- Page 1 USER MANUAL DONNER KARAOKE MICROPHONE DKM-KP100...
- Page 3 CONTENTS English 01-06 07-12 Français 12-18 Deutsche 19-24 Italiano 25-30 Español 日本語 31-36...
- Page 4 ENGLISH Welcome to Donner Thank you for purchasing the Donner Karaoke Microphone DKM-KP100! The DKM-KP100 is a Bluetooth wireless Karaoke microphone. You can enjoy singing at home or at parties for its easy to pair with your Bluetooth-enabled devices (smartphones, tablets and computers). Built-in battery and DSP offer long-lasting hours of fun and present brilliant sound effects.
-
Page 5: Package Include
● Do not clean the product with thinners, alcohol, or similar chemicals to avoid discoloration. ● Do not insert small objects into product. PACKAGE INCLUDE ● Donner karaoke microphone *1 ● Type C-USB cable * 1 ● Type C-3.5mm Aux cable *1 ●... -
Page 6: Polar Pattern
USING THE KP-100 Polar Pattern Top Level: - 77dB Both the acoustic environment and Range:30 dB microphone pointing have significant effects Frequency: 1000 Hz on the sound obtained, the best way to Source Level:0.1 Pa present brilliant sound is as follow. - Page 7 Subwoofer SPL VS FREQ dBSPL...
- Page 8 Long press for power on/off, short press for play/pause. Short press for Bluetooth connection/disconnection, long press about 3s for TWS pairing. Press to choose previous music selection. BGM volume level (6 level); Short press for volume up, long press for volume down. Short press for switching music styles;...
-
Page 9: Bluetooth Pairing
FUNCTIONS ◆ Bluetooth pairing “KP-100” Short press [PAIR] Voice prompts “Bluetooth connected” Note: indicator light will flash when waiting for pairing. PAIR indicator light will be on when pairing is successful. PAIR 3.Short press again [PAIR] can disconnect the Bluetooth pairing. - Page 10 ◆ TWS pairing (Duet sing) “KP-100” Long press [PAIR] for 3s Voice prompts “TWS on” Short press [PAIR] Note: indicator light will flash 2 times and stop 1 time when waiting for TWS pairing. PAIR 2. Voice prompts “TWS off” when one KP-100 disconnect the Bluetooth or power off. 3.TWS mode cannot be used when both KP-100s are connected to different smartphones 4.The KP-100 that connected to a Bluetooth device is the host and outputs the left channel.
- Page 11 Cautions! 1. The microphone has an automatic Bluetooth memory function. The microphone will automatically connect to the Bluetooth device that was last paired successfully when all devices are turned on. 2. Turn off Bluetooth on the device If you don't want to connect. ◆...
- Page 12 ◆ Charging The indicator light shows the battery voltage. 100% The indicator flashes up while charging. The indicator will be constant on after the charging is finished. 100% 100% 100% Type C-USB Cable...
-
Page 13: Specifications
SPECIFICATIONS Type Dynamic (31mm dia.) Full frequency internal magnetic horn 2* 5W Subwoofer (45mm dia.） Diaphragm 1 (45mm dia.) Frequency response 100Hz-10KHz Maximum SPL 110dB 1KHz THD<1% Bluetooth version Connector USB-type C、3.5mm Aux Battery Type Li-Polymer Battery Capacity 2600mAh Appr. 3h Battery Life Charge Time Appr. - Page 14 FCC Statement FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
