  • Page 1 LightSYS Plus User Manual...
  • Page 2 Information in this document is subject to change without notice. Corporate and individual names and data used in examples herein belong to their respective owners. Copyright Information RISCO Group 2021. All rights reserved. No part of this document may be reproduced in any form without prior written permission from the publisher. 01/2022...

  • Page 3: Table Of Contents

    DVANCED EATURES FOR YSTEM SERS RISCO C ................... 2 MPOWERED BY THE LOUD Self-Monitoring, Operation and Notification via the RISCO Cloud ........2 iRISCO Smartphone App ......................2 Web User Interface ........................2 ....................... 3 YSTEM APABILITIES ..................5 ONITORING...
  • Page 4 Deleting a Proximity Tag by its Index Number ..............22 Deleting a Proximity Tags by its Tag ..................23 Deleting My Own Proximity Tag ..................23 7: D ................24 EFINING OLLOW ESTINATIONS Examples of Follow-Me Notifications ................24 Creating or Editing Follow Me Destinations ..............25 Special Dialing Characters for Voice Notifications..............
  • Page 5 Installer Information ......................41 System Version ........................41 Serial Number ........................41 Panel ID ..........................41 ......................... 42 YPASSING ONES Viewing Not-Ready Zones ..................... 42 Defining Zone Bypass Status ..................43 Quickly Bypassing/Un-Bypassing Zones on a One-Time Basis ........44 &...
  • Page 6 ................. 68 ANUALLY PERATING TILITY UTPUTS ......... 69 EFINING UTOMATICALLY PERATED S AND RMING PERATIONS Defining a "One-Time" Schedule for Automatic Arming ..........69 Defining Weekly Schedules for Automatic Arming and UOs ......... 70 Configuring the Arm/Disarm Option ..................70 Turning an Arming/Disarming Schedule On or Off ..............
  • Page 7 IEWED NDICATORS Keypad Indicators ......................87 Slim Keypad Indicators ......................87 LightSYS and LightSYS Plus Keypad Indicators ................. 88 Panda Keypad Indicators ......................88 Elegant Keypad Indicators ....................... 89 Remote Control Indicators .................... 89 8-Button Remote Control Indicators ..................89 4-Button Panda Keyfob Indicators ...................

  • Page 8: Lightsys Plus Main Features

    RISCO detectors and accessories – including remote user operation via Smartphone and Web user apps. A flexible hybrid system that is scalable according to your needs, LightSYS Plus empowers you to utilize up to 512 zones and 500 system users.

  • Page 9: Empowered By The Risco Cloud

    Self-Monitoring, Operation and Notification via the RISCO Cloud Powered by the RISCO Cloud, the iRISCO Smartphone app and Web User Interface empower system users with self-monitoring, notification, control, and operation of their systems remotely - anywhere, anytime, with or without a monitoring station. The RISCO Cloud also enables operating RISCO’s Home Automation services.

  • Page 10: System Capabilities

    User codes • 1 code each for installer, sub-installer and Grand Master Event log capacity 2000 Wired keypads Wireless keypads Wireless keyfobs / 256 (1-way, 2-way) including RISCO’s Panic keyfob remote controls Proximity key readers 64 01/2022 Page 3 5IN2933...
  • Page 11 Compliance Statement Hereby, RISCO Group declares that the LightSYS Plus is designed to comply with: • EN50131-1 • EN50131-3 Grade 3, Environmental Class II for Housing RP512B and RP432BP3 • EN50131-3 Grade 2, Environmental Class II for Housing RP432BP •...

  • Page 12: Monitoring Station Partnership

    EN50136. Monitoring Station Partnership For extra security monitoring, LightSYS Plus can be used with up to 2 separate monitoring stations. When a system event such as an alarm takes place, the monitoring station is automatically notified. This helps enable rapid around-the-clock resolution in notifying responding agencies (police, fire, medical, etc.) for resolution of a false alarm, or in resetting...

  • Page 13: Operational Devices & Interfaces For System Users

    Operational Devices & Interfaces for System Users Device/interface Description & model numbers RisControl Touchscreen Keypad: RP432KPT Panda Wired Keypad: RP432KPP2 (with Proximity) RP432KP02 Panda Wireless: RW432KPP Elegant Keypad: RPKEL (Black)/(White) RPKELP (Black with Proximity)/(White with Proximity) LightSYS LCD Keypad: RP432KP RP432KPP (with Proximity) ProSYS LCD Keypad: ProSYS KCL...
  • Page 14 Device/interface Description & model numbers Panda 2-Way KeyFob: RW332KF1 4-Button Rolling-Code Keyfob WL 132KF1 (433 MHz, black)/(868 MHz, black) WL T4RC (433 MHz, grey)/(868 MHz, grey) RWT4RCP (868 MHz, with 2-button Panic feature) 2-Way 8-Button Remote Control: Agility 132KF2 (433 MHz)/(868 MHz) Web User Interface iRISCO app for Smartphones (both iOS and Android) SMS notifications (for mobile phones)

  • Page 15: Important Safety Precautions

    WARNING: Dispose of batteries according to applicable law and regulation. Getting Started This manual describes how to setup and operate your LightSYS Plus system, and contains the following main sections: • Initial Setup Tasks for the Grand Master: The required, initial system setup tasks that are typically performed by the Grand Master –...

  • Page 16: Initial Setup Tasks For The Grand Master

    Step 1: Changing the Default Grand Master Code Step 2: Registering the System to the RISCO Cloud Step 3: Logging into the RISCO Cloud / Web User Interface Step 4: Downloading the iRISCO Smartphone App Step 5: Working with Keypads and User Menus...

  • Page 17: Step 1: Changing The Default Grand Master Code

    Step 2: Registering the System to the RISCO Cloud Registering to the RISCO Cloud is a one-time procedure that allows you to use the iRISCO Smartphone app and Web User Interface. This procedure should be performed by the system installer, after you supply the installer with the required information, such as an e- mail address.

  • Page 18: Viewing The Panel Id At The Keypad

    Step 3: Logging into the RISCO Cloud / Web User Interface You must log into the RISCO Cloud after registration. In addition, the Grand Master and other system users (according to user authority level) can access and use the Web User Interface, which offers basic and advanced remote operation, control, and management operations for the system.

  • Page 19: Step 5: Working With Keypads And User Menus

    Step 5: Working with Keypads and User Menus Keypad Buttons Familiarize yourself with the keypad buttons for Grand Master setup tasks as well as the buttons used for the operational procedures performed by system users. Also see the packaged keypad instructions and the respective procedures in this manual. This describes the main functions of keypad buttons for both Grand Master setup tasks and the operational commands available for all system users.

  • Page 20: User Menus

    Panda Elegant LightSYS LightSYS Slim For Grand Master For User Operations Keypad Keypad Plus Keypad Setup Keypad Keypad TOGGLE: To toggle FULL ARM: For full between options (not (away) arming applicable for Slim) DISARM: For —— disarming the system Buttons Buttons Buttons Buttons...

  • Page 21: Exiting User Menus

    NOTE: If a partition or tamper alarm goes off (it will sound as well as display), to silence it press the Exit button, immediately enter your Grand Master or user code, and then press OK; the alarm type, date and time will display. Press OK again to view the status.

  • Page 22: Table Of User Authority Levels

    Table of User Authority Levels This table lists all user authority levels, and describes their respective permissions. The Grand Master can perform all of the user operations, while system users with the User authority level (the default) can perform most of the common operations. Authority level Description of permissions o Can perform all operations for all partitions o Grand Master code can be changed by the Grand Master or installer...

  • Page 23: Describing User Codes

    Authority level Description of permissions o Typically used for cleaners and home attendants who may need to enter the premises at times when the owner is not present o For one-time arming of one or more partitions o A temporary code, it is automatically and immediately deleted from Maid the system as soon as it is used to arm (the code will then need to be redefined by the Grand Master)

  • Page 24: Creating Or Editing User Codes

    NOTES: • At the time of installation, the installer designates the codes to be either 4 or 6 digits in length. If defined as 6 digits the length apply for everybody – all users and installer/sub-installer, however if defined as 4 digits then the Grand Master, installer, and sub-installer must have 4-digit codes, while the other system users can codes of various lengths, from 1—4 digits.

  • Page 25: Creating Or Editing The Duress-Disarming Code

    Creating or Editing the Duress-Disarming Code A Duress-Disarming code is a common code to be used if needed by all system users – for the purpose of disarming the system in an emergency situation only (typically when a user is forced to disarm against their will). When activated, the monitoring station is notified, but at the premises there are no visual or audible indications (no alarms will sound).

  • Page 26: Creating Or Editing Labels

    Creating or Editing Labels ➢ To create or edit a label: • Using the scroll buttons to move the cursor, at each cursor position enter (or over-write) a character/symbol by pressing the appropriate button (perhaps repeatedly) to cycle through the button's various options, as listed in the table below. Note that after a few seconds the cursor will automatically advance to the next position.

  • Page 27: Describing Proximity Tags

    Describing Proximity Tags Proximity-enabled RISCO keypads allow using Proximity tags to operate the system (per user authority level – see Describing User Authority Levels, page 14). By holding a personal Proximity tag close to the Proximity sensor of any Proximity-supported keypad, it functions the same as entering a personal user code.

  • Page 28: Defining And Enrolling Proximity Tags

    Defining and Enrolling Proximity Tags ➢ To define and enroll Proximity tags: Enter your Grand Master code, and then press OK. Scroll to the Codes/Tags menu, and then press OK. At Define press OK. Scroll to the user index number (001—499) for which you will define a Proximity tag – or scroll to Grand Master to define your Proximity tag, and then press OK.

  • Page 29: Deleting Proximity Tags

    Deleting Proximity Tags Proximity tags can be deleted by the Grand Master, and also by the system user (his/her tag only). The Grand Master can delete Proximity tags (including the Grand Master's) by the following methods: • By index number—if the user's index number is known •...

  • Page 30: Deleting A Proximity Tags By Its Tag

    Deleting a Proximity Tags by its Tag ➢ To delete a Proximity tag by its tag: Enter your Grand Master code, and then press OK. Scroll to the Codes/Tags menu, and then press OK. Scroll to Delete By Tag, and then press OK. Within 10 seconds, hold the tag about 2 cm (1 inch) directly above the keypad's built-in Proximity sensor;...

  • Page 31: Step 7: Defining Follow-Me Destinations

    Step 7: Defining Follow-Me Destinations The Grand Master can define up to 64 Follow-Me (FM) destinations ("user-recipients") that will receive notification of system events such as alarm activations: • If system is Cloud-connected (for example if using a Smartphone with the Cloud- connected iRISCO app): a FM user can receive notifications by E-mail, push- notification, SMS-notification or voice, simultaneously.

  • Page 32: Creating Or Editing Follow Me Destinations

    Creating or Editing Follow Me Destinations ➢ To create or edit a FM destination: Enter your Grand Master code, and then press OK. Scroll to the Follow Me menu, and then press OK. At Define press OK Scroll to an available FM index number (01—64) -- or scroll to an existing FM index number that you want to edit, and then press OK.

  • Page 33: Deleting Follow Me Destinations

    Deleting Follow Me Destinations You can delete existing FM destinations (telephone numbers, e-mail addresses) and labels of FM recipients who are no longer authorized to receive FM notification. NOTE: During system operation, in the event of a false alarm for example, the Grand Master can terminate Follow-Me notification transmissions to the recipients (see Terminating Follow- Me Notifications, page 79).

  • Page 34: Step 8: Defining Keyfobs For Output (Gate) Control

    Step 8: Defining Keyfobs for Output (Gate) Control Systems equipped with a dedicated wireless expander set to standalone mode can support up to 200 "standalone keyfobs," each of which can be used to activate up to two outputs for gate / parking control. For this purpose, the wireless expander can be used in either "bus mode"...

  • Page 35: Changing The Keyfob Buttons For Output Control

    Changing the Keyfob Buttons for Output Control [For the 4-button keyfob]: By default the small and large circular/oval buttons are used for controlling the outputs. After registering, either the Grand Master or installer can change the functionality of the keyfob buttons so that the buttons with printed "locked" and "unlocked" symbols will be used for output control instead.

  • Page 36: Deleting Registrations For All Output Control Keyfobs

    Deleting Registrations for all Output Control Keyfobs The Grand Master can delete the registrations for all output control keyfobs/remote controls at the same time. ➢ To delete registrations for all keyfobs/remote controls: At the keypad, enter your Grand Master code, and then press OK. Scroll to Stand Alone KF (keyfob), and then and press OK.

  • Page 37: Step 11: Training System Users

    Scroll to Wi-Fi Scan, and then press OK; from the available networks that appear, scroll to your Router’s Wi-Fi network and then select the desired network. Press [enter]. Step 11: Training System Users Typically performed by the Grand Master, all system users must be educated and trained in the operational and security aspects of the system, including, for example: •...

  • Page 38: Operating The System

    Operating the System This chapter contains all the operational procedures available for system users. Modes of Operation The system can be operated by authorized users either remotely or locally (at the premises). Remote Operational Modes • Smartphones via the iRISCO app (see the app for instructions) •...

  • Page 39: Operations Menu

    Repeat the event message Return to the Acknowledgement menu Operations Menu For this: Press this: 1 ➢ 1 Arm all partitions 1 ➢ 9 ➢ partition number Arm by partition (arm selected partition) 2 ➢ 2 Disarm all partition 2 ➢ 9 ➢ partition number Disarm by partition (disarm selected partition) 3 ➢...

  • Page 40: Operating Remotely By Sms

    Operating Remotely by SMS You can operate the system remotely by sending SMS commands. NOTES: • To utilize SMS a GSM module must be installed – ask your installer. • Commands entered are not case sensitive (upper and/or lower case are ok). •...

  • Page 41: Operating The Listen-In & Speak Unit

    Operating the Listen-In & Speak Unit The Listen-In & Speak Unit is an audio accessory that provides 2-way “listen-in" and/or "talk” communication to and from the premises (such as between a system user at the site and the monitoring station). The Listen-In & Speak Unit is also used to broadcast status in the form of voice announcements (for system events such as alarms, and as confirmation for user-initiated commands at the time of arming/disarming only –...

  • Page 42: Using The "Blank" Keypad Display

    Using the "Blank" Keypad Display [For wired keypad models with LCD displays]: If installer-defined, two minutes after the last keypad operation the keypad display will appear blank, other than the text "ENTER CODE." This feature prevents the system status from displaying for unintended viewers – for example, from keypads that are located outside the premises.
  • Page 43 • Keypad beeps (arming/disarming, entry/exit countdown) • Single siren "squawk" for arming confirmation only LightSYS, • Voice announcements broadcast from the Listen-In & Speak unit LightSYS Plus, Panda and (for system events such as alarms, and as confirmation for user- Elegant keypads initiated commands at the time of arming/disarming only) •...

  • Page 44: Obtaining System Status - Requested From Remote Controls

    Obtaining System Status – Requested from Remote Controls When requested from an 8-button remote control, you can get system status via the remote control's LED indicators, and via "beeps" and "squawks" from the remote control and siren respectively (see "Beep" and "Squawk" Sound Indicators, page 85). Remote Control Procedure: Status indications received: Sound status indication:...

  • Page 45: Obtaining System Information - Requested From, And Viewed At Keypads

    Keypad Procedure: Status indications received: Partition status (R=ready/NR=not ready). Panda Press scroll keys Elegant Press scroll keys Partition status (R=ready/NR=not ready). • Quick mode: Press for 2 • LED indications from the keypad (see seconds Slim Keypad Indicators, page 87) •...

  • Page 46: Viewing Alarm Memory

    ➢ To view the event log: At the keypad, enter your Grand Master code, and then press OK. Scroll to Event Log, and then press OK. Scroll through the various events to view their description and time/date of occurrence. NOTE: Use the Partial Arm (toggle) button (see table in Keypad Buttons, page 12) to skip 100 events, either forwards or backwards.

  • Page 47: Viewing Partition Status

    Viewing Partition Status View the status for individual partition(s) or all partitions to which the keypad is assigned (according to your user authority level). ➢ To view partition status for the keypad-assigned partition: At the keypad, press the scroll button to view all status information for the first block of partitions (partitions 1—10), such as R (ready to arm) or NR (not ready to arm).

  • Page 48: Installer Information

    Installer Information ➢ To view installer/technician information: At the keypad, enter your Grand Master or user code, and then press OK. Scroll to View and then press OK. Scroll to Service Information and then press OK. Scroll to Installer and then press OK, installer-input information displays. System Version ➢...

  • Page 49: Bypassing Zones

    Bypassing Zones If installer-enabled, you can arm a partition – even if a zone within that partition is not secured – by manually bypassing that zone. If not bypassed, when a zone is not secured, or "open" (OP) for whatever reason, by default it will be in a "not-ready"...

  • Page 50: Defining Zone Bypass Status

    Defining Zone Bypass Status If installer-configured, you can perform either the following procedure to bypass zones, or the quick procedure for one-time-only bypassing (see Quickly Bypassing/Un-Bypassing Zones on a One-Time Basis, page 44). ➢ To define a zone's bypass status: At the keypad, enter your Grand Master or user code, and then press OK.

  • Page 51: Quickly Bypassing/Un-Bypassing Zones On A One-Time Basis

    Bypass Option Procedure: a. At the One-Time-Only option, press OK. b. Scroll through the zones to one for which you want to One-Time-Only change its bypass status. c. Toggle to either Y (to bypass) or N (to un-bypass), and then press OK. a.

  • Page 52: Arming & Disarming The System

    System arming protects the premises by triggering alarms and sending notifications upon detection from any installed detector. System users can arm/disarm the system according to their user authority level. Arming/Disarming Modes LightSYS Plus offers the following modes of arming/disarming the system: Arming Modes ✓ Full ("Away") arming ✓...

  • Page 53: Arming Procedures

    • Check that all zones are ready to be armed (no open zones) –view the READY indicator on the keypad (see Keypad Indicators, page 87) • Check for system troubles. It is good practice to scroll through and view all troubles, whether or not your system is configured to require viewing them before arming.
  • Page 54 Device Full-Arming procedure: ❖ Quick Arm mode: Press ❖ High Security mode: Enter code ➢ press ❖ Proximity mode: Place Proximity tag ❖ Quick Arm mode: Press ❖ High Security mode: Enter code ➢ press ❖ Proximity mode: Place Proximity tag ❖...

  • Page 55: Partial ("Stay" Or "Home") Arming

    Leave the premises before the end of the exit delay period. During the exit delay period, you can observe the following indicators at the keypad: • The keypad beeps slowly and repeatedly, followed by faster beeps at end of exit delay time period •...
  • Page 56 Device Partial-Arming procedure: ❖ Quick Arm mode: Press ❖ High Security mode: Enter code ➢ press ❖ Proximity mode: Place Proximity tag ❖ Quick Arm mode: Press ❖ High Security mode: Enter code ➢press ❖ Proximity mode: Place Proximity tag ❖...

  • Page 57: Partition Arming

    NOTE: You can press the current keypad's Exit button during the exit delay time period to silence the beeps (other keypads in the system will still beep). At the end of the exit delay time period, the Part-Arm and Full Arm icons both appear without blinking, and AT HOME ARMED displays.

  • Page 58: Arming All Partitions

    Arming All Partitions Arm all partitions at the same time, as either fully-armed or partially-armed. ➢ To arm all partitions: Verify that the areas of the premises to be armed are vacated, and that the system is ready to be armed (view the READY indicator). If not ready to arm, secure (or bypass) any open zones, see Bypassing Zones (Arming with Manually-Bypassed Zones), page 56 and also Forced Arming (Arming with Automatically- Bypassed Zones), page 55.

  • Page 59: Arming An Individual Partition

    For this: Do this to arm ALL partitions: ❖ Quick mode: Press ❖ Quick mode: Press ❖ High security mode: Press ➢ enter code NOTE: You can select only a single partition 1, 2 or 3, even if you have access to more partitions.
  • Page 60 For this: Do this to arm an INDIVIDUAL partition: NOTE: The number of partitions (32 maximum) that can be armed using a Proximity tag is installer-configured per user. ❖ Quick mode: Press partition number (1—3) ➢ press (full-arm) or (partial-arm). ❖...

  • Page 61: Group Arming

    Group Arming In each partition the zones are assignable to up to 4 groups, enabling 4 levels of partial- arming in each partition. Group arming can be performed at the following keypads: • LightSYS LCD keypad • ProSYS LCD Keypad •...

  • Page 62: Automatic Arming And Disarming

    Automatic Arming and Disarming You can have the system arm and disarm automatically for re-occurring weekly schedules, one-time schedules, and vacation schedules (see Defining Automatically-Operated UOs and Arming Operations, page 69). Arming with System Troubles If installer-configured, you can arm the system while overriding all current troubles, provided you first view and confirm all the troubles.

  • Page 63: Bypassing Zones (Arming With Manually-Bypassed Zones)

    Bypassing Zones (Arming with Manually-Bypassed Zones) See Defining Zone Bypass Status, page 43 and Quickly Bypassing/Un-Bypassing Zones on a One- Time Basis, page 44. Keyswitch Arming If the system is equipped with a keyswitch, perform arm and disarm operations by "toggling"...

  • Page 64: Disarming All Partitions

    feature provides extra security without the need for the user code, although a unique PIN code may be used with an 8-button remote control. Disarming All Partitions You can disarm all fully-armed or partly-armed partitions at the same time (per your user authority level –...

  • Page 65: Disarming An Individual Partition

    Disarming an Individual Partition You can disarm 1 individual partition at a time (as fully-armed or partly-armed). ➢ To disarm an individual partition: If outside the premises, open a designated "entry" door. The keypad beeps, indicating that the entry delay time period has started. Before the end of the entry delay time period, perform the following procedure: NOTES: •...

  • Page 66: Duress Disarming

    ❖ Disarm partition: Enter the 2-digit partition number (example 03) ➢Press disarm button ➢ enter code ❖ Proximity disarm partition: Press ➢ place tag ❖ Disarm a partition: Press button 1,2, or 3 for partition number ➢ press ❖ Disarm a partition with PIN: Press button 1,2, or 3 for partition number ➢...

  • Page 67: Returning The System To Normal Operation After Alarm Activation

    CAUTION: During or after any type of alarm activation (manual or automatic), before approaching or entering the premises, first be certain that there is no danger present. You may need to contact responding agencies (police, fire, etc.) in order to confirm whether it is safe to return to the premises.

  • Page 68: Resetting The System With Installer/Technician Intervention

    Resetting the System with Installer/Technician Intervention The following methods of resetting the system require installer/technician intervention (note that a system user must contact the installer/technician after each alarm activation): • Anti-Code reset (also known as "Technician reset") • Configuration Software reset Anti-Code Reset (Technician Reset) If installer-enabled, upon alarm activation the system will not be ready to arm until the technician/installer provides you with a code that allows you to reset the system.

  • Page 69: Disabling Smoke/Heat Detectors After Alarm Activation

    At Activities press OK. Scroll to Config SW, and then press OK; either CS CONNECT or ENABLE CS displays: • [If ENABLE CS displays]: The system is not currently configured to allow the technician/installer to access the CS. For you to authorize the technician/installer a one-time access to the CS, press OK, scroll to CS Connect, and then proceed to step •...

  • Page 70: Restoring The System Upon Power Supply Overload

    Restoring the System upon Power Supply Overload [For the 3-amp Power Supply Module only]: In the event of an overload of the system's power supply, you can attempt to restore the system by yourself. IMPORTANT: If the following procedure does not resolve the situation, it will require the intervention of a technician/installer.

  • Page 71: Activating Emergency Alarms

    Activating Emergency Alarms All RISCO keypads are equipped with specific buttons to use for quick activation of emergency alarms: • Panic ("Police") alarm • Fire alarm • Auxiliary / emergency alarm • Duress-Disarming alarm NOTE: RISCO 4-button keyfobs and 8-button remote controls can also be used to also activate Panic alarms –...

  • Page 72: Activating A Panic ("Police") Alarm

    • RISCO has designed the LightSYS Plus IP and GSM communication modules to be in compliance with the information security and substitution security requirements of EN50136. Monitoring Station Partnership , page 4. CAUTION: During or after any type of alarm activation (manual or automatic), before approaching or entering the premises, first be certain that there is no danger present.

  • Page 73: Activating A Duress-Disarming Alarm

    Panda keypad Enter duress code ➢ press Enter duress code ➢ press Elegant keypad Slim ➢ enter duress code Press LightSYS LCD keypad Enter duress code ➢ press LightSYS Plus LCD keypad Enter duress code ➢ press 01/2022 Page 66 5IN2933...

  • Page 74: Describing Utility Outputs

    Describing Utility Outputs The system supports up to 196 programmable utility outputs (UOs) in the system. UOs typically automatically activate external devices and appliances such as lighting and air conditioning, or system arming/disarming – in response to installer-defined activation criteria, such as events and other triggers related to alarms, zones, partitions, system events, user actions, and scheduled operations.

  • Page 75: Manually Operating Utility Outputs

    Manually Operating Utility Outputs NOTES: • All UOs are installer-configured • Proximity and keyfobs/remote controls can be used if installer-configured Device Manual UO activation procedure: ❖ Press Exit button ➢ enter code and press OK ➢ scroll to Activities menu and press OK ➢...

  • Page 76: Defining Automatically-Operated Uos And Arming Operations

    Defining Automatically-Operated UOs and Arming Operations The Grand Master can configure the following automated system operations according to schedules and other criteria that the Grand Master defines: • One-time system arming/disarming: (For arming within the next 24 hours • Re-occurring weekly schedules: Up to 64, for arming/disarming the system and/or activating/deactivating up to 4 UOs •...

  • Page 77: Defining Weekly Schedules For Automatic Arming And Uos

    Defining Weekly Schedules for Automatic Arming and UOs You can define up to 64 re-occurring weekly schedules for automatic UO activation/deactivation and automatic system arming/disarming. Each schedule can have up to 2 separate start and stop time intervals per day. For an automatic arming/disarming, you can also set a "user limitation"...

  • Page 78: Selecting An Arming Mode For The Arming/Disarming Schedule

    Configuring the Arm/Disarm Option Selecting an Arming Mode for the Arming/Disarming Schedule Scroll to 3)ARMING MODE, and then press OK. Scroll to an arming mode: ARM (full arming), STAY (partial arming), or GROUP (group arming), and then press OK. [For Group mode]: Select the group letter(s) to automatically arm (each selected group displays as Y).

  • Page 79: Configuring The Uo Option

    Configuring the UO Option Turning a UO Schedule On or Off Scroll to 1)ON/OFF, and then press OK. Toggle to ON or OFF to turn the UO schedule on or off respectively, and then press Defining the Utility Output(s) for the Schedule Scroll to 2)UTIL OUTPUTS, and then press OK.

  • Page 80: Configuring The User Limitation Option

    Configuring the User Limitation Option You can apply a "user limitation" mechanism to prevent selected users from disarming the system during 1 or 2 specified time intervals per day. By default users do not have a user limitation applied. Applying/Removing a User Limitation Scroll to 3)USER LIMIT, and then press OK.

  • Page 81: Setting Dates/Times And Activating A Vacation Schedule

    Setting Dates/Times and Activating a Vacation Schedule This procedure is for both UO vacation schedules and arming vacation schedules. ➢ To set the date/time and activate a UO or arming vacation schedule: [For a UO vacation schedule only]: First perform the following procedure: Defining a UO Schedule as a "Vacation"...

  • Page 82: Using Macros

    Using Macros System users can activate macros, which are custom commands for controlling and operating the system. Up to four macros (A, B, C, D) can be recorded (programmed) locally using any RISCO keypad except Slim models. Recording Macros ➢...

  • Page 83: Performing Maintenance Tasks

    Performing Maintenance Tasks Defining the Time and Date Manually For systems connected to the Cloud, the time and date are updated automatically, however, regardless whether your system is Cloud-connected or not, the time and date can be manually set as needed. ➢...

  • Page 84: Performing Sim Card Maintenance

    Performing SIM Card Maintenance Checking the SIM Credit Level Receive information on the available credit level of the prepaid SIM card via SMS or voice (installer-configured). ➢ To check the SIM credit level: At the keypad, enter your Grand Master code, and then press OK. At Activities press OK.

  • Page 85: Enabling / Disabling The Current Keypad's Chime

    Enabling / Disabling the Current Keypad's Chime ➢ To enable/disable the internal chime of the currently-used keypad: At the keypad, enter your Grand Master or user code, and then press OK. At Activities press OK. Scroll to Keypad Sound, and then press OK. At Chime press OK.

  • Page 86: Terminating Follow-Me Notifications

    Terminating Follow-Me Notifications You can terminate the transmission of FM notifications to the recipients – for example, for a false alarm, where you don’t want the recipients to get notified. ➢ To terminate Follow Me notifications: At the keypad, enter your Grand Master code, and then press OK. Scroll to Follow Me and then press OK.

  • Page 87: Performing A Walk Test

    Performing a Walk Test A walk test checks the detection ability of all detectors (PIR and Magnetic Contact detectors) in all zones, to ensure correct operation. Test results are displayed on the keypad. A walk test can be a relatively a quick procedure, depending on the scope of the installation and premises, however if needed, up to 60 minutes is allotted for the test.

  • Page 88: Testing Follow-Me Destinations

    Testing Follow-Me Destinations This tests if notifications sent to Follow-Me destinations (recipients) are received. It is highly recommended to test every FM destination. ➢ To test a FM destination: At the keypad, enter your Grand Master code, and then press OK. Scroll to Follow Me and then press OK.

  • Page 89: Performing A Strobe Test

    Performing a Strobe Test This tests a siren's strobe light. ➢ To perform a strobe test: At the keypad, enter your Grand Master code, and then press OK. Scroll to Maintenance and then press OK. Scroll to Strobe Test and then select the strobe to test. Press OK;...

  • Page 90: Appendix A: Scheduling Chart For Automatic Uo & Arming Operations

    Appendix A: Scheduling Chart for Automatic UO & Arming Operations You can use this chart (optional) to list the details of an automatic UO or arming schedule – it can be used for reoccurring weekly schedules, or weekly vacation schedules. Schedule name / number: ______________ Reoccurring weekly schedule: ...

  • Page 91: Appendix B: User Menu Maps

    Appendix B: User Menu Maps The following user menus and respective options will display according to the system installation, as well as the authority level of the user. User menu Menu options and respective settings Bypass ➢ Zones ➢ Time Only, Bypass Reset, Bypass Recall, Permanent Bypass o Output control ➢...

  • Page 92: Appendix C: System Indicators

    Appendix C: System Indicators Various audible (sound) indicators and visual (viewed) indicators are available, depending on the system configuration. Sound Indicators Sound indications are available for system status, operations and events: • Beeps and squawks • Voice announcements Sound indicators are requested / initiated from keypads and remote controls, and the sounds can be heard from the keypads, remote controls and external sirens.
  • Page 93 Requested / initiated from: Slim keypad Each key press 1 short beep No sound Arming / disarming 1 long beep Armed = 1 squawk Disarmed = 2 squawks (or 4 if disarmed after an alarm) Requested / initiated from: LightSYS keypad, Elegant, Panda keypad Operation / event Sounds from keypad Sounds from siren...

  • Page 94: Voice Announcements

    Voice Announcements Requested/initiated from keypads, Voice Announcements enable users to hear LightSYS Plus-supplied voice clips (short voice recordings) that are broadcast through Listen-In & Speak Units – for announcing system events such as alarms, and as confirmation for user- initiated commands at the time of arming/disarming only. NOTE: To utilize voice announcements, specific modules need to be installed –ask your installer.

  • Page 95: Lightsys And Lightsys Plus Keypad Indicators

    LightSYS and LightSYS Plus Keypad Indicators POWER STAY/BYPASS On: Power OK (Also red LED on LightSYS On: System is in partially- keypad) Off: No power armed or zone-bypass mode On: System armed – either Rapid flash System fully or partially.

  • Page 96: Elegant Keypad Indicators

    Elegant Keypad Indicators POWER READY On: Power OK. On: Ready to arm On: System in fully armed mode Off: No power Off: Not ready to arm Off: System disarmed Rapid flash: System trouble. Slow flash: Ready to Rapid flash: Alarm arm with open Slow flash: System is Slow flash: System in Exit Delay...
  • Page 97 UKCA and CE RED Compliance Statement Hereby, RISCO Group declares that this equipment is in compliance with the essential requirements of the UKCA Radio Equipment Regulations 2017 and CE Directive 2014/53/EU. For the UKCA and CE Declaration of Conformity please refer to our website www.riscogroup.com...
  • Page 98 RISCO, for a period of (i) 24 months from the date of connection to the RISCO Cloud (for cloud connected products) or (ii) 24 months from production (for other products which are non-cloud connected), as the case may be (each, the “Product Warranty...
  • Page 99 Consequently RISCO shall have no liability for any personal injury, property damage or loss based on a claim that the product fails to give warning.
  • Page 100 Contacting RISCO Group RISCO Group is committed to customer service and product support. You can contact us through our website (www.riscogroup.com) or at the following RISCO branches: Belgium (Benelux) Israel United Kingdom Tel: +32-2522-7622 Tel: +972-3-963-7777 Tel: +44-(0)-161-655-5500 support-be@riscogroup.com support@riscogroup.com support-uk@riscogroup.com...

Table of Contents
