Hunter 28872 Parts Manual

Hardware
(Drawn to Scale)
x 2
x 4
x 2
x 3
x 1
x 11
x 16
x 16
Balancing
x 1
Kit
Wire x 3
x 4
Connector
3" Wood Screw
Flat Washer
Hanger
1.5" Wood Screw Bracket
Assembly
Canopy Screw
Set Screw
Screw, Blade
Iron Armature
Screw, Blade Blade
Assembly Assembly
Blade
Grommet
Screw,
Switch
Machine, 6-32
Housing
Assembly
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
R
SINCE 1886
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model # 28872

Parts List

Asm. Dwg. # 97010-01
Finish Antique Pewter
Item Name Qnty Part #
* Hanging System Kit 96761-14
Ceiling Plate
Canopy
Canopy Trim Ring
Hanger Ball / Downrod Assembly
Setscrew
Canopy Screw
Wood Screw
Flat Washer
Mounting Isolator
Switch/Housing Assembly 1 87330-01
Blade Iron Set 1 87332-05
Medallion 5 87334-01
Blade Set 1 75885-51
Screw, Blade Iron Armature 16 63730-17
Hardware Kit 1 97010-00-860
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Balancing Kit 1 07570-01
Cap, Finial 1 63987-02
Finial 1 07613-03
Globe/Shade 1 87333-02
Hunter Fan Company • 2500 Frisco Avenue • Memphis, TN 38114 • www.hunterfan.com •
28873
97010-02
New Bronze
96761-30
87330-01
87332-05
87334-01
75885-52
63730-17
97010-00-861
07570-01
63987-02
07613-03
87333-01
98000-01-721 10-26-2007 • 2007
©
