Page 2: Table Of Contents
13.2. Trouble: Non stable flow or Empty pipe alarm ________________________________ 34 13.3. Trouble: Error overloaded ________________________________________________ 35 13.4. Trouble: Error excitation _________________________________________________ 36 13.5. Trouble: AD – converter error _____________________________________________ 36 14. How to order your MAGE1 .................. 37 15. Appendix ......................38 MAGE1 User Guide V1.5 12-1-2021... - Page 3 15.1. Country of Origin ______________________________________________________ 38 15.2. CE requirements ______________________________________________________ 38 15.3. Warranty ____________________________________________________________ 38 15.4. Contact ______________________________________________________________ 38 MAGE1 User Guide V1.5 12-1-2021...
-
Page 4: Introduction
1.3. Safety Instructions Please read this manual carefully before using the product. Keep this manual for future reference. Arkon Flow Systems, s.r.o will not be liable for any damage caused by improper use of the product or its accessories. The MAGE1 flowmeter must not be mounted in explosive hazardous areas. -
Page 5: Installation
Proper installation is extremely important in order for your flowmeter to work correctly. There are minimum sensor installation requirements that need to be respected at all Times. Please note that Arkon cannot warranty any installation which does not comply with these requirements. -
Page 6: Dry Liner
All MAGE1 sensors are supplied with a built in earthing electrodes that are sufficient for all applications with metal pipes and tanks. However on applications where all pipes and tanks are manufactured from plastic, it is recommended that earthing rings are also installed to ensure the maximum resistance of the sensor to earth is <1 ohm. -
Page 7: Mage1 Unit
3. MAGE1 Unit The MAGE1 flowmeter consists of the motherboard, a graphical display, touch-buttons and sensor housing. Through the display and with help of the controls, you can see and change flow and totalizers. The following symbols are used in this manual and on the flowmeter display. -
Page 8: Errors And Warnings
3.2. Errors and Warnings That is a list of the possible errors for MAGE1: Empty Pipe If the Empty pipe appears on the screen there is no medium in the pipes. Excitation Coils interrupted or disconnected. AD-converter AD converter fault. -
Page 9: Power Supply
- The power supply input is protected against reverse polarity. Colour coding: Brown … +U White …. GND Green … A (RS485) Yellow …. B (RS485) Gray …. I/O (4-20mA) Blue …. –V (4-20mA) Pink …. +V (4-20mA) MAGE1 User Guide V1.5 12-1-2022... -
Page 10: Outputs
5. Outputs 5.1. 4-20 mA output Each MAGE1 is equipped with embedded 4-20mA current loop output signal proportional to actual flow. Electrical Specifications: 12-bit DAC Maximum Resolution 3.9 µA. Output mode Active or Passive Colour coding: Brown … +U White …. GND Green …... -
Page 11: Rs485 Output
5.2. RS485 output MODBUS RTU – for detailed information see MAGE1 MODBUS guide Protocol Standart Arkon SW Baud rate 9600 baud/s BASIC CIRCUIT CONNECTIONS: Multi-Node Network with End Termination using RS485 Terminator R with resistance 100 should be connect to the end of line RS-485. -
Page 12: Internal Backup
When power is removed, the last Total and last Batch will be saved in the EEPROM until the unit is switched on again. Up to one hour of totalizers can be lost due to power off. MAGE1 User Guide V1.5 12-1-2022... -
Page 13: Mage1 Connection To Pc
7. MAGE1 connection to PC Picture above shows practical connection MAGE1 to PC through USB using RS485 – USB Converter. MAGE1 User Guide V1.5 12-1-2022... -
Page 14: Datalogger
Data from datalogger save into external Flash memory. Capacity for write entries is 131072 (one entry has All items in Datalogger are creating from 8 Bytes: Date Time Total+ For more information see section 9.16 - Datalogger. MAGE1 User Guide V1.5 12-1-2022... -
Page 15: Modbus
Reference 1 v. 1.0 modbus.org 12/02/02 Modbus Application Protocol Specification v. 1.1 modbus.org Reference 2 12/06/02 9.3. Technical data ARKON Flowmeter Modbus RTU specification Device type Slave Baud rates 9600, 14400, 19200, 38400, 57600, 115200 bits/sec. Number of stations Recommended: max. -
Page 16: General Modbus Rtu
The Modbus frame is shown below, and is valid for both requests and responses. Slave Address Function code Data 1 Byte 1 Byte 0-252 Bytes 2 Bytes Further details of the Modbus protocol can be found in Reference 1 and 2. MAGE1 User Guide V1.5 12-1-2022... -
Page 17: Commissioning
• If the end address is only part of a mapped Exception 2 (Illegal data address) holding register item (e.g. one half of a longint value) => Exception 2 (Illegal data address) Function code 17 (Report Slave ID) •There are no exceptions for this function MAGE1 User Guide V1.5 12-1-2022... -
Page 18: Modbus Holding Registers
9.8. Modbus holding registers In the following the holding registers for the MAGE1 Modbus RTU module are described. Modbus Section Start Register Password Real-time measurement Datalogger memory management 1000 Info 1500 Display 2000 User settings 4000 Factory settings 10000 Datalogger items Holding registers memory map When writing to the Holding registers, data validity is not checked. -
Page 19: Real-Time Measurement
Convert read value to binary number. Number one means error. For more information see chapter Chyba! N enalezen zdroj odkazů. Empty pipe Overloaded Reserved Reserved Excitation AD Converter Read Reserved Overload flow Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved MAGE1 User Guide V1.5 12-1-2022... -
Page 20: Datalogger Memory Management
Datalogger memory size - memory size in bytes, according to Flash memory size capacity is 1048576 bytes Datalogger base address - actual base address in memory, value in range of 0 to Datalogger memory size MAGE1 User Guide V1.5 12-1-2022... -
Page 21: Info
3=l/min, 4=l/s Unit Volume, 0=UKG, 1502 1501 Longint 1=USG, 2=m3, 1504 1503 Longint Contrast [%] Unit Flow – actual flow unit (default m Unit Volume – totalizer unit (default m Contrast – Set display’s contrast MAGE1 User Guide V1.5 12-1-2022... -
Page 22: User Settings
2029 ---- Current Min 2032 2031 ---- ---- Current Max Datalogger Interval 0= OFF 1= 15 s 2034 2033 Longint 2= 30 s 3= 1 min 4= 2 min 5= 5 min 6= 10 min MAGE1 User Guide V1.5 12-1-2022... - Page 23 Current Min – Max – Setup of the current output range, corresponds to the actual flow-rate within given range Flow Min – Max – Setup of measurement flow-range Flow Real value = Actual value / 1000 (only positive values) MAGE1 User Guide V1.5 12-1-2022...
-
Page 24: Factory Settings
1000000 Constant Excitation frequency, 0=1/60 Hz, 1=1/30 Hz, 2=1/15 Hz, 4036 4035 Longint 3=1/5 Hz, 4=1.5625 5=3.125 Hz, 6=6.25 Hz Excitation, 4038 4037 Bool 0=OFF, 1=ON 4040 4039 Bool Reserved Reset 4042 4041 Bool system MAGE1 User Guide V1.5 12-1-2022... - Page 25 Zero Flow Constant – Set manually value for zero flow constant Excitation Frequency – choose the excitation frequency. Excitation – write zero for turn OFF the excitation. Default ON Reset – Reset all system. After application it must be restarted by connecting SW with flowmeter MAGE1 User Guide V1.5 12-1-2022...
-
Page 26: Datalogger
9999 1048575 65535 Date+Time 131071. 10002 10001 1048575 Longint 4294967295 Total 10004 10003 1048575 65535 Date+Time 131072. 10006 10005 1048575 Longint 4294967295 Total All items in Datalogger are created from 8 bytes: Date Time Total+ MAGE1 User Guide V1.5 12-1-2022... - Page 27 The data are written into Flash memory in clusters of 16 records. It takes 16 times datalogger interval to fill the cache memory before it is written into Flash thus last 16 records might not be seen in the flash memory. MAGE1 User Guide V1.5 12-1-2022...
-
Page 28: Sotware
To uninstall Flowmeters SW in „Settings“ (Start menu), under „Add/remove programs“ you select Flowmeters 2 and then click the „uninstall“ button. SW Flowmeters allows settings of all flowmeters manufactured by Arkon. To start with MAGE1 click on its icon or select MAGE1 from menu. -
Page 29: Service Section
When asked for a password, simply enter the correct password for the given section (User and Factory password) and click OK. • TIME - The next tab is "Time". Here, you can enter the correct time. MAGE1 User Guide V1.5 12-1-2022... - Page 30 This graph shows current flow data for the last 100 seconds of measurement. On right side are actual errors in red color. Actual flow and totalizers data Actual Error – marked red Graphical representation of flow in time MAGE1 User Guide V1.5 12-1-2022...
-
Page 31: Statistic Section
10.4. Statistic section Load data from Save data Print MAGE1 to .cvs file the data *.CSV file This format file is standard output format for databases. Examples open in Microsoft Excel. MAGE1 User Guide V1.5 12-1-2022... -
Page 32: Cleaning
11. Cleaning MAGE1 electromagnetic flowmeters do not have any moving parts so special maintenance is not required, however we strongly recommend: 1. Once a year check overall meter appearance - check for any obvious mechanical damage or water leakage. 2. Do yearly mechanical cleaning of the sensor to remove any sedimentation from liner or electrodes. -
Page 33: Specifications
Stainless steel 1.4301 Outer casing Carbon steel (1.0036) as standard External coating Lacquered finish (anticorrosive) Accessories options Earthing rings for plastic and lined pipes 100 Ω Coils resistance Other features Earthing through 3 and 4 electrodes MAGE1 User Guide V1.5 12-1-2022... -
Page 34: Troubleshooting
Check if the Insert the cable flowmeter is powered correctly with correct voltage, is the display working now? Contact technical support MAGE1 User Guide V1.5 12-1-2022... -
Page 35: Trouble: Non Stable Flow Or Empty Pipe Alarm
Make better installation of all the time? the flowmeter Are there bubbles in Eliminate the air bubbles. the liquid? Has the liquid Electromagnetic minimal conductivity flowmeter is not ≥ 20µS/cm applicable for this liquid Contact technical support MAGE1 User Guide V1.5 12-1-2022... -
Page 36: Trouble: Error Overloaded
Eliminate Check if the real flow is not the high flow bigger than maximum applicable flow Contact technical support MAGE1 User Guide V1.5 12-1-2022... -
Page 37: Trouble: Error Excitation
13.4. Trouble: Error excitation Contact technical support 13.5. Trouble: AD – converter error Contact technical support MAGE1 User Guide V1.5 12-1-2022... -
Page 38: How To Order Your Mage1
In case you are interested in purchasing a MAGE1 flowmeter, you can either contact the Arkon Sales Department and request a quote to serve as a basis for ordering, or you can use the Arkon price-list as an easy order form. -
Page 39: Appendix
MAGE1 flowmeter are manufactured conforming to CE requirements. 15.3. Warranty The warranty conditions are covered by Arkon Flow Systems, s.r.o. Terms & Conditions of Sale and by Arkon Flow Systems, s.r.o. Return Regulations and Warranty Conditions. The Arkon Flow Systems, s.r.o Terms &...
