Summary of Contents for Tranberg STAHL TEF 2440
-
Page 1: Document Properties (Tum1072)
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Perimeter / Obstruction Light LED TEF 2440 Document properties (TUM1072) Revision Comment Date Changed tyoe of cable gland and cable diameter range. Converted to word. 25.10.2022 CKR... -
Page 2: Table Of Contents
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Installation and operating manual Contents Document properties (TUM1072) ..........................1 Warnings and risk levels ............................3 General information ..............................3 Marking and intended use ............................4 Special conditions for safe use ..........................5 Technical data ................................. -
Page 3: Warnings And Risk Levels
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Warnings and risk levels DANGER Non-compliance with the instruction results in risk of severe or fatal injuries to persons WARNING Non-compliance with the instruction may result in risk of severe or fatal injuries to persons CAUTION Non-compliance with the instruction may result in risk of injuries or damage to equipment NOTICE... -
Page 4: Marking And Intended Use
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Marking and intended use CAUTION Not intended for use in “these” conditions (Where mud may be present, on helidecks, underground, direct sunlight, heavy vibrations, high risk of impact, harsh cleaning agents, high pressure washer etc.) CE-marking Other markings For use in safe area... -
Page 5: Special Conditions For Safe Use
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Special conditions for safe use DANGER Special conditions for safe use are critical conditions to maintain the safety of the equipment. These shall be adhered to in all cases and under all circumstances. Changes made to the product and/or installation of components which do not conform to the approval, •... -
Page 6: Mounting And Installation
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Mounting and installation DANGER Incorrect mounting and installation may lead to risk for falling objects, risk for electric shock or fire and risk for equipment malfunction. In turn, this can lead to severe damage and/or injuries. Mounting Regular tools required for installation: 10 mm wrench for tightening the M6 bolts... - Page 7 Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light The safety wire should be in place and the two electrical wires for power to the LED’s should be correctly positioned (+ and -). The input power 100-230 VAC should be terminated as indicated inside the lamp. For the 24VAC/VDC version, connect power to the connection block.
-
Page 8: Dimensions
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Dimensions External dimensions:... -
Page 9: Commissioning
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Commissioning The luminaire should be inspected according to company routines. The manufacturer suggests regular check for water intrusion/ condensation which should be removed immediately. Description Part No Complete low globe assembly, green 6597 Complete high globe assembly, red 4417... -
Page 10: Compliance/Conformity
Installation and operating manual – TUM1072 TEF 2440 Perimeter / Obstruction light Compliance/Conformity Complies with: ICAO Annex 14 Vol. II • • Low type complies with: IMO on 150mm height restrictions of IMO...
