- Page 1 WASSP WSP-038 IMU INSTALLATION MANUAL...
- Page 2 WSP-038 IMU INSTALLATION MANUAL WSP-038 IMU INSTALLATION MANUAL WASSP WSP-038 IMU General Notices WASSP Ltd. reserves the right to change the contents of this manual and any system specifications without notice. INSTALLATION MANUAL Contact WASSP Ltd. regarding copying or reproducing this manual.
-
Page 3: Table Of Contents
4.2. WSP-038 Connection 4.3. DRX Configuration 4.3.1. Configuring for WSP-038 with Furuno SC 4.3.2. Configuring for WSP-038 with WASSP V123 5 Appendix APPENDIX Appendix A - Interconnections Appendix A.1 DRX RS422-A To Satellite Compass Appendix A.2 DRX RS422-B To WSP-038 Appendix A.3 WSP-038 Configuration... - Page 4 1 INTERCONNECTION DIAGRAMS 2 COMPONENTS 2.1. WSP-038 IMU RS422 Down @ 38400 P/N WSP-002-120 - HDT - RMC Furuno SC Preconfigured WASSP IMU with direct connection to DRX. - ZDA IF-NMEASC #8 IF-NMEASC RS422-A WSP-400-259 RS422-B WSP-002-120 RS422A Up @ 38400...
-
Page 5: Wsp-038 Mounting
WSP-038 IMU INSTALLATION MANUAL WSP-038 IMU INSTALLATION MANUAL 3 WSP-038 MOUNTING 4 WASSP CONNECTION AND CONFIGURATION The WSP-038 should be installed taking the following into consideration: Refer to “1 Interconnection diagrams” on page 6 for system configuration. » Accurate measurements need to be taken from the WSP-038, reference point, transducer and the Satellite compass. -
Page 6: Wassp V123 Configuration
4.1.4. WASSP V123 Configuration interconnect. WSP-038 comes preconfigured and does not require any install specific configuration. WASSP V123 will be supplied preconfigured from WASSP and should be mounted Fore/ Aft for true heading. See “Appendix A.1 DRX RS422-A To Satellite Compass” on page WSP-038 connectivity: for Satellite Compass Interconnect. -
Page 7: Drx Configuration
Refer to the DRX Installation Manual for full details. under the DATA SETUP tab, following the instructions in the DRX Installation Manual. wassp.com wassp.com Page 12 of 24 Doc: WSP-038 IMU INSTALLATION MANUAL Doc: WSP-038 IMU INSTALLATION MANUAL Page 13 of 24 Version: 1.4 December 2019... -
Page 8: Configuring For Wsp-038 With Wassp V123
WSP-038 IMU INSTALLATION MANUAL WSP-038 IMU INSTALLATION MANUAL 5 APPENDIX 4.3.2. Configuring for WSP-038 with WASSP V123 With the system full connected with all sensors powered on open the DRX SETUP APPENDIX A - INTERCONNECTIONS WEBPAGES. Select CONFIGURATION and open the PRESETS tab. -
Page 9: Appendix A.2 Drx Rs422-B To Wsp-038
When referring to colour code of wires, the first colour is the primary colour of the cable and the second is the stripe. Eg. Grey/White is a Grey wire with a white stripe and White/ Grey is a white wire with a Grey stripe. wassp.com wassp.com Page 16 of 24... -
Page 10: Appendix A.4 Lever Arm Configuration
SERIAL PROTOCOL SERIAL INPUT should coordinate. be checked to confirm data. Press the Contact WASSP Support or your local dealer for support or WSP-038 diagnosing issues. button to send the configuration settings to the APPENDIX A.4 LEVER ARM CONFIGURATION unit. - Page 11 Cabling - Standard** *External Inputs - Velocity; RMC, RMA, VTG, VBV, VHW - Heading; HDT, HDG **Optional 20m Extension cables available wassp.com wassp.com Page 20 of 24 Doc: WSP-038 IMU INSTALLATION MANUAL Doc: WSP-038 IMU INSTALLATION MANUAL Page 21 of 24 Version: 1.4 December 2019...
- Page 12 WSP-038 IMU INSTALLATION MANUAL WSP-038 IMU INSTALLATION MANUAL NOTES NOTES wassp.com wassp.com Page 22 of 24 Doc: WSP-038 IMU INSTALLATION MANUAL Doc: WSP-038 IMU INSTALLATION MANUAL Page 23 of 24 Version: 1.4 December 2019 Version: 1.4 December 2019...
