Samsung SR-S25NTA Service Manual

Hide thumbs Also See for SR-S25NTA:

Service manual (134 pages)

Instruction manual (34 pages)

Instruction manual (34 pages)

100

101

page of 101

/ 101
Bookmarks

Quick Links

Download this manual

All manuals and user guides at all-guides.com

Model : SR-S25/26NTA

REFRIGERATOR

SR-S24/25/27FTA

SR-S24/25/27DTA

CONTENT

1. Product Specifications

2. Safety Warnings

3. Specifications of Electric Components

4. Electric Circuit Diagram

5. External Size and Designations

6. Refrigeration Cycle and Cool Air Circulation

7. Function and Usage of Refrigerator

8. Circuit Operation Theory

9. Inverter Component List

10. Troubleshooting

11. Instruction of ICE-MAKER Operation and

Troubleshooting

12. References

13. Disassembly Method of the Refrigerator

14. Assembly and Disassembly of Hinge-Upp

AssÕy

15. Exploded View of Refrigerator and List

16. Assembled State of Machine Room

17. Disassembly of PCB Panel and Assembly

of Internal Components

18. Installation of the Water Dispenser Line

19. PCB Circuit Diagram and Service

Components LIST

20. Specifications of Major Components in Circuit

115

116

117

119

122
