Kohler Persuade Circ K-3753 Detailed Planning Dimensions

Features
•
Vitreous china.
•
Two-piece toilet.
•
Comfort Height Elongated bowl.
•
Dual Flush flushing system.
•
Includes top-mount dual flush trip lever.
•
1.6 gpf (6.0 lpf) or 1.0 gpf (3.8 lpf).
•
Fully skirted trapway.
•
12" (305 mm) rough-in.
•
Supply line included.
•
4-1/2" (114 mm) x 5-3/4" (146 mm) water area.
•
28-5/8" (727 mm) x 14-3/16" (360 mm) x 33-3/4" (857 mm).
•
Floor mount / Floor outlet.
Optional Accessories
K-4650 Toilet Seat
K-186 Dual Flush Actuator
K-4008 Toilet Seat
K-4636 Toilet Seat
K-4652 Toilet Seat
K-4659 Toilet Seat
K-4684 Toilet Seat
K-4688 Toilet Seat
K-4694 Toilet Seat
K-4748 Toilet Seat
K-4774 Toilet Seat
K-4814 Toilet Seat
K-4888 Elongated Toilet Seat
K-5588 Elongated Toilet Seat
K-5638 Elongated Toilet Seat
K-7637 Angle Supply with Stop (single)
K-7659 Angle Stop
K-7668 Straight Stop
K-9384 Dual-flush Actuator
K-4761-BN Toilet Seat
K-4761-CP Toilet Seat
Components
Product includes:
K-4353 Toilet Bowl
K-4442 Toilet Tank
Additional included component/s: Tank cover, Dual flush push
buttons, Installation kit, Installation template, and Tank accessory
pack.
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
3-7-2017 07:27
Persuade Circ
Dual Flush Toilet
Codes/Standards
ASME A112.19.2/CSA B45.1
ASME A112.19.14
DOE - Energy Policy Act 1992
EPA WaterSense
KOHLER One-Year Limited Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
Color Code Description
0 White
96 Biscuit
47 Almond
NY Dune
95 Ice™ Grey
7 Black Black™
K-3753
