- Page 1 CRMX Stardust User Manual LumenRadio AB 2023-04-03...
-
Page 2: Table Of Contents
Linking ......... . . LumenRadio AB... - Page 3 Industry Canada ......... Accessories LumenRadio AB...
-
Page 4: Safety Information
Cet appareil doit être branché à une prise de terre. Este aparato se debe conectar a una toma de tierra. Apparaten skall anslutas till jordat uttag. Apparatet må tilkoples jordet stikkontakt. Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan. Apparatets stikprop skal tilsluttes en stikkontakt med jord. LumenRadio AB... -
Page 5: English
13. Never submerge the product or the mains cable in water or any other liquid, in order to prevent electric shocks, fire, injury and other hazards. 14. Never carry the product by the cables and do not put the cord around sharp edges. LumenRadio AB... -
Page 6: Deutsch
13. Tauchen Sie das Produkt oder das Anschlusskabel niemals in Wasser oder in andere Flüssigkeiten ein, um einen Stromschlag, Brand, Verletzungen oder andere Gefahren zu vermeiden. 14. Das Produkt nicht am Netzkabel tragen und das Netzkabel nicht um scharfe Kanten legen. LumenRadio AB... -
Page 7: Introduction
Welcome to the large family of users of LumenRadio’s world-leading wireless DMX system. We hope that you will enjoy your brand new devices. We, at LumenRadio, have tailored this wireless DMX system to deliver reliability at its best. No matter if you’re using them at a night-club, a community theatre or on the set of a feature film, you should be able to trust its cable-like reliability, but without the hassle of cables. - Page 8 Simply link each receiver to the transmitted universe you want it to output. The system will automatically exchange encryption keys and other security parameters. The system will coordinate the frequency usage to avoid collisions so that multiple universes can be transmitted simultaneously. Multipoint-to-mutlipoint setup Figure 3: LumenRadio AB...
-
Page 9: Cognitive Coexistence
CRMX Stardust 2023-04-03 Cognitive coexistence Cognitive Coexistence is LumenRadio’s patented technology for real-time adaptive frequency hopping. ® It’s the foundation of our CRMX technology and the main reason why we are perceived as the most reliable and resilient wireless DMX system on the market. -
Page 10: Linking Key
Fixtures using CRMXchip, TiMo RX, TiMo FX or TimoTwo FX can all be upgraded. Contact your fixture’s manufacturer for further information. CRMX Nova, CRMX Outdoor and CRMX Slim can not be upgraded. LumenRadio AB... -
Page 11: Cloning Transmitters
Linking receivers by Linking key can be used both in CRMX Classic and CRMX , but it requires the manufacturer of the device to have enabled this in their fixture. Current LumenRadio products that supports this is; Aurora (through app or UI), Luna (through app) and Moonlite (through app). -
Page 12: Your Stardust Device
13. Decorative lights Power options Stardust has three different power options. It is possible to connect multiple power sources at the same time without damaging the device, this can for instance be used to have redundant power sources. LumenRadio AB... -
Page 13: Ac Inlet
TV spigot. Do not use screws that can go deeper than 27 mm. Safety wire There are holes on the device where a safety wire shall be fasted if mounted more than 2 meters (6 feet) above ground. LumenRadio AB... -
Page 14: Rack Mounting
Stardust can be mounted to a wall using the wall mounting kit (sold separately). Loosen the lower two M4 screws on each side of the unit, place the brackets and fasten them using the M4 screws. Tighten firmly. LumenRadio AB... -
Page 15: Settings And Operation
How to update 1. Go to https://lumenradio.com/products/stardust/ to download the latest firmware release. 2. Unzip the release and copy the .swu file to the root directory of a FAT formatted USB stick. -
Page 16: Status Icons
Web UI Most settings and functions can also be operated from the web UI embedded in the device. To access the web UI, take a browser and go to http://a.b.c.d where a.b.c.d is the IP address of your device. LumenRadio AB... -
Page 17: Linking
When unlinking, all receivers that are linked to this output - and within range - will be unlinked. The receivers will then be available to link to other transmitters. Universe mapping In the Universe menu, you can connect each Stardust output to an Ethernet universe, or alternatively disconnect it. LumenRadio AB... -
Page 18: Streaming Acn
Stardust tracks up to 4 data sources per output. Data is merged based on source priority, sourced with equal priority is merged according to a HTP (highest takes precedence) policy where the highest value for each DMX channel is used. If using ArtNet, no priority is used. LumenRadio AB... -
Page 19: Ethernet
• SSID (the name of the network) • Password • IP settings • DHCP (if the DHCP server shall be enabled or not) Client mode In client mode, the Stardust tries to connect to the specified WiFi network. LumenRadio AB... -
Page 20: Rdm
Power off option in the main menu. Charging the battery The battery will automatically charge whenever external power is connected to the device. If the battery is completely depleted it takes approx two hours for it to fully charge. LumenRadio AB... -
Page 21: Compliance Information
FCC Declaration of Conformity We LumenRadio AB, Svangatan 2B, 416 68 Gothenburg, Sweden, declare under our sole responsibil- ity that this product complies with Part 15 of FCC Rules. Operation is subject to the following two conditions:... -
Page 22: Fcc Radio Frequency Interference Warnings & Instructions
• Connect the equipment into an electrical outlet on a circuit different from that which the radio receiver is connected • Consult the dealer or an experienced radio/TV technician for help. Modifications made to the product, unless expressly approved by LumenRadio AB, could void the user’s right to operate the equipment. Industry Canada This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. -
Page 23: Accessories
CRMX Stardust 2023-04-03 Accessories All accessories can be ordered from your local CRMX distributor. Order code Description 800-2204 Stardust Rack Mounting Kit 800-2206 TNG Wall Mounting Kit 800-2208 TNG V-mount Battery mount LumenRadio AB...
