- Page 1 LCD Monitor User Manual AG274QG www.aoc.com 2021 AOC.All Rights Reserved ©...
-
Page 2: Table Of Contents
Safety ....................................1 National Conventions ..............................1 Power ..................................2 Installation ................................. 3 Cleaning ..................................4 Other ..................................5 Setup ....................................6 Contents in Box ................................. 6 Setup Stand & Base ..............................7 Adjusting the monitor ..............................8 Connecting the Monitor ............................. 9 Wall Mounting................................ -
Page 3: Safety
Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 4: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 5: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 6: Cleaning
Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. -
Page 7: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 8: Setup
Wire clip Packet Adapter Power Cable Quick Switch USB Cable Micphone DP Cable HDMI Cable Keypad Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. -
Page 9: Setup Stand & Base
Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:... -
Page 10: Adjusting The Monitor
Adjusting the monitor For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor’s angle. You are able to adjust the monitor as below: 120mm 90°... -
Page 11: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor and Computer: 1. Microphone in 2. Earphone (Combined with Microphone) 3. USB3.2 Gen1 downstream + fast charging 4. USB3.2 Gen1 downstream(Reflex Latency Analyzer)(Green port) 5. USB3.2 Gen1 upstream 6. AC in 7. -
Page 12: Wall Mounting
4. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for instructions on attaching it to the wall. Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. 0° 90°... -
Page 13: Adaptive-Sync Function (Available For Selective Models)
G-SYNC function Compatible Graphics Card: GeForece GTX 1070 Boost or higher (for a list of compatible graphics cards, please visit www.nividia.com/G-SYNC) Driver: GeForece 331.58 or higer OS: Windows 10 64b (other version of Windows are not supported by the provided HDR driver!) -
Page 14: Hdr
It is compatible with input signals in HDR600 format. The display may automatically activate the HDR function if the player and content are compatible. Please contact the device manufacturer and the content provider for information on the compatibility of your device and content. Please select “OFF”... -
Page 15: Adjusting
Adjusting Hotkeys Source/Up Dial Point/Down Game Mode/Left Light FX /Right Power/ Menu/Enter Power/Menu/Enter Press the Power button to turn on the monitor. When there is no OSD, Press to display the OSD or confirm the selection. Press about 2 seconds to turn off the monitor. Dial Point/Down When there is no OSD, press Dial Point button to show / hide Dial Point. -
Page 16: Quick Switch
Quick Switch ◄: When there is no OSD, press the ◄ button to open game mode function, then press ◄ or ► key to select game mode (FPS, RTS, Racing, G-SYNC Esports,Gamer 1, Gamer 2 or Gamer 3) basing on the different game types. ►: When there is no OSD, press “Right”... -
Page 17: Osd Key Guide (Menu)
OSD Key Guide (Menu) Enter Move Exit Enter : Use Enter key to enter the next OSD level Move : Use Left / Up / Down key to move OSD selection Exit : Use Right key to exit OSD Enter Move Exit Enter : Use Enter key to enter the next OSD level... - Page 18 Enter Select Select : Use Up / Down key to adjust OSD setting Enter Select Enter : Use Enter key to exit OSD to previous OSD level Select : Use Left / Right key to adjust OSD setting...
-
Page 19: Osd Setting
OSD Setting Basic and simple instruction on the control keys. Color Setup G-SYNC Processor ® G-SYNC Processor ® Audio Light FX Audio Light FX Extras OSD Setup Enter Move Exit Enter Move Exit 1). Press the MENU-button to activate the OSD window. 2). -
Page 20: Game Setting
Game Setting Game Setting Game Mode Shadow Control DialPoint QuickSwitch LED Overdrive Frame Counter Exit Enter Select For playing FPS (first Person Shooters) games. Improves dark theme black level details. For playing RTS (Real Time Strategy). Improves the image quality. For playing Racing games, Provides fastest response time Racing and high color saturation. -
Page 21: Luminance
Luminance Luminance Contrast Peak white (nits) Variable Backlight Mode Gaming Relative Gamma Default SDR Colors sRGB SDR Variable Backlight HDR Variable Backlight Auto Brightness Auto Black Level Max Brightness Exit Enter Select Contrast 0-100 Contrast from Digital-register. Peak white (nits) 40-450 Peak white setting.(Only for SDR) Ref. -
Page 22: G-Sync ® Processor
® G-SYNC Processor G-SYNC Processor ® Deep sleep USB Charge NVIDIA Reflex Latency Analyzer Exit Enter Select Set the “allow deep sleep mode” to ON or OFF. The deep sleep mode will turn the FPGA completely Deep sleep OFF/ON off after a certain amount of time when either the user presses the monitor DC power off button or the PC puts the monitor to sleep. -
Page 23: Color Setup
Color Setup Color Setup LowBlue Mode DP YCbCr sRGB HDMI YCbCr sRGB 6-axis color Color Temp. Warm Green Blue Exit Enter Select Off / Multimedia Decrease blue light wave by controlling color LowBlue Mode / Internet / temperature. Office / Reading DP YCbCr sRGB Off/On Disable or Enable DP YCbCr sRGB. -
Page 24: Audio
DP YCbCr sRGB Gamma curve selection for YCbCr formats on DP input in SDR mode; get/set methods (returns off or on): When enabled (default), the DP input will use sRGB gamma to display YCbCr inputs. When disabled, the DP input will use BT1886 gamma to display YCbCR inputs. Default is: ON HDMI YCbCr sRGB Gamma curve selection for YCbCr formats on HDMI input in SDR mode;... -
Page 25: Light Fx
Light FX Light FX Light FX Light FX Mode Breathing Pattern Rainbow Foreground R Foreground G Foreground B Background R Background G Background B Exit Enter Select Off / Low / Medium / Light FX Select the intensity of Light FX. Strong Static / Dark Point Sweep / Gradient Shift / Spread... -
Page 26: Extra
Extra Extra Input Auto Switch Input Select Logo Projector Medium Green Blue Reset Information Exit Enter Select Input Auto Switch Off/On Disable or Enable Input Auto Switch. Input Select HDMI1/HDMI2/DP Select Input Signal Source Logo Projector Off/Weak/Medium/Strong It’s projection logo function. 0 ~ 100 Red gain from Digital-register. -
Page 27: Osd Setup
OSD Setup OSD Setup Language English Timeout H.Position V.Position Transparence Break Reminder Exit Enter Select Language Select the OSD language Timeout 10-120 Adjust the OSD Timeout H. Position 0-100 Adjust the horizontal position of OSD V. Position 0-100 Adjust the vertical position of OSD Transparence 0-100 Adjust the transparence of OSD... -
Page 28: Led Indicator
LED Indicator Status LED Color Full Power Mode White Active-off Mode Orange... -
Page 29: Troubleshoot
Press to auto-adjust. Please refer to Regulation & Service Information which is in the CD manual Regulation & Service or www.aoc.com (to find the model you purchase in your country and to find Regulation & Service Information in Support page. -
Page 30: Specification
Specification General Specification Model name AG274QG Driving system TFT Color LCD Viewable Image Size 68.5 cm diagonal Panel Pixel pitch 0.2331mm(H) x 0.2331mm(V) Display Color 10.7B Colors 30k-222kHz (HDMI) Horizontal scan range 1k-255kHz (DP) Horizontal scan Size(Maximum) 596.74 mm 24-144Hz (HDMI) Vertical scan range 1-240Hz (DP) Vertical Scan Size(Maximum) -
Page 31: Preset Display Modes
Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY(kHz) FREQUENCY(Hz) 640 x 480 (60p Hz) 31.469 59.94 VGA(For HDMI) 720 x 480 (60p Hz) 29.855 59.71 SD(For HDMI) 720 x 576 (50p Hz) 31.25 SVGA 800 x 600 (60p Hz) 37.879 60.317 1024 x 768 (60p Hz) 48.363... -
Page 32: Pin Assignments
Pin Assignments 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0- DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2- TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock-... -
Page 33: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
