- Page 1 Installation Guide RSD PEFS-EL Series www.projoy-electric.com...
-
Page 2: Table Of Contents
RSD PEFS-EL Series CONTENT Operation Manual of Array Level Rapid Shutdown 1. Scope and General 2 Important Safety Precautions 3 About Rapid Shutdown 4 Operation 5 About PEFS Array-level Rapid Shutdown 6 Installation 7 Aftersales service and warranty 8 Contact us... -
Page 3: Scope And General
RSD PEFS-EL Series 1 Scope and General The manual only used to PEFS-EL Series Array-level Rapid Shutdown. Version Date Remark Chapter V1.0 2021-10-15 First Edition 6 Installation V2.0 2022-04-20 Content Modified 1. Changes or modifications not explained/approved in this manual voids your authority to operate this equipment. -
Page 4: Operation
RSD PEFS-EL Series 4 Operation 4.1 Normal operation: The PEFS will automatically switch to the off position, breaking the DC connection between the solar panels and the inverter, after the AC power to the PEFS is interrupted for longer than five seconds. The PEFS will automatically switch to the on position, restoring the DC connection between the solar panels and the inverter, once the AC power to the PEFS is restored longer than five seconds. -
Page 5: Installation
RSD PEFS-EL Series 5.3 Wiring Options Number of poles Appearance 3-core wire 1 *1.2m for AC power supply MC4 cable 6 Insatllation 6.1 Installation Requirements Open the box, take out PEFS, read this manual, and prepare cross/straight screwdriver. 6.2 Installation Steps 1) Pull out the product bottom bracket to both sides. - Page 6 RSD PEFS-EL Series 3) Wire the power AC connection to the terminals. Wire Color: According to American and Europe standard requirements -- American standard: L: Black; N: White; G: Green American Europe standard: L: Brown; N: Blue; G: Green&Yellow Europe Note! FB1, FB2 are used to remotely display the on and off states of the switch.
- Page 7 RSD PEFS-EL Series × √ √ √ × × √ √ √ √ × 6) Diagram PV Arrays PV Arrays PV Arrays PV Arrays Firefighter Safety Switch Inverter Distribution box 1-10 strings Grid PV Arrays PV Arrays PV Arrays PV Arrays...
-
Page 8: Aftersales Service And Warranty
RSD PEFS-EL Series 3) Step 3. Deactivate AC power circuit. PEFS will switch off in about 7 seconds. Red LED light off. AC POWER OFF Approx. 7 sec. 4) Step 4. Activate AC power circuit. PEFS switches on in 8 seconds. Red LED light on.
