VinciLab is an advanced mobile graphic data acquisition system, which can be used in a variety
of ways, standalone and with a computer or tablet, in the classroom and in the field.
Internal
Sound Sensor
for recording
sound signals
Capacitive Color
Touch Screen
for viewing
and controlling
Power Button for turning VinciLab On or Off
and for turning the screen on when it is timeout
Mini USB Port for charging and communication
USB Port for connecting any USB peripheral
At the backside of VinciLab a Speaker and a compartment with an internal rechargeable Battery are located.
The Home Screen is the starting point for using VinciLab and provides shortcuts to
applications. Tap an application's icon to launch the application. Tap Home to display the
Home Screen. Tap Back to return to the previous screen.
Coach
Collecting, graphing and processing data
My Files
Managing user files on VinciLab
Settings
Configuring the device to your preferences
Connections
Configuring the wireless connections
T V L O
O TURN INCI AB
• Tap or press shortly the hardware Power button.
• Tap to shut down,
S G
TART UIDE
:
FF
to reboot,
D2
D1
Analog (A1, A2, A3, A4) and Digital (D1, D2) Inputs
for connecting sensors
Audio Out (left) for generating DC/AC voltage signals
Audio In (right) for connecting external microphone
Web Browser
Accessing the Internet
Images
Browsing and displaying images
Media Player
Playing audio and video files
Calculator
Performing simple mathematical calculations
to turn the screen off, or
V L
INCI AB
Home Screen
for controlling VinciLab
and providing shortcuts
to Applications.
A2
A3 A1
A4
to cancel.
