- Page 1 LS-US2 Media Station Quick Installation Guide ENGLISH AREC Inc.© All Rights Reserved 2021. l www.arec.com All information contained in this document is Proprietary...
- Page 2 LS-US2 Quick Installation Guide Federal Communication Commission interference statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 LS-US2 Quick Installation Guide Hereby, AREC Inc., declares that this Media Station is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.
-
Page 4: Specifications
LS-US2 Quick Installation Guide Introduction Featuring a compact and stand-alone design, AREC LS-US2 Media Station consists of diverse features and functionality, including multi-signals capturing, recording synchronously, codec, streaming online, live broadcasting, and web-based monitor page, providing complete presentation or lecture capture solution. -
Page 5: Product Appearance
1.For the external USB storage device* 2.Available for the USB mouse, keyboard and touch devices 3.Available for the USB audio/video input NOTE: The LS-US2 can detect and record to USB storage devices using FAT32, NTFS, exFAT, Ext3, Ext4 file systems. - Page 6 LS-US2 Quick Installation Guide Connection Video output DP Power projector USB Micro B Video output HDMI external hard disk USB mouse USB cam USB mouse USB Keyboard Speakerphone USB Keyboard Speakerphone network USB cam projector IP cam Interactive Whiteboards Interactive Whiteboards...
- Page 7 LS-US2 Quick Installation Guide Accessing the Administrator pages 1. Connect HDMI output with a display monitor and use the RJ-45 Ethernet cable to connect an IP-based network to the WAN port. 2. Connect your PC/NB to be the same network area with the device. Enter the IP address displayed in the lower right side of the screen in your browser to access the System Administration webpage.
- Page 8 ]. Then the camera is ready for video input selection. Select the target camera by its IP address. For video source of encoder, enter RTSP or RTP connection URL. * For instance, the camera and LS-US2 connected under the same router with the same LAN address. LS-US2(192.168.0.10) Router(192.168.0.1)
- Page 9 LS-US2 Quick Installation Guide Step 2: Set up audio source in [ Audio ] of [ Media I/O ]. Choose the correct USB audio source. If there are more than 2 USB audio inputs connected to the system, you only could assign one of them for the recording.
- Page 10 LS-US2 Quick Installation Guide Getting start a recording Start a recording from the top panel Press [ ] button and recording begins. Press [ ] button to end a recording. Start a recording from the APK of iFPD Consult your iFPD supplier to install the AREClick APK.
- Page 11 LS-US2 Quick Installation Guide CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Important Security Policy Precautions 1.Please open the product package carefully; we recommend you keep this packaging for future transport, storage or maintenance use.
- Page 12 AREC Inc.© All Rights Reserved 2021. l www.arec.com All information contained in this document is Proprietary Made in Taiwan Date : 2021.12.01 Version : 2.20...
