KLAUS Multiparking trendvario6X00 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Service Manual
trendvario
6X00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the trendvario6X00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KLAUS Multiparking trendvario6X00

Summary of Contents for KLAUS Multiparking trendvario6X00

  • Page 1 Service Manual trendvario 6X00...

  • Page 2: Table Of Contents

    Contents Introduction .......................... 4 Switching on the system ...................... 4 Parking space designation ....................4 Safety instructions ........................5 Customer area ........................... 6 Start screen ......................... 6 Customer menu ........................6 Setting the language ......................7 Teaching a new chip ......................7 Select chip storage location and enter name ...............
  • Page 3 Add radio remote control to parking space ................ 31 Add Bluetooth to parking space ..................31 Add WiFi numbers to parking space .................. 31 Settings ..........................32 Project info, HMI version, parking process statistics ............33 Firmware Update ....................... 34 Automatic logout from the service menu................

  • Page 4: Introduction

    Introduction This document describes the operation of the TrendVario 6X00 parking system. Switching on the system Appears after connecting to the mains power and switching on the main switch. ► Press red button to switch on the system. Parking space designation Every parking space has a 4-digit parking space number.

  • Page 5: Safety Instructions

    Safety instructions Meaning of the signal words Warning sign, signal Meaning word Indicates a hazardous situation which could result in death or serious injury if not WARNING avoided. NOTICE Indicates material damage: the product or the environment could be damaged. Warning and danger symbol Meaning Symbol...

  • Page 6: Customer Area

    Customer area Start screen the next maintenance is due Item Description Customer menu: to open the customer menu press here. Indicator showing that the next maintenance is due. NFC reader. To hold the SmartChip up to. Display for time and date. Customer menu Item Description...

  • Page 7: Setting The Language

    Setting the language ► Select the language by pressing the buttons Teaching a new chip ► Hold the new chip to the NFC reader. The following screen appears. Item Description Input fields for the customer PIN when teaching a chip. Input keypad.

  • Page 8: Select Chip Storage Location And Enter Name

    Select chip storage location and enter name NOTE Up to three chips can be taught for each parking space. The customer can choose to which of the three storage locations they wish to add the new chip. If a chip is already assigned to one of the three storage locations and the customer selects this storage location, then the previous chip is deleted and replaced by the new chip.

  • Page 9: New Parking Process With Closed Gates

    New parking process with closed gates ► Hold the SmartChip to the reader. the next maintenance is due ► Press start. ► Wait until parking space is made available. Page 9 of 72...
  • Page 10 ► Gate is opened. Gate is opened Please wait ► Park vehicle and close gate. Press start ► Gate is closed  end of parking process. Page 10 of 72...

  • Page 11: New Parking Process With Open Gates

    New parking process with open gates ► Hold the SmartChip to the reader. the next maintenance is due ► Gates are open  press check button. ► Hold the SmartChip to the reader again  gates are closed. Press start Page 11 of 72...

  • Page 12: Acknowledging Emergency Stop As Customer

    ► Gate is closed  system ready for another parking process. Acknowledging emergency stop as customer If the emergency stop has been pressed or the system was switched on, the emergency stop must be acknowledged by the customer. This is done by pressing the red ʺQUITʺ button. NOTE To do so, the emergency stop button on the selection panel must be unlocked.

  • Page 13: Acknowledging Malfunction As Customer

    Acknowledging malfunction as customer The following error screen appears. Item Description Button for acknowledging malfunction as customer. If the error is no longer present, the customer home page appears after pressing the Quit button. If the error persists, the HMI remains in the red screen Display of the current parking process, in which an error occurred, if a parking process has just been carried out.

  • Page 14: Service Menu

    Service menu Access to the service menu ► Press the ʺServiceʺ button. ► Enter the individual service PIN via the keypad. ► Press the “Login” button  the service menu opens. Page 14 of 72...

  • Page 15: The Service Home Page

    The Service home page This page appears after logging into the Service menu. Maintenance key NOTE The maintenance key bridges the ʺGates safely closedʺ signal. This allows the system to be run with open gates if the maintenance key is turned. The maintenance key is located on the selection panel housing below the selection panel.

  • Page 16: Transferring System Configuration

    Transferring system configuration Before initial commissioning, the system configuration must be transferred from the user tablet to the master. NOTE The electrical installation of the system must be fully finished. All addresses of the controller must be set. ► Log in to the user tablet service menu. ►...
  • Page 17 Once the transfer is finished, the message "transfer to master complete" appears in this window. ► Close the window by pressing the "back" button. The transfer is now complete. Page 17 of 72...

  • Page 18: Acknowledging The Emergency Stop

    Acknowledging the emergency stop The emergency stop is displayed at the top right of every service page and can be acknowledged there. Item Description The red emergency stop symbol indicates that the emergency stop circuit is not OK. This can occur if the emergency stop button on the selection panel has been pressed. To acknowledge, the emergency stop button must be unlocked and the red emergency symbol must be pressed.

  • Page 19: Acknowledging Errors

    Acknowledging errors The errors are displayed at the top right of every service page and errors can be acknowledged there. Item Description The red error symbol indicates that an error has occurred. A triggered emergency stop is also evaluated as an error and results in an error being displayed.

  • Page 20: Manual Mode

    Manual mode The complete parking system can be controlled in locked manual mode via the ʺServiceʺ page. NOTE With locked manual mode, the system will only carry out a movement if the desired travel direction is free. This means that all platforms are in a position which will not lead to a collision. NOTICE Locked manual mode does not absolve the operator of their responsibility for careful operation of the system in manual mode!

  • Page 21: Selection Of Row And Grid

    Selection of row and grid ► Select row and grid in which to run manual mode. Item Description Display and button for selecting the row. Display and button for selecting the grid. Button for closing the number field without accepting the number entered. Number field for entering the row or the grid.

  • Page 22: Running In Manual Mode

    Running in manual mode It is possible to run the system in manual mode using the buttons ʺLift UFʺ, ʺLower UFʺ, ʺGF leftʺ, ʺGF rightʺ, ʺLift basementʺ, ʺLower basementʺ, ʺLift FPʺ, ʺLower FPʺ, ʺOpen gateʺ and ʺClose gateʺ. The platform moves as soon as the button is pressed, and stops when the button is released.

  • Page 23: Display Of Signals From The Master Cabinet

    Display of signals from the master cabinet Item Description Display of the signal indicating that all gates are closed securely. Illuminates green once all gates are closed securely. Display of the signal indicating that the motor protection of the unit is OK. Illuminates green if the motor protection of the unit is OK.

  • Page 24: Providing Parking Space In Automatic Mode

    Providing parking space in automatic mode In the service menu all parking spaces can also be approached without a chip or remote control. The field ʺRequest a parking spaceʺ is provided for this. When the ʺRequest a parking spaceʺ button is pressed, a number field appears, where the parking space number of the customer can be entered.

  • Page 25: Error Log

    Error log Item Description Time period of the errors displayed in the log Error log Selection of the time period for displaying the errors in the log Button for updating the log if the time period has been changed Page 25 of 72...

  • Page 26: Error Code List

    Error code list General errors Code Error description No error in sub-distributor Emergency stop not OK Release for movement missing UF errors Code Error description Runtime Lift UF exceeded Runtime Lower UF exceeded Runtime UF open left locking exceeded during lowering Runtime UF open right locking exceeded during lowering Locking UF left opened in idle mode Locking UF right opened in idle mode...
  • Page 27 Both UF limit switches at upper and lower positions are activated at the same time UF upper position limit switch is not released within 2.5 secs UF bottom limit switch is not released within 2.5 secs General gate errors Code Error description Both limit switches gate open + gate closed are activated at the same time Light barrier interrupted, while gate is closing...

  • Page 28: Parking Spaces

    Errors in master Code Error description 1010 Emergency stop not OK 1020 Unit motor protection has tripped 1030 Gate motor protection has tripped 1040 At least one error has occurred in a sub-distributor 1050 Light barriers test unsuccessful 1060 Current relays test unsuccessful 1500 Corridor cannot be created, check 4th rotary switch 1510...

  • Page 29: Add Chip To Parking Space

    Add chip to parking space ► Press on one of the three chip storage locations. Each parking space has three chip storage locations ► Select chip storage location and hold up to the NFC reader. Page 29 of 72...

  • Page 30: Add Remote Control To Parking Space

    Add remote control to parking space ► Press the ʺIRʺ field. This opens a number field. ► Enter IR remote control number. ► Confirm with Enter. Page 30 of 72...

  • Page 31: Add Radio Remote Control To Parking Space

    The radio number is now entered as 1 for the parking space 1. The red indicator shows that the entry has been accepted. Add radio remote control to parking space See section on add remote control to parking space. Same procedure. Add Bluetooth to parking space See section on add remote control to parking space.

  • Page 32: Settings

    Settings NOTE The selection panel does not change between summer and winter time Item Description Change over of the length units between centimetres and inches. Depending on the settings, the max. vehicle measurements are displayed in centimetres or inches during the parking process. Entering the next maintenance in days (adjustable from 1-365 days) 30 days before the next maintenance period expires, the display ʺNext maintenance dueʺ...

  • Page 33: Project Info, Hmi Version, Parking Process Statistics

    Project info, HMI version, parking process statistics Item Description Field for entering the system type. Field for entering the project number. Field for entering the street of the project. Field for entering the street number of the project. Field for entering the town/city of the project. Field for entering the county/region of the project.

  • Page 34: Firmware Update

    Firmware Update NOTICE During a software update of the parking system, you must not leave the ʺFirmware updateʺ page of the selection panel, or switch off the parking system! Item Description Button for reading in the software versions of all controllers (sub-distributor + master). Display of the software versions of the sub-distributors.

  • Page 35: Automatic Logout From The Service Menu

    Automatic logout from the service menu After 10 minutes the user is automatically logged out of the service menu. NOTE 10 seconds before the automatic logout takes place, a window appears, notifying the user of the automatic logout. This can be extended by a further 10 minutes in this window. Item Description Button for extending the automatic logout.

  • Page 36: Status Indication Led

    Status indication LED Limit switch UF top: green & yellow Limit switch is actuated (UF is in top end position).  green & white Limit switch is not actuated (UF is not in top end position).  No LED lights There is no power supply.
  • Page 37 Limit switch LF locking front / rear: green & yellow Limit switch is actuated (locking is closed).  green & white Limit switch is not actuated (locking is not closed).  No LED lights There is no power supply.  Tilt sensor UF / LF: green &...

  • Page 38: Checklist Error

    Check whether pins are bent within the M12 plug. Check whether the cabling between the sub-distributors and the master cabinet has been carried out correctly (see assembly instructions TrendVario6X00 cabling). The bus cabling always starts on the master cabinet and leads to the 1st sub- ...
  • Page 39 Error Cause of error / error rectification Check software status. ► In the service menu on the "Firmware" page check the software versions of all sub- distributors and the master. The software must be at least V1.3 on both. If this is not the case, an update must be carried out (see chapter "Update instruction").
  • Page 40 Error Cause of error / error rectification No controller board plugged in within the sub-distributor? ► Plug controller into sub-distributor. No movement possible in manual mode Check whether the unit is running and the rotation direction of the unit cable is set as right- hand rotation.

  • Page 41: Error In Electrical / Assembly / Commissioning

    Error in electrical / assembly / commissioning Error Cause of error / error rectification ► Move gate to "Gate closed" position. ► Adjust limit switch with counterpart. ► Switch system off and on again. ► Check whether the limit switch is still flashing red. Check whether the closure plug is plugged in on the last gate box.
  • Page 42 Error Cause of error / error rectification Unplug all gate power cables and check whether a pin has moved backwards. Also check this with the socket connector plugs. Check on all dead boxes to see whether a pin has moved backwards. Also check this with the "Gate closed socket connector plugs.

  • Page 43: Error In Automatic Mode

    Cause of error / error rectification Check whether the green power LED on the MCU in the master cabinet is illuminated. Check whether the cabling of the radio system was carried out correctly (see assembly instructions TrendVario6X00 cabling). Radio hand- held...

  • Page 44: Components In The Master Cabinet For Systems With Sliding Gates

    Components in the master cabinet for systems with sliding gates Test Safety relay MCU (radio, BT, Current Resistor Connection Gates closed IR receiver relay for supply and hydraulics Current Safety relay Emergency relay Pit closed stop Test relay Main Contactor fuse Socket FI service...

  • Page 45: Components In The Master Cabinet For Systems With Vertical Gates

    Components in the master cabinet for systems with vertical gates Emergency Relay stop Main Pits closed Potential-free Contactors fuse securely Contacts Safety device Safety Socket Relay Vertical gates device Gates secure Motor protection Power Master Unit pack Controller Power System Contactor pack Power pack...

  • Page 46: Update Of The Selection Panel And The Controllers

    Update of the selection panel and the controllers Download update files ► Download update files from the KLAUS Multiparking cloud. Link to cloud to download the update files: https://cloudservice.multiparking.com/index.php/s/uAv1liHYoeNMNen TrendVario1 ► Mark and download files. Page 46 of 72...

  • Page 47: Update Via Iphone

    Update via iPhone ► Press "WLAN" on the mobile phone settings. ► Search for the network "hmi_6X00" and press. ► When requested enter the WLAN password klaus3658. Connection has been created with the WLAN of the selection panel. ► Install FTPManager from the App Store. ►...
  • Page 48 ► For display name enter HMI, for host address 10.0.0.1 and enter user name and password, then press "Save". The iPhone is now connected with the selection panel. Load controller firmware on selection panel: ► Call up downloaded file. ► Click on the open file symbol, then press "HMI", and then press on the Firmware folder. Page 48 of 72...
  • Page 49 ► Press save. A window appears stating that the file is being copied. Once the file has been completely copied, this window closes and the transfer is complete. Load selection panel update package on selection panel: ► Call up downloaded file. ►...

  • Page 50: Update Via Android

    ► Press save. A window appears stating that the file is being copied. Once the file has been completely copied, this window closes and the transfer is complete. Update via Android ► Press "WLAN" on the mobile phone settings. ► Search for the network "hmi_6X00" and press. ►...
  • Page 51 ► Install AnyFTP from the App Store. ► Press the "AnyFTP" icon, then press the "+" on the top in the middle. ► For host name enter 10.0.0.1 and enter password admin, then press "Save". The Android device is now connected with the selection panel. Load controller firmware on selection panel: ►...
  • Page 52 A window appears stating that the file is being copied and another once the upload is completed. ► Confirm both with OK The transfer is now complete. Load selection panel update package on selection panel: ► Press on the "Firmware" folder. ►...
  • Page 53 A window appears stating that the file is being copied and another once the upload is completed. ► Confirm both with OK The transfer is now complete. Page 53 of 72...

  • Page 54: Update Via Windows Pc

    Update via Windows PC ► Install FileZilla (or other FTP programme. Download FileZilla at Download FileZilla at https://filezilla-project.org/download.php?platform=win64 or other FTP programme. ► On the PC call up the network connections. ► Double-click the network connection TV6X00_6000-00022. ► In the field "Enter network security key" enter the password klaus3658 and press "Next". TV6X00_6000-00022 ►...
  • Page 55 Load controller firmware on selection panel: ► Open FileZilla programme. ► Open "firmware" folder (if the "firmware" folder is not present, one must be created). ► Search for the controller update file (KMA110_ _crc.bin), right click on it and then click on "Upload" Once this file can be seen on the right side, the upload of the controller firmware file is complete.
  • Page 56 Load selection panel update package on selection panel: ► Open FileZilla programme. ► Open "firmware" folder (if the "firmware" folder is not present, one must be created). ► Search for the UpdatePackage.zip file, right click on it and then click on "Upload" Once this file can be seen on the right side, the upload of the update package is complete.

  • Page 57: Carry Out Update Of The Selection Panel

    Carry out update of the selection panel ► Login to the service menu. ► Press on the "Firmware" button. ► Press the "Update HMI" button. Page 57 of 72...
  • Page 58 ► A window opens, here press the "Refresh" button. The installation of the selection panel update package is now complete. Page 58 of 72...

  • Page 59: Carry Out Update Of The Controller

    Carry out update of the controller ► Login to the service menu. ► Press on the "Firmware" button. ► In the "Available software versions" field press the "Dropdown button" and select the previously downloaded firmware file (Kma110_ _crc.bin) by pressing. Kma110_V1.3_crc.bin Page 59 of 72...
  • Page 60 ► Press the “Read file” button. Kma110_V1.3_crc.bin ► Press the “Read file” button. Kma110_V1.3_crc.bin ► Press the "Update all" button. Kma110_V1.3_crc.bin Page 60 of 72...
  • Page 61 The controller update then starts. NOTE Do not close the "Firmware" page during the update, since otherwise the update is cancelled! If the firmware update fails, the firmware version must be reloaded! The update takes approx. 10 minutes per grid. The update of the master also takes approx.

  • Page 62: Commissioning System

    Commissioning system ► Call up the "settings" page. ► Press the “restart” button. ► A window opens, here press the "Yes" button. ► Save system configuration on master. NOTE For procedure see chapter "Transferring system configuration". Page 62 of 72...

  • Page 63: Remote Parking Systems

    Remote parking systems Product overview Range of A remote control system consists of an evaluation unit MCU, various receivers (infrared, radio, Bluetooth) and a remote control such as an IR / wireless remote control or the smartphone. If a parking system is equipped with a remote control system, the user can switch on or off.

  • Page 64: Controller Options

    Controller options Function Infrared (IR) When dialing, the user must have access to the parking system, as an infrared signal has a relatively  short range and the IR receiver must be mounted on the system. The angle of incidence of the receiver is 30°. An exact targeting of the recipient is essential. ...
  • Page 65  Battery life > 1,5 years (depending on application)  Compatible with the Control Unit Simply (MCU) Version KLAUS Multiparking and matching IR and RF  sensors of the IFFS series. When replacing a remote control, it must be re-taught at the radio receiver. The new address of the ...
  • Page 66 Radio receiver (only in conjunction with a Flashlight) The Radio Sensor (SN-RF-xx-CAN-CS-KLAUS) is compatible with the IFFS series systems for KLAUS Multiparking systems and operates on different radio frequencies (depending on the country of use). Connected to a Control Unit, the sensor receives radio telegrams from the hand transmitters in the series, evaluates the telegrams and sends the control data to the Control Unit.

  • Page 67: System Overview

    System overview Technical system overview max. 20m max. 20m Terminal Box max. 20m max. 20m Remote Box Radio remote control connections = CAN-Bus cable 2x2x0,34mm² Radio remote control connections Page 67 of 72...

  • Page 68: Configuration (Radio / Bluetooth)

    Configuration (Radio / Bluetooth) Radio remote control with IR / radio hand-held transmitter In order for an IR / radio transmitter to control a MCU via radio, the remote control must be taught in the system. To do this, the following steps must be performed on a connected radio receiver and the hand-held transmitter. ►...

  • Page 69: Confirmation

    Confirmation I received an instruction to the handling of the system. The content of this technical manual is known to me. Date | Signature Registration Number Vehicle type Pitch number. Page 69 of 72...
  • Page 70 Notes Page 70 of 72...
  • Page 71 Notes Page 71 of 72...
  • Page 72 When you smile, we've achieved our goal. Premium parking systems from KLAUS Multiparking are tailored to individual requirements. They use the available space efficiently and enable easy access and exiting. Each of our systems is the result of decades of experience, solid know-how and the high quality of our products made in Germany.
