KLAUS Multiparking multibase U20 EB Series Product Data

Page 1
Section
Dimensions
Car data
Page 2
Width
dimensions
Page 3
Approach
Load plan
Page 4
Pit
Paving
Page 5
Electrical
installation
Technical
data
Page 6
Tec. data
To be perfor-
med by the
customer
Page 7
Description
100
U20 EB
Standard type
1
Special system: maximum load for extra charge.
2
To follow the minimum finished dimensions, make sure
3
to consider the tolerances according to VOB, part C
(DIN 18330 and 18331) and the DIN 18202.
Car width for platform width 230 cm. If wider platforms
4
are used it is also possible to park wider cars.
Potential equalization from foundation grounding connection
5
to system (provided by the customer).
Slope with drainage channel and sump see page 3.
6
In compliance with DIN EN 14010, 10 cm wide yellow-black
7
markings compliant to ISO 3864 must be applied by the
customer to the edge of the pit in the entry area to mark the
danger zone (see „load plan" page 4).
At the transition section between pit floor and walls no hollow
8
mouldings/coves are possible. If hollow mouldings/coves are
required, the systems must be designed smaller or the pits
accordingly wider.
9
6
Water drainage
230
x 530 for vehicle up to 5.00 m = 16'4'' long
(550 for vehicle up to 5.20 m 17' long)
KLAUS Multiparking GmbH
Hermann-Krum-Straße 2
D-88319 Aitrach
Fon +49 (0 ) 75 65 5 08-0
Fax +49 (0 ) 75 65 5 08-88
info@multiparking.com
www.multiparking.com
10 7
8
5
Grounding
140
Type H1
U20 EB-425 425
U20 EB-495 495
If necessary, protective gratings are installed at the back area
9
The upper platform is a frame construction. Flooring can
10
be provided by the customer (e.g. soil/turf, sandbed/turfblock,
sandbed/marble, etc.). Maximum weight of customer coating
250 kg/m
The upper platform is at ground level and is traversible when in
lowered position (vehicle load: 2600 kg maximum, wheel load:
650 kg maximum). On special conditions the upper platform
may be used as parking space.
A separate maintenance manhole must be installed by the
11
customer (with manhole cover, ladder and a connecting
passage to the pit). A save maintenance access with a door
has to be provided by the customer – please contact KLAUS
Multiparking. The hydraulic power unit and ventilation system
are also housed in the maintenance manhole
After operation, the system must always be run into the
lowest final position (key interlock).
PRODUCT DATA
2000 kg / 2600 kg
1
Dimensions
All space requirements are minimum
finished dimensions.
Tolerances for space requirements
Dimensions in cm.
EB (single platform) = 2 + 1 vehicles
Suitable for
Standard passenger cars:
Limousine, station wagon, SUV, van
according to clearance and maximal
surface load.
Standard
width 190 cm
weight max. 2000 kg
wheel load max. 500 kg
Clearance profile
160
15°
100
500 (520)
H2 car height
385 165
455 200
.
2
U20 EB
2
.
+ 3
3
0
2
Special
4 4
190 cm
max. 2600 kg
max. 650 kg
30
13°
6°
125
