Fichier : UG-AT188N
Version : V1.2
AT188N
User guide
1/29
AXEM Technology
11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com
Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €
Advertisement
Table of Contents
Related Manuals for AXEM Technology AT188N
Summary of Contents for AXEM Technology AT188N
- Page 1 Fichier : UG-AT188N Version : V1.2 AT188N User guide 1/29 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €...
-
Page 2: Table Of Contents
Fichier : UG-AT188N Version : V1.2 Table des matières Révision ........................... 4 Before Beginning ........................5 Product Overview........................5 Strength of Product ........................5 H/W Specification........................7 Product Composition ........................ 9 Product Composition......................9 Composition of Each Product’s parts ................9 6.2.1... - Page 3 Fichier : UG-AT188N Version : V1.2 “Erase data” ......................16 8.1.4 “Data space” ......................16 8.1.5 “Comm & Mode” ...................... 16 8.1.6 “Bluetooth Pairing” ....................17 8.1.7 “Power down” ......................18 8.1.8 System Configuration ...................... 18 “Barcode” ......................... 18 8.2.1 “UHF RFID”...
-
Page 4: Révision
Fichier : UG-AT188N Version : V1.2 1 Révision Description Date Version Author Check First release 2019/02/26 Second release 2020/06/11 4/29 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com... -
Page 5: Before Beginning
Fichier : UG-AT188N Version : V1.2 2 Before Beginning The objective of user guide is to pass the basic contents related with AT188`s maintenance and smooth uses. User guide inclusive of text, images, logos, product name may not be distributed, modified, displayed, reproduced (in whole or in part) without the prior written permission of ATID CO.LTD... - Page 6 Fichier : UG-AT188N Version : V1.2 • Exclusive charging package for only battery charging will be offered (Option: To be Offered in the near future) 6/29 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com...
-
Page 7: W Specification
Fichier : UG-AT188N Version : V1.2 5 H/W Specification Performance Characteristics Processor ARM7 Core Support Operating System Windows, Android, iOS (BLE Only) Memory 128Kbyte Display LCD & LED Indicator Weight 160g (with Battery & UHF Option, without GPS) Operation Temperature -20~60℃... - Page 8 Fichier : UG-AT188N Version : V1.2 Reading Range 0M~1M (According to Tag & Environment) Writing Range 0M~0.5M (According to Tag & Environment) Max. RF output 26dBm, Circular Protocol EPC Gen2, ISO/IEC 18000-6C Special Function Anti-Collision HF 13.56MHz RFID Reader/Writer (Option) Frequency 13.56MHz...
-
Page 9: Product Composition
Fichier : UG-AT188N Version : V1.2 6 Product Composition Product Composition The basic package for AT188 is shown as below <Device Body> <Micro USB Cable> <Battery> User Guide <Hand strap or Neck strap> <Adapter (Optional)> Composition of Each Product’s parts 6.2.1 Front Side... -
Page 10: Right And Left Of Back Side
Fichier : UG-AT188N Version : V1.2 • LCD Display: Show the collected data and current state of device • Operation Button: Use its button in case of selecting the barcode and RFID Tag reading and various menu • Reset Button: Restart the device by force. -
Page 11: Function Of Each Button
Fichier : UG-AT188N Version : V1.2 • Strap Hole: The portability of device can be improved by connecting the Hand • Strap or Neck strap with strap hole Function of Each Button Scan button Reset Button < Operating Button> ▲ Button: Scroll the screen upward or select the next item. The function of Barcode and •... -
Page 12: Message Output Section
Fichier : UG-AT188N Version : V1.2 : Show the Scanner Mode and show the activated state of Barcode ) and RFID ( ) through the ICON (Bright Condition: ON, Dark Condition: OFF) 10:00P: Show the set time. (There is a possibility to be different with the present... -
Page 13: Power On And Off
Fichier : UG-AT188N Version : V1.2 10:00 P 1 . Run Program 2 . Setup Param 3 . Download App Power ON and OFF 7.2.1 Power ON ① Press the scan button for 2 seconds. ② After “Booting…” message is come out at the screen, please move the hand from scan in case of that “Wait…”... -
Page 14: Rfid Tag Data Reading (Scan)
Fichier : UG-AT188N Version : V1.2 10:00 P 10:00 P Scan Ready 1837922 RFID Tag Data Reading (Scan) Convert to the RFID mode by pressing the ▲ button and making the ① RFID( ) ICON bright with device on (Bright Condition: ON, Dark Condition: OFF) ②... - Page 15 Fichier : UG-AT188N Version : V1.2 Show the system configuration menu if user press the ▲ button and Scan ② button for several seconds. Select the “2. Setup Param” by using either ▲button or ▼ button and ③ then, enter the configuration menu through scan button ④...
-
Page 16: Settings & Changes
Fichier : UG-AT188N Version : V1.2 8 Settings & Changes Scan Configuration 8.1.1 .”Scan data” After scan configuration, AT188 gets back to either barcode or RFID scan 8.1.2 “View data” View Data shows the stored data located in the internal memory, in case of Batch Process Mode. -
Page 17: Bluetooth Pairing
Fichier : UG-AT188N Version : V1.2 Realtime-USB: transfer the read data to the equipment connected with USB in real time ② Batch-BTH: Transfer the read data to equipment connected with Bluetooth in a lump (Batch Process mode) ③ Batch-USB: Transfer the read data to equipment connected with USB in a lump (Batch Process mode) 8.1.7 “Bluetooth Pairing”... -
Page 18: Power Down
Fichier : UG-AT188N Version : V1.2 8.1.8 “Power down” The time to automatically turn off the device can be selected as 1 minute, 2 minutes, 5 minutes, 10 minutes, 30 minutes, 60 minutes, 120 minutes, None. The device will be automatically turned off itself after designated time. -
Page 19: Hf Rfid" (Hf Only)
Fichier : UG-AT188N Version : V1.2 8.2.2.2 “MODE” Set up the tag Reading Mode of RFID among Multi Tag / Single Tag / Multi Repeat 10:00 P * MULTI SINGLE Multi Repeat “MULTI”: Set up Multi Tag Reading mode to read all the nearby tags. -
Page 20: Scan Time
Fichier : UG-AT188N Version : V1.2 8.2.3.2 “MODE” Set up Tag Reading Mode of RFID to one of UID only, UID+Read User, USN ID. 10:00 P * UID only UID+Read User USN ID “UID only”: Output the UID (Unique Identification Number) of HF RFID Tag “UID+Read User”: Additionally, output the user data behind the UID... -
Page 21: Data
Fichier : UG-AT188N Version : V1.2 8.2.5.1 BTH Protocol Select the communication protocol to be used when connecting with Bluetooth BTH HID: It will connect through Human Interface Device and the data to be transferred will • be inputted in accordance with the contents typed through Keyboard at the place where the cursor is located. - Page 22 Fichier : UG-AT188N Version : V1.2 8.2.6.1 “Record” After reading the barcode, user can decide to use the barcode type ID or time to be appended when storing or transferring the data “*” is marked in selected item. 10:00P Barcode Only: The only read barcode data will be stored or transferred •...
-
Page 23: System
Fichier : UG-AT188N Version : V1.2 8.2.6.3 “Quantity” Choose to input tag quantity. Quantity settings can be operated in the only barcode mode and its settings might be possible after reading the barcode tag. User can get AT188 to input quantity from 1 to 9999 and it cannot read another tag before inputting applicable tag quantity. -
Page 24: Default
Fichier : UG-AT188N Version : V1.2 8.2.7.3 “Display” Set up the time to turn off the LCD for saving battery and LCD will be automatically turned off in accordance with the designated time 10:00 P N one * 1 minute... - Page 25 Fichier : UG-AT188N Version : V1.2 25/29 AXEM Technology 11 rue Auguste Perret, 94042 Créteil, FRANCE – info@axemtec.com – +33 (0)1 41 94 11 85 – www.axemtec.com Siret : 45071140300045 - APE : 4652Z - RCS : CRETEIL 450711403 - N° TVA intracom : FR05450711403 - Capital : 500 000,00 €...
-
Page 26: Firmware Update
Fichier : UG-AT188N Version : V1.2 Firmware Update Firmware for AT188 can be updated for improvement of its device. If user does not have a proper knowledge on software and hardware, please ask distributor or manufacturer to handle the issue since the recovery of device cannot be possible, in case of that the problem comes up in doing update. - Page 27 Fichier : UG-AT188N Version : V1.2 ⑥ Enter the Firmware Download Modem in AT188`s configuration menu and move to the configuration mode by pushing the ▲ button and Scan button at the same in the switch-off state. 10:00 P 1 . Run Program 2 .
- Page 28 Fichier : UG-AT188N Version : V1.2 “Online” will be appeared when clicking “off line” and Firmware version will be displayed as well. Start the download for Firmware by clicking the download button After completion of download, new firmware will be automatically restarted...
-
Page 29: Warranty And Technical Supports
Fichier : UG-AT188N Version : V1.2 10 Warranty and Technical Supports All of ATID products have one-year warranty from date of manufacture However, there is a principle in ATID that the customer will be charged for the repairs, in case of the damage caused by customer even if it is under warranty period We recommend requesting the warranty and technical support.
