- Page 1 USER MANUAL PLY SEPARATOR MLT PLYS 15 3 + 1 4 + 1,5 5 + 1,5 Épaisseur de revêtements 1/8’’ + 5/32’’ + 3/16’’ + de votre bande avant décorticage inch 1/32’’ 1/16’’ 1/16’’ Lame de décorticage (en mm) 3 + 1 Épaisseur de revêtements...
- Page 2 Index: CE Declaration of conformity:....................................1 Electrical connection to the grid:.....................................4 Description:...........................................4 Characteristics:..........................................4 User instructions:........................................5 Changing and adjusting the blade:..................................6 Stroke adjustment of rollers:....................................8 Electrical diagram:........................................10 Parts list:.............................................10...
-
Page 3: Declaration « Ce» De Conformite
DECLARATION « CE» DE CONFORMITE We, undersigned, MLT ZI du Clos Marquet - Rue Michel Rondet - CS 70059 - 42 200 Saint-Chamond, France The person(s) authorised to compile the technical documentation : - Gilles FURNON : Product Manager, MLT... -
Page 4: Electrical Connection
Electrical connection Connect the equipment to a 230 v or 400 v three-phase depending on the voltage shown on the technical specifications plate, and its corresponding earth connection, without taking into consideration the direction of the motor rotation. This equipment has a rotation selector. Description The ply separator is activated by a reducer motor and drive shaft, with manually controlled height adjustment by way of eccentrics. - Page 5 User instructions WARNING THIS DEVICE INVOLVES THE HAZARD OF HANDS BEING TRAPPED AND CUT BY THE PINCH ROLLERS. THE USER SHOULD EXERCISE GREAT CARE AND PRECAUTION IN THE MATERIAL ENTRY ZONE, AVOIDING THE PLACEMENT OF HANDS IN THIS ZONE. Once the equipment is connected to the mains, it must be fixed to a table or support through the four holes in its base, to avoid overturning or falls.
- Page 6 The cutting thickness is adjusted by turning the height regulation control found on the right hand side. Perform a test on a corner of the belt, or on a scrap piece of the same material, to see if the height adjustment and pressure is correct.
- Page 7 Also, use a 5mm. Allen key to the arm. Once the blade arm assembly has been taken off, loosen the two M8 bolts that fix the blade to the support, with a 13mm key. Remove the old blade and insert the new one, up to the limit set by the two adjustment screws in the rear. These two limiting screws in the rear determine the proximity of the blade to the pinch rollers.
- Page 8 Adjust this measure to 108.5 mm. After changing the blade, reset the support to its original position by firmly tightening the two M8 Allen screws. Set adjustment of rollers: NOTE: The incorrect stroke adjustment of the rollers may cause the blade’s cutting edge to break if they are too close, or on the contrary, may cause poor traction when using thin materials.
- Page 9 To adjust the height of the lower roller, adjust the M8 screw that is on the right hand side cover, next to the height regulation control WARNING ATTENTION: Although safety systems are present, due to the function of the equipment, there is a high risk of trapping and cutting in the open zone.
- Page 10 Electrical connection to the grid Electrical diagram...
- Page 11 Electrical diagram...
- Page 15 HOTLINE MLT service Our MLT representatives will assist you remotely and in pictures HOTLINE MLT service is at your disposal to assist Our teams are available to answer your questions in 10 you live in the resolution of any problems you may...
- Page 16 PLY SEPARATOR MLT PLYS 15 MLT Minet Lacing Technology More than 70 years of innovation at your disposal TECHNICGUM distributor Logo www.mltgroup-conveyor.com - info@mltgroup-conveyor.com...
