Rice Lake 882IS Instructions

882IS Intrinsically Safe Indicator
Battery Tester Instructions
This document contains important 882IS battery tester safety, operation and set up instructions. Before using the battery tester,
please read all instructions and cautionary information on the battery tester and the 882IS. More information on the 882IS
indicator can be found at www.ricelake.com/882IS.
Manuals and additional resources are available from Rice Lake Weighing Systems at
Warranty information can be found on the website at
Follow all manufacturer safety precautions for the indicator, the battery charger and the battery.
WARNING
Only use Rice Lake Weighing Systems approved charger for 882IS indicator batteries.
Batteries produce explosive gases and can explode.
Because hydrogen gas may be present, disconnect battery charger unit from AC power before connecting or
disconnecting output connectors from the battery.
Battery pack must be removed from the 882IS unit and taken to a non-hazardous location before testing.
CAUTION
Do not expose the tester to rain or moisture.
Do not disassemble.
Disconnect the tester from both the charger and the battery before maintenance or cleaning.
Connections to the battery must be made in the non-hazardous area before connecting the cable to the 882IS
IMPORTANT
indicator.
Battery must be fully charged for a healthy battery confirmation.
If modifications are made to the battery or it is changed in any way including field repair or modification, the FM
approval is void and all warranties, expressed or implied, are void. The customer becomes fully responsible and
liable for all such modifications.
Introduction
The 882IS Battery Tester is an instrument designed to test the six-volt, sealed, lead-acid batteries in the 882IS. While the
instrument is connected to the battery, it continuously measures the battery terminal voltage. When the Apply Load button is
pressed, the instrument measures voltage of the battery while it is under a full load. While the tester is connected to both the
battery and the IS6V2 battery charger, and the Apply Charge button is pressed, the instrument measures voltage going into
the battery from the battery charger.
Connector to
Battery
LED Display
Apply Charge
Button
March 31, 2022
www.ricelake.com/warranties
Connector to
IS6V2 Battery
Charger
Apply Load
Button
Figure 1. 882IS Battery Tester
www.ricelake.com/manuals
PN 207786 Rev A
