- Page 1 Courtesy of: DiscountCarStereo.com Serving the internet community since 1995 A2D-MBFM QUICK START BLUETOOTH INSTALLTION GUIDE FOR MERCEDES BENZ RADIOS Created September 3, 2021 Revised: March 14, 2022...
- Page 2 The A2D-MBFM works on any Mercedes Benz FM Band radio and does not interfere with normal radio operation or the operation of existing factory options. Installation Radio must be removed from dash to gain access to connectors.
- Page 3 Fig. 6 radio connector Connect BLACK wire to ground. We suggest removing radio chassis screw and securing ground terminal as seen Fig. 4 in Fig. 7. Factory plug Connect antenna terminal marked “TO RADIO” (See Fig. 4) to vacated antenna socket on radio.
- Page 4 Optional AUX input jack Bluetooth operation This module has supports for a wired AUX. Any RCA cable will suffice, but if you Turn ignition and radio “ON” purchased our optional cable, simply connect RCA plug to “AUX INPUT” jacks on 2.
- Page 5 • This product has no affiliation with Mercedes, Becker or Alpine • There are no warranties expressed or implied by purchase of this product © 1995-Mar-22 Discount Car Stereo, Inc. All rights reserved. Information in this document is subject • We’re not liable for misuse of this product.
