more easily.

  • Page 10: Crispers And Pans

    Crispers and Pans Not all features are on all models. Fruit and Vegetable Crispers Convertible Deli Pan (on some models) Excess water that may accumulate in The convertible deli pan has its own cold air duct to the bottom of the drawers should be wiped dry.

  • Page 11: Automatic Icemaker

    Automatic Icemaker Not all features are on all models. Automatic Icemaker The icemaker will produce seven cubes per cycle— approximately 100–130 cubes in a 24-hour period, temperature, number of door openings and other use conditions. is made to the icemaker, set the power switch in the Green When the refrigerator has been connected to the water Power Light...
  • Page 12 Automatic Icemaker Accessing Ice and Reaching the Power Switch on Dispenser Models There are two types of ice storage bins on dispenser Models with a shelf above the ice bin models. One has a shelf above the bin, the other does To access ice, pull the bin forward.

  • Page 13: Ice And Water Dispenser

    Ice and Water Dispenser (on some models.) Using the Dispenser Dispenser Light This pad turns the light in the dispenser on and off. The light also comes on or WATER when the dispenser cradle is pressed. Press the glass gently against the top of the dispenser burns out, it should be replaced with cradle.

  • Page 14: Care And Cleaning

    Care and Cleaning Cleaning the Outside The dispenser drip area, (on The dispenser cradle (on some models). Before some models) beneath the cleaning, lock the dispenser by pressing and holding the grille, should be wiped dry. LOCK pad for 3 seconds. Clean with warm water and Water left in this area may baking soda solution—about a tablespoon (15 ml) of leave deposits.
  • Page 15 Care and Cleaning Behind the Refrigerator Be careful when moving the refrigerator away from When pushing the refrigerator back, make sure you the wall. All types of floor coverings can be damaged, don’t roll over the power cord or icemaker supply line (on particularly cushioned coverings and those with some models).
  • Page 16 Care and Cleaning Replacing the Light Bulbs (Cont.) WARNING Before replacing a burned-out light bulb, the refrigerator should be unplugged in order to avoid contact with a live wire filament. (A burned-out light bulb may break when being replaced.) Refrigerator Compartment—Lower Light This light is located above the top drawer.
