- Page 1 User Manual CORDLESS DRILL BBT-JOZ57C Please scan the QR CODE for more services. Read all safety rules and instructions carefully before operating this tool. geprufte Sicherheit...
-
Page 2: Table Of Contents
CONTENTS ....................................Contents ....................................... Symbols ..............................Safety instructions Machine information ................................................................. Assembly 8-11 ..................................Operation 12-13 ..................................Maintenance ................................... Environment ....................................Warranty... -
Page 3: Symbols
SYMBOLS The following symbols are used in the user manual or on the product: Read the user manual. Time-lag miniature fuse-link. Denotes risk of personal injury, loss of life or damage to the tool in case of Max temperature 45 non-observance of the instructions in this manual. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Read the enclosed safety warnings, the additional safety warnings and the instructions. Failure to follow the safety warnings and the instructions may result in electric shock, fire and/or serious injury. Save the safety warnings and the instructions for future reference. GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. - Page 5 Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
- Page 6 Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury. Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130 °C may cause an explosion.
-
Page 7: Machine Information
Intended use This cordless drill is intended for driving in and loosening screws as well as for drilling in wood, metal and plastic. TECHNICAL SPECIFICATIONS Model Number BBT-DC20A Model No. BBT-JOZ57C Battery type Lithium-ion Rated voltage Voltage Chuck capacity φ10 mm Capacity 2.0 Ah... - Page 8 Only use the following batteries of the SnapFresh power 20V battery platform. Using any other batteries could cause serious injury or damage the tool. BBT-DC20A 20V, 2Ah Lithium-ion BBT-DC40A 20V, 4Ah Lithium-ion The following charger of the can be used to charge these batteries. BBT-YFT20V Quick charger The batteries of the SnapFresh power 20V battery platform are interchangeable with all the SnapFresh...
-
Page 9: Assembly
ASSEMBLY... - Page 10 Before any work on the power tool, remove the battery. The battery must be charged before first use. DESCRIPTION The numbers in the text refer to the diagrams on page 9. 1. Machine 2. Battery 3. Battery unlock button 4. Work light 5.
- Page 11 Charging the battery with the charger (Fig. C) • Take the battery (2) off from the machine. • Turn the battery (2) to upside down position and slide it onto the charger (13) as shown in Fig. C. • Push the battery until it is fully pushed into the slot. •...
-
Page 12: Operation
OPERATION Adjusting the gears (Fig.A) Never switch gears when the motor is running, this will damage your machine. Never put switch in the middle between both positions, this will damage your machine. The machine has 2 drill speeds, which can be adjusted by sliding the gear switch (8) forward or backwards. -
Page 13: Maintenance
during drilling. Ensure that the direction switch (9) is always set to The machine is equipped with electronic overload protection function. When the machine gets overloaded it will shut down automatically. When this happens, please wait for a few seconds to let the overload protection reset itself. MAINTENANCE Before cleaning and maintenance, always switch off the machine and remove the battery pack from the machine. -
Page 14: Warranty
WARRANTY Ningbo Babytec Technology Co., Ltd (Hereinafter referred to as Babytec) warrants this product against defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by the original purchaser (’Warranty Period’). The following circumstances are excluded from this guarantee: •...
