FITTING AND OPERATING
INSTRUCTIONS FOR FARHO HEATERS
Please read these instructions carefully and keep them for future queries.
It is recommended that heaters are being installed and accredited by a qualified
electrician following Low Voltage Regulations. Any claim presented will be deemed
as invalid if the prevailing regulations have not been met.
Thank you for purchasing a Farho heater.
Farho, is a unique heating system designed, developed and produced by Farho based on a
heating conducting fluid with a very high heat inertia. Farho heaters put together a great
number of the advantages of existing heating systems such as the use of injected aluminum
and electricity as a source of energy easy to use and control and Farhoil, a patented fluid
elaborated just for Farho. Farho heaters are available in different types giving therefore
solutions for everyone.
Farho heaters have been designed and are manufactured in accordance with appliance
requirements pursuant to EN 60950, EN 300 220, EN 301 489, EN 60335-1 y EN 60335-
2-3 standards.
Correctly sized, the heater will provide sufficient heat to keep the space in which it has
been fitted warm in a very efficient way.
IMPORTANT: Always disconnect the electricity supply from the power point before any
maintenance operations.
DO NOT COVER heater´s surface. Inflammable items must not be placed on the heaters.
Heaters should not be used to dry out clothes, towels... These items as well as other such
as spray cans and volatile substances or objects must be kept away at least 2cm from
the radiator.
WARNING
GENERAL INFORMATION
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Farho XP-3
Summary of Contents for Farho XP-3
-
Page 1: General Information
GENERAL INFORMATION Thank you for purchasing a Farho heater. Farho, is a unique heating system designed, developed and produced by Farho based on a heating conducting fluid with a very high heat inertia. Farho heaters put together a great number of the advantages of existing heating systems such as the use of injected aluminum and electricity as a source of energy easy to use and control and Farhoil, a patented fluid elaborated just for Farho. -
Page 2: Table Of Contents
When we want to get rid of the heater, we will have to take it to a recycling centre, since it contains oil that can be harmful to the environment. You can consult all our manuals on our website www.farho.com... -
Page 3: Alejandria Model- An, Eco R Ultra Y Lpr
ECO GREEN MODEL- ECG, ECG ULTRA The EG model is the latest product in Farho range. This heater combines high technology performance with easy use. Farho EG models can be programmed in up to six independent operating periods for each day of the week and it can also be controlled from the front panel. - Page 4 To raise or lower the room temperature simply press buttons until the temperature indicator displays the desired temperature level. The Farho heater will automatically adjust the heat emission efficiently until reaching the temperature level set. HOW TO KNOW IF THE HEATER IS CONSUMING OR NOT: If the heater is consuming, the pre-set temperature indicator on the display will flicker.
- Page 5 TO DEACTIVATE PROGRAMS: 1. Press the key. 2. The “ “ indicator will position itself in front of “Programs”. Press the key. 3. The “ “ indicator will position itself in front of “ Active”. Press the key. 4. The text “Prog: On” will be displayed. Press to change the text to “Prog: Off”...
- Page 6 11. Press to set the desired ending hour for the first program slot, and then press 12. Press to set the desired ending minute for the first program slot, and then press 13. Press to set the desired temperature for the first programming block, and then press 14.
- Page 7 5. Press the key. 6. The text “Offset: 0ºC” will be displayed. Press keys to display the offset you wish to apply. (Note: this offset can be positive or negative, and is added to the temperature value obtained by the probe. If you select +5ºC, a probe reading of 15ºC will be displayed as 20ºC, conversely, if you select 5ºC, a probe reading of 15ºC will be displayed as 10ºC).
-
Page 8: Modelos Xana Plus- Xp, Xp-Lst, Lpd
XANA PLUS, XP-LST, XP ULTRA, LPD, Eco-D Ultra The XP model is the most innovative product at Farho. This heater combines high technology performance with easy use. Farho. XP models can be programmed in up to six independent operating periods for each at day of the week and it can also be controlled from anywhere with its automation model. - Page 9 CHANGE TEMPERATURE: To raise or lower the room temperature simply press buttons “+” o “-“ until the temperature indicator displays the desired heat level. The Farho heater will automatically adjust the heat emission efficiently until reaching the temperature level set.
- Page 10 3. The indicator “ “ will be in front of “Activate”. Press the key. The programmes have now been activated. (Note: If on reaching this step the “ “ indicator is positioned in front of the word “Deactivate” instead of “Activate”, this means that programmes had already been activated).
- Page 11 CUSTOMISE PROGRAMMES: This model enables you to customise, in a centralised fashion, operating programmes of radiators so that these meet your heating needs. You can to customise your programmes so these can be adjusted to your heating requirements. Press the key.
-
Page 12: Why Is The Heater Not Giving Off Heat
NOTE: If you reset the XP heater, all of the customised programmes that you may have stored in the memory will be deleted. If you have a Central Unit Farho or a MI-Farho, if you reset the heater you must also re-install the automation system. -
Page 13: Technical Information
770X350X950 12,7 930X350X950 15,5 1090X350X950 18,7 ULTRA POWER DIMENSIONS WEIGHT MODELS width x depth x height 450x58x980 10,3 1.000 610x58x980 14,4 1.330 770x58x980 15,5 1.650 930x58x980 22,7 2.000 1090x58x980 26,8 You can consult all our manuals on our website www.farho.com... -
Page 14: Fitter's Instructions
100% yield above 90% yield 85% yield FITTING THE RADIATOR FIG 1 FITTING: The Farho heater will be mechanically secured to the wall by using the brackets which have been specially designed for this purpose and that are included with the heater. -
Page 15: Guarantee Terms And Conditions
During the next 18 months, Farho will cover any replacement without any cost for the client including carrier and labor costs. - Page 16 VERY IMPORTANT: If you wish to report any incident please consult factory by calling Have a look at the manuals in our web THERMAL RADIATOR FARHO DISTRIBUTOR: DATE OF PURCHASE: INSTALLER: NAME: ADDRESS: EMAIL: TELEPHONE: INSTALLER: NAME: ADDRESS: STARTUP DATE:...
