7. Storage

7.1 Storage Safety

At the end of the season, the disc harrow should be
thoroughly inspected and prepared for storage. Repair
or replace any worn or damaged components to
prevent any unnecessary downtime at the beginning of
the next season.
CAUTION
Personal Injury Hazard
Store the disc harrow in an area away from
human activity. To prevent the possibility of
serious injury, do not permit children to play on or
around the stored disc harrow.
NOTICE
To prevent damage to the disc harrow, store it in a dry,
level area.

7.2 Placing In Storage

1. Remove all entangled vegetation.
2. Thoroughly wash the disc harrow with a pressure
washer or water hose to remove all dirt, mud, or
debris.
3. Select an area that is dry, level, and free of debris
(inside a building is ideal). Move the disc harrow to
its storage area.
4. Lower the disc harrow onto blocks.
5. Disconnect the disc harrow from the 3-point hitch
and drive the tractor away from the disc harrow.
Refer to "5.8 Detaching From Tractor" on page
23. Do not leave the tractor attached to the disc
harrow.
6. Lubricate all grease points. Make sure all grease
cavities have been filled with grease to remove any
water residue from washing.
7. Touch up all paint nicks and scratches to prevent
rusting.
Titan Implement, LLC
(423) 334-0012

7.3 Removing From Storage

When removing the disc harrow from storage, follow
this procedure:
1. Before placing the disc harrow back into service,
replace any worn or defective parts and perform the
Pre-Operation Checklist.
2. Attach the disc harrow to the tractor 3-point hitch.
Refer to "5.3 Attaching to Tractor" on page 20.
3. Raise the disc harrow up off the blocks.
