- Page 1 QUAD SOLAR FOUNTAIN Care and Instruction Manual...
- Page 2 51057CONSOL ASSEMBLY INSTRUCTIONS Thank you for purchasing a Kenroy Home water feature, you are now only minutes away from filling your home or outdoor living space with peaceful displ ays. Our guarantee backs all of our water features, please do...
- Page 3 51057CONSOL ASSEMBLY INSTRUCTIONS Please reference the separate parts list and ensure that all pieces are included in the package prior to assembly. More than one person may be required to complete the assembly of this product. To protect the finish, place all parts on a soft surface when unpacking.
- Page 4 51057CONSOL ASSEMBLY INSTRUCTIONS Please carefully open on a so surface to avoid damage. Place reservoir (B) onto base (A) and twist the reservoir (B) clockwise to secure. Feed pump power cord (D) and light cord through the plastic tube. Cords should exit through notch in base (A).
- Page 5 51057CONSOL ASSEMBLY INSTRUCTIONS Insert the cords into the slots in hole plug (J), and then insert the hole plug (J) into the plastic tube. Place the column assembly (C) into reservoir (B). Slot Plastic tube Join the bracket (E), tube (F) and stake (G) together, then attach bracket (E) to back of the solar panel (H) as shown.
-
Page 6: Final Steps
51057CONSOL ASSEMBLY INSTRUCTIONS FINAL STEPS Fill reservoir (B) with 2.6 gallons of Fill Line distilled water a little above the min. ll line. Insert pump plug (larger plug) into the hole for pump (D) on back of the solar panel (H), then insert light cord... - Page 7 51057CONSOL ASSEMBLY INSTRUCTIONS PUMP SAFETY & TROUBLESHOOTING To keep water clean • Periodically change water to prevent algae buildup. Impeller cover Pump housing Filter sponge Filter/ Front cover Rotor/Impeller If the pump fails to run: • Make sure the solar panel is receiving direct sunlight. Performance is directly related to the amount and strength of sunlight received.
- Page 8 51057CONSOL ASSEMBLY INSTRUCTIONS WATER FEATURE WARNINGS & SOLAR PANEL TROUBLESHOOTING Splashing may occur when the fountain is first turned on, protect surrounding surfaces as needed. Do not place the water feature on or near any surface that can be damaged by water.
-
Page 9: Frequently Asked Questions
51057CONSOL ASSEMBLY INSTRUCTIONS FREQUENTLY ASKED QUESTIONS What should I consider when selecting a water feature? In addition to your personal style tastes, be sure you have an area for your water feature that can be safely exposed to water, as splashing can occur. - Page 10 51057CONSOL ASSEMBLY INSTRUCTIONS FREQUENTLY ASKED QUESTIONS CONTINUED How much water do I need to keep in the water feature? Where possible in our water features, we have included fill lines to help you visualize the water level required for proper function. If your water feature does not include fill lines, please check the instruction manual for water capacity.
- Page 11 51057CONSOL ASSEMBLY INSTRUCTIONS FREQUENTLY ASKED QUESTIONS CONTINUED How do I level the water feature? For the water to flow properly, it is critical the water feature is level. If your water feature will be placed in an area with uneven ground, use a level and leveling shims to help level the water feature.
