Empire Comfort Systems EMBF11S Series Assembly Instructions

INSTRUCTIONS MUST BE LEFT WITH THE OWNER FOR FUTURE REFERENCE AFTER INSTALLATION.
1. Place back base in desired location. Place fireplace on base
and route gas line to fireplace.
2. Position left side assembly and right side assembly against
base.
23686-0-0507 Empire Comfort Systems, Inc. • 918 Freeburg Avenue • Belleville, IL 62222 • PH: 618-233-7420 • FAX: 618-233-7097
MANTEL ASSEMBLY INSTRUCTIONS
EMBF11S SERIES
FULL CABINET MANTEL
EFFECTIVE DATE MAY 2007
3. Position breastboard assembly to the front of left side as-
sembly and right side assembly.
4. Use six (6) 1 1/4" screws to attach breastboard assembly to
left side assembly and right side assembly.
(6) 1/4" SCREWS
Page 1
