- Page 1 LCD TV USER S MANUAL Before using the TV, Please read this manual thoroughly, retain it for future reference. LED19T28 22T28P English 26T28 IES010...
-
Page 2: Table Of Contents
Contents Specification Important safety instructions and Environment View the control panel and connection panel Connections to other devices View the remote control Brief operation of the remote control Basic operation Turn on/off Changing channels/volume Channel setting Picture setting Sound setting Screen setting Function setting Digital multimedia function... -
Page 3: Specification
Specification Model Name LED19T28 LED22T28P LED26T28 486×340×35 Dimension Without stand ×376×35 ×449×35.9 With stand 486×392×160 ×425×160 ×498.5×220 (W×H×D)(mm) Without stand Weight(kg) With stand LCD Panel Minimum size diagonal) Screen resolution 1366×768 1920×1080 1366×768 Power consumption Audio power 1.8W+1.8W 1.8W+1.8W 5W+5W... -
Page 4: Important Safety Instructions And Environment
Important safety instructions and Environment Important safety instructions Attentions The flash with the symbol of arrowhead inside a triangle alerts the user about the presence of a dangerous tension inside the product. The flash with the symbol of exclamation inside a triangle alerts the user about the important instruction related to the product. - Page 5 Important safety instructions and Environment Important safety instructions Please do not stick the sharp objects, metal, or liquid into or use them to touch the signal interface or heat-radiating holes in case of short circuit or damage to the product. Maintenance Do not clean this unit with volatile oils or diluent, which may cause cabinet deterioration or damage its coating surface.
-
Page 6: View The Control Panel And Connection Panel
Volume up Volume down Channel up Channel down Power Remote sensing window Main power switch Power indicator LED19T28 LED22T28P LED19T28 LED22T28P LED26 LED26 NOTE: The above picture is for reference only, please refer to the actual TV to determine their appearance. -
Page 7: Connections To Other Devices
Connections to other devices Warning: Before connecting the TV to any other electronic device, unplug the TV and electronic device AC cords from the AC input. Connecting the broadcast antenna or the cable TV To have an optimal picture quality, it is strongly recommended to have an external antenna or a cable TV. - Page 8 Connections to other devices Component video(Y, Pb, Pr)transmits video as separate red, green and blue signals. Use this connection for high-definition video signals from a DVD or other equipment. Audio R White Audio L Blue DVD With Component jacks Green Connecting the devices with HDMI interface HDMI, which is also called "High Definition Multimedia Interface", is a newer generation interface that transmits digital AV signals via a single cable without compression.
-
Page 9: View The Remote Control
View the remote control Power indicator Power button Power Source selecting button Source Picture mode selecting button Enter TV source button Picture ZOOM Sound Sound mode selecting button Zoom button Program selecting Special function buttons button Display information button Display Recall Recall button CH+/-: Channel up/Down... -
Page 10: Brief Operation Of The Remote Control
Brief operation of the remote control Change the batteries 1. Open the battery cover on the back of the remote control. 2. Install two AAA size (1.5V) batteries. Match the “+” and “-” signs on the batteries to the signs on the battery compartment. - Page 11 Brief operation of the remote control 6. Sleep: It can set the TV to let it enter into the Standby Sleep Timer state automatically, Press this button repeatedly to select Sleep Time 40 Minute the proper sleeping clock mode, and the clock tells you Mins Left 39 Minute the remaining time before the TV enters Standby state.
-
Page 12: Basic Operation
Basic operation Turn on/off 1. Connect the TV power line to AC outlet. 2. Press the Power button on the TV set. When the TV is on, press the Power button on the remote control, and the TV will enter Standby state. Press this button again, and you can watch TV normally. -
Page 13: Channel Setting
Channel setting To set the channels: 1 Press Menu button to display the main menu. Channel 2 Press CH+/- button to select Channel item. Program No. Color System Auto 3 Press VOL+/ OK button to enter Channel menu. Sound System 4 Press CH+/- button to select the option, press... -
Page 14: Picture Setting
Picture setting To adjust the picture: 1 Press Menu button to display the main menu. Picture 2 Press CH+/- button to select Picture item. Brightness /OK button to enter Picture menu. 3 Press VOL+ Contrast 4 Press CH+/- button to select the option, press Color Sharpness /OK button to enter or press... -
Page 15: Sound Setting
Sound setting Sound setting To adjust the sound: 1 Press Menu button to display the main menu. Sound 2 Press CH+/- button to select Sound item. Balance 3 Press VOL+/ OK button to enter Sound menu. Speakers Internal Sound Field Table 4 Press CH+/-... -
Page 16: Screen Setting
Screen setting To adjust the screen image: 1 Press Menu button to display the main menu. Screen 2 Press CH+/- button to select Screen item. H Size 3 Press VOL+/ OK button to enter Screen menu. V Size Image Position 4 Press CH+/- button to select the option, press... -
Page 17: Function Setting
Function setting To set the parameters: 1 Press Menu button to display the main menu. Function 2 Press CH+/- button to select Function item. OSD Language English 3 Press VOL+/ OK button to enter Function menu. Blue Screen Light Effect 4 Press CH+/- button to select the option, press... - Page 18 PIP setting To adjust the PIP image: 1 Press Menu button to display the main menu. PIP Mode 2 Press CH+/- button to select PIP Mode item. PIP Mode PIP Position Right Bottom 3 Press VOL+/ OK button to enter PIP Mode menu. Sub Brightness Sub Contrast 4 Press...
-
Page 19: Digital Multimedia Function
Digital multimedia function Brief Function Introduction This unit has USB digital multimeadia player . It can identify signal mode support format such standard USB1.1 and USB2.0 devices as hardware, U JPEG Picture disk, digital camera, etc. Music At the same time, you can browse the images, listen to music, MPEG1(.dat) MPEG2(.mpg) and enjoy various files such as MPEG1, MPEG2, MPEG4, AVI, Movie... - Page 20 Digital multimedia function Picture Browsing: Browse the pictures DMP main interface You can select and browse the kept pictures in the storage device. Picture 001/004 \USB\ 1. Press DMP button to enter DMP main interface and the Picture1 contents of the storage device will appear on the screen. Picture2 Picture3 2.
- Page 21 Digital multimedia function Enjoying Music: Play audio files You can select and browse the kept images in the storage devices. Music 001/002 1. Press DMP button to enter DMP main interface and the \USB\ the day you went away contents of the storage device will appear on the screen. Title: Say you Say me say you say me Artist:...
- Page 22 Digital multimedia function Introduction to Function Menu Press Display button to display the function menu. Play State information column, displaying the Forward the movie current state. Browse the previous AV file Pause/Play Browse the next AV file Stop playing the AV file and return to root file Display the specific information of the AV file A ,B-point repeat playback Backward the movie...
-
Page 23: Environment
Important safety instructions and Environment Important safety instructions and Environment Environment Environment WEEE (Waste Electronic Electric Equipment) WEEE (Waste Electronic Electric Equipment) European Directive 2002/96/EC & 2003/108/EC European Directive 2002/96/EC & 2003/108/EC The symbol of the The symbol of the barred barred dustbin means that this apparatus cannot be... -
Page 24: Pedestal Installation Instruction
Pedestal installation instruction Pedestal Installation Instruction Put the TV set on the level table on which is the pad cloth or other soft material. Use the provided 4 screws (in the enclosed bag of the base) to fix the base to the whole unit. 4 screws... -
Page 25: Trouble Shooting
Trouble shooting When there is something wrong with your TV, you can try turning off the TV and then restart it. You can also operate according to the following chart. If the problem still cannot be solved, please contact the professional technicians. 1.
