CONNECT TO AUDIO SOURCE (CONT'D)
1A For RCA connection:
Connect one end of the RCA cable to the corresponding RCA jack on the back of the subwoofer
Then connect the other end of the cable to the RCA outlet on your device (TV and gaming console, etc )
Note: the RCA cable is not included in the box and must be purchased separately
1B For 3 5 mm connection:
Connect one end of the provided 3 5 mm cable to the auxiliary input on the back of the subwoofer
Then connect the other end of the cable to the 3 5 mm audio jack on your device
2 Plug your headphones into the headphone jack on the control pod Adjust the volume either from
the control pod or the audio source
3 Power speakers on/off by sliding the power on/off button on the wired control pod
1A
2
All manuals and user guides at all-guides.com
1B
3
