USER MANUAL
Series 1 - Industrial STD Models
JH 19T14 STD-AA1-AAAA - 19.0 inch Industrial Display (STD)
User Manual STD Series 1
Updated: 03 Feb 2022
Created: 7495/363
Please visit www.hattelandtechnology.com for the latest electronic version of this manual.
Doc Id: INB100036-2 (Rev 9)
Approved: 6987

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hatteland Technology Series 1 and is the answer not in the manual?

Questions and answers

Related Manuals for EMBRON Hatteland Technology Series 1

Summary of Contents for EMBRON Hatteland Technology Series 1

  • Page 1 USER MANUAL Series 1 - Industrial STD Models JH 19T14 STD-AA1-AAAA - 19.0 inch Industrial Display (STD) User Manual STD Series 1 Updated: 03 Feb 2022 Doc Id: INB100036-2 (Rev 9) Created: 7495/363 Approved: 6987 Please visit www.hattelandtechnology.com for the latest electronic version of this manual.
  • Page 2 Copyright © 2021 Hatteland Technology AS Eikeskogvegen 52, N-5570 Aksdal, Norway. All rights are reserved by Hatteland Technology AS. This information may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine- readable form without the prior written consent of Hatteland Technology AS.

  • Page 3: Table Of Contents

    Contents Contents ..................3 Contents of package ..................5 General .................... 7 About this manual ..................8 About Hatteland Technology ..............8 www.hattelandtechnology.com ..............8 Contact Information ..................8 Basic Construction ..................9 Product Labeling ..................10 Front Logo Label ................12 Installation ..................13 Installation and mounting .................14 Ergonomics ....................14 Cables ......................16 Cable Entries &...
  • Page 4 Contents Technical Drawings - Accessories ..........43 Technical Drawings - JH 19TSV STD-A1 ..........44 Sun Visor - 19” ................44 Technical Drawings - JH MMDRO STD-A1 ..........45 Rotary Bracket - 17” to 26” ............45 Technical Drawings - JH MMDBR STD-A1 ..........46 Mounting Bracket - 17”...

  • Page 5: Contents Of Package

    Contents of package This product is shipped with: Item Description Illustration 1 pcs of Standard DVI Signal Cable. DVI-D 18+1P Male to DVI-D 18+1P Male Single Link- Length 2.0m HA-SDM-2M 1 pcs of Standard VGA Signal Cable. DSUB 15P Male to DSUB 15P Male - Length 2.0m HA-VGA-2M-32 1 pcs of power cable European Type F “Schuko”...
  • Page 6 This page left intentionally blank...

  • Page 7: General

    General...

  • Page 8: About This Manual

    Hatteland Technology AS About this manual The manual contains electrical, mechanical and input/output signal specifications. All specifications in this manual, due to manufacturing, new revisions and approvals, are subject to change without notice. However, the last updated and revision date of this manual are shown both on the frontpage and also in the “Revision History” chapter. This user manual is a standard/general manual that applies to all variations of its product family, i.e.

  • Page 9: Basic Construction

    Basic Construction Basic Construction - Series 1 Touch Screen (option) Sun Visor (option) Centerbox Water Cover (option) Mounting Bracket (option) Mechanics Glass Casing Rotary Bracket (option) Front Frame Bonding Electronics / PCB’s User Controls Logo label (option) Example with mounting bracket Example with sun visor, mounting bracket and rotary bracket General IND100077-75...

  • Page 10: Product Labeling

    Product Labeling Introduction This section details the locations, content details and specifications for factory mounted labels for all currently available standard Hatteland Display Industrial Display (STD) models. This information will in most cases also apply for most Customized Models as well, but may differ based on customer requirements, in that case, please refer to the customized User Manual (paper or electronic version, dependent on customer requirements).
  • Page 11 Product Labeling Label Locations Number ID and coloring based on “Label Size and Types“ table from previous page. All illustrations below are seen from rear (and side where needed) with connectors facing down. Actual labels regarding its size and text orientation vs product size is drawn in.

  • Page 12: Front Logo Label

    Product Labeling Warranty Label If you are to perform service on a unit still under warranty, any warranty will be void if this label show signs of removal attempts or damaged by screw driver. This label is located on the back of the product and covers a key screw. This is to aid service departments in determining if there has been any unauthorized service on a unit still under warranty.

  • Page 13: Installation

    Installation...

  • Page 14: Installation And Mounting

    General Installation Recommendations Installation and mounting 1. Most of our products are intended for various methods of installation or mounting (panel mounting, bracket mounting, ceiling/wall mounting etc.); for details, please see the relevant mechanical drawings. 2. Adequate ventilation is a necessary prerequisite for the life of the product. The air inlet and outlet openings must definitely be kept clear;...
  • Page 15 General Installation Recommendations General mounting instructions 1. The useful life of the components of all Electronics Units generally decreases with increasing ambient temperature; it is therefore advisable to install such units in air-conditioned rooms. If there are no such facilities these rooms must at least be dry, adequately ventilated and kept at a suitable temperature in order to prevent the formation of condensation inside the display unit.

  • Page 16: Cables

    General Installation Recommendations Cables Use only high quality shielded signal cables. Cable Entries & Connectors (Marked area) - Illustration only Bottom View Back View Maximum Cable Length Any cable should generally be kept as short as possible to provide a high quality input/output. The maximum signal cable length will depend not only on the signal resolution and frequency, but also on the quality of the signal output from the computer/radar.

  • Page 17: Rotary Bracket And Mounting Bracket - Assembling/Finalization

    General Installation Recommendations Rotary Bracket and Mounting Bracket - assembling/finalization Illustration shows Mounting Bracket “JH MMDBR STD-A1” / “JH 23TBR T01” and “Rotary Bracket JH MMDRO STD-A1” combined and not combined. The brackets are available separately and may be delivered in parts. Some disassembly/assembly is required. Use the provided screws/ bolts/nuts included in the package.
  • Page 18 General Installation Recommendations JH MMDBR STD-A1 Hatteland Technology AS Eikeskogvegen 52 JH 23TBR T01 N-5570 Aksdal 23” Hatteland Technology AS Eikeskogvegen 52 N-5570 Aksdal Installation IND100078-26 Hatteland Technology AS Eikeskogvegen 52 N-5570 Aksdal...

  • Page 19: Physical Connections - Std Based Models

    Physical Connections - STD Based Models Connection area of display (illustration) RGB IN DVI-I IN AC Power Input Cable Tension To reduce tension on the cables you connect, secure them with a cable tie to the base mounted clamp or to the chassis hinges. For certain models a base mounted clamp is available (FIG 1).
  • Page 20 This page left intentionally blank...

  • Page 21: Operation

    Operation...

  • Page 22: User Controls

    User Controls USER CONTROLS OVERVIEW The tactile only keypad controls with 5 push buttons and the Status LED Ring. The keypad provide the user to control brightness, access the configuration menu and use the Direct Access / Hotkeys functionality. The LED ring will provide feedback for various status or modes that the unit can or currently operates in.
  • Page 23 User Controls KEYPAD FUNCTIONALITY Up (+) button Power / Menu button Right / Hotkey button Push Buttons Left / Hotkey button +Direct Access / Hotkeys Status LED Ring Down (-) button MENU function as: Power On/Off & On Screen Display (OSD) menu access. LEFT (◄) function as: Direct Access / Hotkey, exit the current function and navigate to the previous OSD menu.

  • Page 24: Status Led Overview

    Status LED Overview Status LED Overview The unit features a multi purpose indicator LED status ring which through different patterns and realtime activity gives back the status of the signal detected, power on/off, calibration, menu activity and more. The LEDs are multicolored which either illuminate green or red, based on the activity.

  • Page 25: Osd Menu Overview

    OSD Menu Overview OSD Menu Quick Start To understand the workflow of the OSD menu, follow these steps for a quick start. The table shows the various OSD overlays you might encounter while navigating, adjusting parameters or when text messages are displayed. The OSD menu always remembers its last position which is indicated by the red bar.

  • Page 26: Osd Functions Map

    OSD Menu Overview OSD Functions Map The OSD menu consists of main function groups with sub menu groups. On the following pages a complete map of the available functions is shown. The following section should be viewed in color. Please note that the red selection bar is not indicated in any of the following illustrations.
  • Page 27 OSD Menu Overview Main Group #1 - Picture In this group (with its sub groups) the user can adjust parameters that directly impact the picture visually for all incoming signal sources. Some of these Sub Groups have more options, please review this map to quickly determine the location of your desired function/option.
  • Page 28 OSD Menu Overview Main Group #2 - Setup In this group (with its sub groups) the user can adjust parameters that directly impact settings for the video controller software, OSD settings and gain access to settings that are physically accessible for the user. None of these settings will impact on the picture visually for the incoming signal sources.
  • Page 29 OSD Menu Overview Main Group #3 - Source In this group (with its sub groups) the user can change the signal input source and setup the Picture-In-Picture views or Picture-By-Picture views which both take advantage of the Maritime Multi Display functionality. Some of these Sub Groups have more options, please review this map to quickly determine the location of your desired function/option.
  • Page 30 OSD Menu Functions OSD Menu Functions The following section covers all possible settings that the user can (in a certain mode) encounter or needs to adjust. The structure of these commands are identified as paths. Please review the “OSD Menu Overview Map” earlier in this manual to see the different paths if you have not already made yourselves familiar with the OSD Menu structure.
  • Page 31 OSD Menu Functions Display / Picture / Sharpness Increase/decrease the overall image sharpness. This affects the whole panel, and applies to all signal inputs and window overlays (PIP/PBP). Use it to increase the visual quality of signals from older equipment or electronically weak signals.
  • Page 32 OSD Menu Functions Display / Picture / Advanced Settings / Graphic Scaling / Fill Aspect Ratio - DEFAULT Function only available in “Full” menu mode & when analog DVI/VGA/RGB signal are set as Main Source. Set the image scaling to fit the entire native TFTs panel resolution based on correct aspect ratio (factory default).
  • Page 33 OSD Menu Functions Display / Picture / Picture Info / Main Source Please note that a valid input signal must be present for this function to work. This function will show the picture information as detected by the display controller such as Physical Port Input Name, Current Signal Resolution, H-Freq.
  • Page 34 OSD Menu Functions Display / Setup / OSD Settings / OSD Vert Position Move the vertical (left/right) position of the OSD Menu overlay. The OSD Menu can only be moved within the max display area available. ● Level adjusts from 0-100 steps. 100 is default. Display / Setup / OSD Settings / Full Menu Function only available through password protection.
  • Page 35 OSD Menu Functions Display / Setup / User Settings / Auto Source Select Enable/disable the automatic detection and selection of any signal input and show it full screen. If you have a external unit that switches between several other external signal inputs of different signal origins, this function will be helpful and switch to the signal that appears to be valid since the last detection was made.
  • Page 36 OSD Menu Functions Display / Setup / Load Default / Load User Default This function will restore any User Default settings that have been saved previously. If no User Defaults was found, nothing will be re-configured. The User Defaults consists of custom settings and all parameters adjusted in the entire OSD Menu by user.
  • Page 37 OSD Menu Functions Display / Setup / Service Menu / ECOM Firmware Ver Function only available in “Full” menu mode. This will show the firmware version on the internal micro controller. This information is stored electronially on a board chip component. Example: “SW100062-1E5”. Display / Setup / Service Menu / Elapsed Time (hr) Function only available in “Full”...
  • Page 38 This page left intentionally blank...

  • Page 39: Specifications

    Specifications...

  • Page 40: Specifications - Jh 19T14 Std-Aa1-Aaaa

    Specifications - JH 19T14 STD-AA1-AAAA SPECIFICATIONS Note: All specifi cations are subject to change without prior notice! Please visit www.hatteland-display.com for the latest electronic version. TFT Technology: Physical Considerations: • High Quality SHARP TFT • 483 (W) x 444 (H) x 82 (D) mm - 19.02" (W) x 17.48" (H) x 3.23" (D) •...

  • Page 41: Technical Drawings

    Technical Drawings...

  • Page 42: Technical Drawings - Jh 19T14 Std-Aa1-Aaaa

    Technical Drawings - JH 19T14 STD-AA1-AAAA IND100132-147...

  • Page 43: Technical Drawings - Accessories

    Technical Drawings - Accessories...

  • Page 44: Technical Drawings - Jh 19Tsv Std-A1

    Technical Drawings - JH 19TSV STD-A1 Sun Visor - 19” IND100132-67...

  • Page 45: Technical Drawings - Jh Mmdro Std-A1

    Technical Drawings - JH MMDRO STD-A1 Rotary Bracket - 17” to 26” IND100132-46...

  • Page 46: Technical Drawings - Jh Mmdbr Std-A1

    Technical Drawings - JH MMDBR STD-A1 Mounting Bracket - 17” to 20” IND100132-69...

  • Page 47: Technical Drawings - Jh 19Tap Std-A1

    Technical Drawings - JH 19TAP STD-A1 CRT Adapter - 19” TFT to 21” IND100132-44...

  • Page 48: Technical Drawings - Jh 19Tap Std-B1

    Technical Drawings - JH 19TAP STD-B1 CRT Adapter (Custom) - 19” TFT to 21” IND100132-187...

  • Page 49: Technical Drawings - Jh 19Ved Std-A1

    Technical Drawings - JH 19VED STD-A1 VESA Adapter - 19” IND100132-45...

  • Page 50: Technical Drawings - Jh 19Twc Std-B1

    Technical Drawings - JH 19TWC STD-B1 Water Cover (HW01) - 19” IND100132-136...

  • Page 51: Appendixes

    Appendixes...

  • Page 52: Pin Assignments - Common Connectors

    Pin Assignments - Common Connectors Note: Not all connectors may be available on your specific product. This depends on the amount of additional hardware installed from factory, or customized solutions. These pin assignments are for the common connectors used. Connectors are seen from users Point Of View (POV). 18/24/24+5 pin DVI-D, DVI-I, Single Link, Dual Link Combined Female Analog RGB/VGA, 15-pin DSUB High Density Female Onboard or via DVI-4 adapter...

  • Page 53: Pin Assignments - Multifunction Cable Outputs

    Pin Assignments - Multifunction Cable Outputs Connectors that are commonly available on the Multifunction Cable or customized cable. Connectors are seen from users Point Of View (POV). Pin Assignments - 9P Serial COM RS232 4 3 2 1 9 8 7 6 Pin 01 - CTRL(+) Buzzer Control (+) (+12V input for driving the buzzer) Pin 02 - TX Transmit Data...

  • Page 54: Basic Trouble-Shooting

    Basic Trouble-shooting GENERAL ISSUES FOR TFT PANEL BASED PRODUCTS Note: Applies for a range of various products. This is only meant as a general guide. O PICTURE / LED BEHAVIOUR: If there is no light at all in the LED at the FRONT, check power cables. If the LED in front is green, then check if the brightness is set/adjusted to max brightness.

  • Page 55: Declaration Of Conformity

    Declaration of Conformity We, manufacturer, Hatteland Technology AS, Eikeskogvegen 52, N-5570 Aksdal, Norway declare under our sole responsibility that the JH MMD, JH MMC, JH STD, JH MIL, HM NMD, HM MIL, HM CMD, HT STD, HD MMD, HD MVD, HM MMD, HM XRD, HM RMD, HT MMC, HD MMC, HT/HM (computers) and HN G (Network Switches) product ranges is in conformity with the following standards in accordance with the EMC Directive.

  • Page 56: Return Of Goods Information

    Return Of Goods Information Return of goods: (Applies not to warranty/normal service/repair of products) Hatteland Technology referenced as “manufacturer” in this document. Before returning goods, please contact your system supplier before sending anything directly to manufacturer. When you return products after loan, test, evaluation or products subject for credit, you must ensure that all accessories received from our warehouse are returned.

  • Page 57: General Terms And Conditions

    General Terms and Conditions As of January 2015, Hatteland Technology AS’ “Terms of Sales and Delivery” and “Warranty Terms” have been substituted by the updated ”General terms and conditions for sale of goods and performance of additional services” (the “General Terms and Conditions”). Further, from January 2015 onward, the previous “Terms of Sales and Delivery”...

  • Page 58: Pixel Defect Policy

    Pixel Defect Policy PIXEL DEFECT POLICY Dot-defects (Bright or dark spots on the panel) Due to the effect that dot failures are part of the TFT technology such failure occurrence cannot be prevented basically. Even though dot defects usually occur during production process, new defects can appear within the lifespan of a TFT display. Neither the production at LCD-supplier nor the use of an LCD-Monitor after shipment can be influenced by Hatteland Technology.

  • Page 59: Notes

    Notes General Notes: - The unit is tested according to IEC 60945 4th (EN 60945:2002), 4.4, equipment category b) “protected from the weather (formerly class B)”. - Use of brightness and push buttons may inhibit visibility of information at night. Appendix IND100077-71...
  • Page 60 User Notes Appendix IND100077-24...

  • Page 61: Revision History

    Revision History Rev. Date Notes 03 Nov 2008 First release. 26 Jan 2009 Revised specifications (Type Approval ClassNK) 08 Oct 2009 Revised to current company profile layout. Revised general chapter text (page 8) Revised contents of package chapter (added typenumbers) (page 5) Revised specifications (added type approvals) (page 42) 21 Jan 2010 Fixed typing error ”Display Data Configuration”...
  • Page 62 Hatteland Technology AS | www.hattelandtechnology.com | Enterprise no: NO974533146...
