PHASER
Pure Water System
Effective August, 2020
Pure Water
Window Cleaning System
Operation and Maintenance
Manual
Overview
Congratulations on your purchase.
Thank you for purchasing the Phaser Pure Water
System! With proper care, this unit will provide you with
years of trouble free service. This system was designed
with professional window cleaners in mind. The Phaser
will help you clean faster, safer, and better than ever
before, leaving spot free results that you and your
customers will love!
The following is provided to help you understand how
your system purifies water. The Phaser is a multi-stage
water purification unit using Carbon/Sediment, Reverse
Osmosis (RO), and Deionization (DI) to remove impurities
from water before delivery to surfaces for cleaning.
General lifespan of the filters will vary depending on
feed water TDS (Total Dissolved Solids). Based on an
average TDS of 100 ppm (parts per million) in your water,
approximately 10,000 gallons of water can be passed
through the Carbon/Sediment and DI filters before
replacement filters are needed. Lower TDS levels in
the source water will allow for a longer lifespan, while a
higher TDS source levels will lead to a shorter lifespan. It
is recommended that the Carbon/Sediment and DI filters
be replaced at the same time. The RO membrane is
rated to process 100,000 gallons under ideal conditions.
Failure to properly maintain the RO membranes will
reduce the life of the filter
In The Box
Parts Check
• TS-2200 (Phaser) System
• RO Filter
• DI Filter
• Carbon Filter
• TDS Meter
• Bypass Hose
• Quick-Connect Shut Off
1. Unpacking/Inspecting The System
Your system is packaged to stay undamaged in transit.
Please inspect all components to ensure no damage
has occurred prior to continuing. Carefully remove the
packaging material from around the system and discard.
Inspect your Phaser for any shipping damage. If damage
has occurred, notify the shipping company that made
delivery to begin a damage claim.
Phaser Pure Water System Operation and Maintenance Manual - 1
Advertisement
Table of Contents
Summary of Contents for abc PHASER
- Page 1 The RO membrane is rated to process 100,000 gallons under ideal conditions. Failure to properly maintain the RO membranes will reduce the life of the filter Phaser Pure Water System Operation and Maintenance Manual - 1...
-
Page 2: Initial Setup
The bypass valve is also the primary way you can control the pressure of your system. Opening the 2 - Phaser Pure Water System Operation and Maintenance Manual... - Page 3 6. Using A WaterFed Pole 5. TDS (Total Dissolved Solids) Meter ® Once your Phaser system is hooked up, and you have Total Dissolved Solids are the minerals and salts within a WaterFed® pole connected to the unit, you’re ready source water that lead to spotting on glass as the water to clean windows.
-
Page 4: Filter Replacement
3. Screw the DI filter housing back onto the outlet of TDS levels of the source water to the level of pure the RO filter. Do not overtighten. 4. Replace quick connect shut off valve. 4 - Phaser Pure Water System Operation and Maintenance Manual... -
Page 5: 12. Troubleshooting
Do not allow the filters or system to freeze. Failure to 1. Low tap pressure is one of the most common causes do so could result in damage to your filters and Phaser of low flow of pure water. Source water pressure is the system. - Page 6 If necessary replace brass fittings. Replacement parts that the DI filter is spent. Testing before and after the can be ordered from ABC or bought from a local store. DI filter will verify that there is not another issue. If the The plastic hole size is ½”...
- Page 7 3. Check brass fittings for damage or deformation. If necessary replace brass fittings. Replacement parts can be ordered from ABC or bought from a local store. The plastic hole size is ½” national pipe thread (NPT) and the Brass fitting connection are a standard ¾” Garden hose If for any reason the customer wishes to return the thread (GHT).
-
Page 8: Replacement Parts
Shut-off Valve TDS Meter HMTDS-3 WF601311 WF2CSC-6 WF2CDI-6 Optional Upgrades Booster Pump PSI Pressure Gauge WF1000-BP TA-PG www.abcWindowSupply.com 12371 Mead Way, Littleton, CO 80125 1.800.989.4003 // ©abc Window Cleaning Supply, Inc. 8 - Phaser Pure Water System Operation and Maintenance Manual...
