  • Page 1 ME910X1 – mPCIe HW Design Guide 1VV0301642 Rev. 2 – 2022-01-14 Telit Technical Documentation...

  • Page 2: Applicability Table

    ME910C1 mPCIe HW Design Guide APPLICABILITY TABLE PRODUCTS ME910C1-WW ME910G1-WW 1VV0301642 Rev. 2 Page 2 of 56 2022-01-14 Not Subject to NDA...

  • Page 3: Table Of Contents

    ME910C1 mPCIe HW Design Guide CONTENTS APPLICABILITY TABLE CONTENTS INTRODUCTION Scope Audience Contact Information, Support Symbol Conventions Related Documents GENERAL PRODUCT DESCRIPTION Overview Product Variants and Frequency Bands Target Market Main Features TX Output Power RX Sensitivity Mechanical Specifications 2.7.1. Dimensions 2.7.2.
  • Page 4 ME910C1 mPCIe HW Design Guide Recommended Operating Conditions DIGITAL SECTION Logic Levels Power On Unconditional Restart Power OFF Procedure Control Signals 6.5.1. W_DISABLE_N and PERST_N 6.5.2. LED_WWAN_N Hardware Interfaces 6.6.1. USB Port 6.6.2. Serial Port SIM Interface RF SECTION Bands Variants TX and RX Characteristics Antenna Requirements 7.3.1.
  • Page 5 ME910C1 mPCIe HW Design Guide Tray Drawing Moisture Sensitivity CONFORMITY ASSESSMENT ISSUES Declaration of Conformity REFERENCE TABLE OF RF BANDS CHARACTERISTICS PRODUCT AND SAFETY INFORMATION Copyrights and Other Notices 14.1.1. Copyrights 14.1.2. Computer Software Copyrights Usage and Disclosure Restrictions 14.2.1. License Agreements 14.2.2.

  • Page 6: Introduction

    This document provides the description of some hardware solutions useful to develop a product with the Telit ME910X1 Mini PCIe Adapter (mPCIe). Audience This document is intended for system integrators that are using the Telit ME910X1 Mini PCIe Adapter in their products. Contact Information, Support For technical support and general questions please e-mail: TS-EMEA@telit.com...

  • Page 7: Symbol Conventions

    ME910C1 mPCIe HW Design Guide Symbol Conventions Danger: This information MUST be followed or catastrophic equipment failure or personal injury may occur. Warning: Alerts the user on important steps about the module integration. Note/Tip: Provides advice and suggestions that may be useful when integrating the module.

  • Page 8: General Product Description

    • Designed for industrial grade quality In its most basic use case, the ME910X1-mPCIe can be applied as a wireless communication front-end for mobile products, offering mobile communication features to an external host CPU through its rich interfaces. ME910X1-mPCIe can further support customers’...

  • Page 9: Target Market

    ME910C1 mPCIe HW Design Guide Target Market ME910X1-mPCIe can be used for wide variety applications, where low power consumption and low cost are required while sufficient data rates are achieved: • Applications using the mPCIe connector • Notebook PC • M2M applications...

  • Page 10: Tx Output Power

    4G FDD (BW=5 MHz) -102 Table 4: RX Sensitivity Mechanical Specifications 2.7.1. Dimensions The overall dimensions of ME910X1-mPCIe family are: • Length: 50.95 mm, +0/-0.3mm • Width: 30 mm, +0/-0.3mm • Thickness : 3.2 mm, +/-0.15mm (Version with SIM holder : 4.78 mm, +/-0.15mm) 2.7.2.
  • Page 11 ME910C1 mPCIe HW Design Guide Case Range Note Storage non- Storage temperature is not intended for mPCIe in his transport operating Temperature –40°C ~ +105°C tray, wich cannot be heated over 65°C. Range Table 5: Temperature range Note: (*) Functional: the module is able to make and receive calls, data connection and SMS.

  • Page 12: Pins Allocation

    ME910C1 mPCIe HW Design Guide 3. PINS ALLOCATION Pin-out ME910X1 mPCIe Pinout follows the mPCIe specification Signal Function Type Comment Power Supply 3V3_AUX 3.3V Main Power Supply Power 3V3_AUX 3.3V Main Power Supply Power 3V3_AUX 3.3V Main Power Supply Power 3V3_AUX 3.3V Main Power Supply...
  • Page 13 ME910C1 mPCIe HW Design Guide Signal Function Type Comment Input for Clear To Send signal UART_CTS 1.8V See note (CTS) from DTE I2S – Digital Voice Interface (DVI) Digital Audio Interface (BIT Only for ME910G1-WW PCM_CLK 1.8V Clock) RESERVED for others Digital Audio Interface (TX Out Only for ME910G1-WW PCM_TX...
  • Page 14 ME910C1 mPCIe HW Design Guide Signal Function Type Comment Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Table 6: Pin-out Warning: Reserved pins must be left flowting Warning: 3V3 and 1V5 Power Supply at Connector are not used in the board.

  • Page 15: Power Supply

    ME910C1 mPCIe HW Design Guide 4. POWER SUPPLY The power supply circuitry and board layout are a very important part in the full product design and strongly reflect on the product overall performances, so please read carefully the requirements and guidelines that will follow for a proper design. Power Supply Requirements The external power supply must be connected to 3V3_AUX signal and must fulfil the following requirements:...

  • Page 16: General Design Rules

    ME910C1 mPCIe HW Design Guide General Design Rules The principal guidelines for the Power Supply Design embrace three different design steps: • The electrical design • The thermal design • The PCB layout. 4.3.1. Electrical Design Guidelines The electrical design of the power supply depends strongly from the power source where this power is drained.
  • Page 17 ME910C1 mPCIe HW Design Guide Figure 1: Linear regulator with 5V input and 3.3V output +12V Source Power Supply Design Guidelines • The desired output for the power supply is 3.3V. Due to the large difference between the input and output voltage values together with the current sinked, the linear regulator in the example above is capable but not efficient at high current sink and should not be used.

  • Page 18: Thermal Design Guidelines

    RF signals continuously during transmission. Therefore, special attention must be paid to how to dissipate the heat generated. The ME910X1 mPCIe card is designed to distribute the heat from the module IC’s to the entire PCB increasing as much as possible the heat dissipation.

  • Page 19: Power Supply Pcb Layout Guidelines

    4.3.3. Power Supply PCB Layout Guidelines Some ME910X1 versions have GSM capabilities. The GSM system is designed in such a way that the RF transmission is not continuous, otherwise it is packed into bursts at a base frequency of about 216 Hz, and the related current peaks can be as high as about 2.4A.
  • Page 20 ME910C1 mPCIe HW Design Guide • Any PCB power traces to the ME910X1-mPCIE and the Bypass capacitors must be wide enough to ensure no significant voltage drops occurs. This is for the same reason as previous point. Try to keep this trace as short as possible.

  • Page 21: Electrical Specification

    ME910C1 mPCIe HW Design Guide 5. ELECTRICAL SPECIFICATION Absolute Maximum Ratings – Not Operational Warning: A deviation from the value ranges listed below may harm the module. Symbol Parameter Unit 3V3_AUX Main Supply Voltage -0.5 at pins 3V3_AUX Table 8: Absolute Maximum Ratings – Not Operational Recommended Operating Conditions Symbol Parameter...

  • Page 22: Digital Section

    ME910C1 mPCIe HW Design Guide 6. DIGITAL SECTION Logic Levels All digital signals are powered from the internal module’s V power bank, V =1.8V. All control signals are powered from the external 3V3_AUX power bank, 3V3_AUX=3.3V. ABSOLUTE MAXIMUM RATINGS: Parameter Input High Voltage on digital signals (CMOS 1.8) with respect to ground when 3V3_AUX is supplied...

  • Page 23: Power On

    Table 13 Operating Range SIM Card Pads Power On The ME910X1-mPCIe will automatically Power ON as soon as VBATT applies to the module and W_DISABLE_N and PERST_N are HI. The module is ready for use after HW power Up and SW initialization process completes. For this reason, it is impossible to access ME910X1-PCIe during the initialization state.
  • Page 24 ME910C1 mPCIe HW Design Guide Note: To Turn ON the ME910X1-mPCIe module give the 3V3_AUX and release both the PERST_N and W_DISABLE_N pins, they must not be asserted Low. The following flow chart shows the proper ”MODEM TURN ON” procedure: Modem TURN ON POWER ->...

  • Page 25: Unconditional Restart

    Figure 6: MODEM START AT COMMAND” procedure Unconditional Restart To unconditionally restart the ME910X1-mPCIe, the signals PERST_N and W_DISABLE_N must be tied low for at least 200 milliseconds and then released. The unconditional hardware restart must always be implemented on the application board as the software must be able to use it as an emergency exit procedure.
  • Page 26 ME910C1 mPCIe HW Design Guide W_DISABLE_N and PERST_N are in open drain configuration. PERST_N needs an external pull up resistor to 3V3_AUX. W_DISABLE_N have already an internal pull up 100K resistor to 3V3_AUX. PIN DESCRIPTION Signal Function W_DISABLE_N Active Low, unconditional shutdown PERST_N Active Low, unconditional shutdown Table 14 W_DISABLE_N and PERST_N...
  • Page 27 ME910C1 mPCIe HW Design Guide The following flow chart shows the proper “MODEM RESTART” procedure: Modem RESTART Modem START AT CMD AT#SYSHALT Delay > 15s W_DISABLE_N -> LOW PERST_N -> LOW Delay > 200ms W_DISABLE -> HIGH PERST_N -> HIGH Delay >...

  • Page 28: Power Off Procedure

    ME910C1 mPCIe HW Design Guide Power OFF Procedure To turn OFF the ME910X1-mPCIe module, the W_DISABLE_N and/or PERST_N signals must be asserted Low. For proper shutdown operation with correct network detach and memory access disable, first prepare the module to shutdown by using AT#SYSHALT command..

  • Page 29: Control Signals

    ME910C1 mPCIe HW Design Guide Control Signals Signal Function Type WAKE_N Open Drain Output Signal 3V3_AUX Wake Up signal to the host W_DISABLE_N Active Low Input Signal Shutdown 3V3_AUX Wireless disabling (Airplane mode) PERST_N Active Low Input Signal 3V3_AUX Shutdown LED_WWAN_N Open Drain Output Signal 3V3_AUX...

  • Page 30: Hardware Interfaces

    It is compliant with the USB 2.0 specification and can be used for control and data transfers as well as for diagnostic monitoring and firmware update. The USB port is typically the main interface between the ME910X1-mPCIe module and OEM hardware.

  • Page 31: Serial Port

    USB physical communication is needed in case of SW update. 6.6.2. Serial Port The serial port is typically a secondary interface between the ME910X1-mPCIe module and OEM hardware. Several configurations can be designed for the serial port on the OEM hardware.
  • Page 32 The other lines can be left open if the host software allow it and is correctly set. RS232 Level Translation To interface the ME910X1-mPCIe UART with a RS232 PC COM Port, a voltage level translator is required. This level translator must: •...
  • Page 33 ME910C1 mPCIe HW Design Guide RS232 Level Adaption Circuitry Example: Figure 9 UART Level Adapter Example Note: In case of high speed access, higher than 1Mbps, the lines should be designed carefully to avoid signal degradation and noise generation. The RS232 serial port lines are usually connected to a DB9 connector as shown in a Figure below.

  • Page 34: Sim Interface

    ME910C1 mPCIe HW Design Guide SIM Interface The SIM pins provide the connections necessary to interface to a SIM holder located at the host device. The Voltage levels over this interface comply with 3GPP standards. The SIMIN line is not at the connector and is internally grounded. In this mPCIE variants onboard SIM holder and eSIM are not mounted.

  • Page 35: Rf Section

    Please refer to the Module’s Hardware User guide for the details Antenna Requirements 7.3.1. Antenna Connectors The ME910X1 Mini PCIe adapter is equipped with a set of 50 Ω RF U.FL. connectors from Hirose U.FL-R-SMT-1. The available connectors are: •...

  • Page 36: Main Gsm/Lte Antenna Requirements

    Main Antenna Requirements 7.3.3. GNSS Antenna Requirements ME910X1 mPCIe board does not supports active antenna. If you want to us an active antenna, the bias circuit should be done externally. In case of GNSS active antenna, It is recommended to follow: •...
  • Page 37 • Insertion loss (1565.42–1585.42 MHz) = 2.0 dB (Max) • Insertion loss (1597.5515–1605.886 MHz) = 2.0 dB (Max) Note: It is recommended to add a DC block to the customer’s GPS application to prevent damage to the ME910X1-mPCIe module due to unwanted DC voltage. Combined GNSS Antenna The use of a combined RF/GNSS antenna is NOT recommended.

  • Page 38: Mechanical Design

    3.2 mm (Version with SIM holder : 4.78 mm) • Weight: 7 gr Mechanical Drawing 8.2.1. Top View The figure below shows mechanical top view of the ME910X1-mPCIe, dimension are in Figure 13 ME910X1-mPCIe Top View 1VV0301642 Rev. 2 Page 38 of 56 2022-01-14 Not Subject to NDA...

  • Page 39: Bottom View

    ME910C1 mPCIe HW Design Guide 8.2.2. Bottom View The figure below shows mechanical top view of the ME910X1-mPCIe, dimension are in The figure shows the eSIM and SIM holder although by default they are not mounted. Figure 14 ME910X1-mPCIe Bottom View 1VV0301642 Rev.

  • Page 40: Side View

    ME910C1 mPCIe HW Design Guide 8.2.3. Side View The figure below shows mechanical side view of the ME910X1-mPCIe, dimension are in Figure 15 ME910X1-mPCIe Side View 1VV0301642 Rev. 2 Page 40 of 56 2022-01-14 Not Subject to NDA...

  • Page 41: Application Pcb Design

    ME910C1 mPCIe HW Design Guide 9. APPLICATION PCB DESIGN The ME910X1-mPCIe modules have been designed in order to be compliant with a standard lead-free SMT process. Recommended Footprint for the Application ME910X1-mPCIe modules fits any full mPCIe 52 pin socket and latch connectors compliant with PCI Express Mini Card Electromechanical Specification Revision 2.1...

  • Page 42: Emc Recommendations

    ME910C1 mPCIe HW Design Guide EMC RECOMMENDATIONS All ME910X1-mPCIe signals are provided with some EMC protection. However, the accepted level differs according to the specific pin. EMC Recommendations: Signal Function All Pins All pins All functions 500V Antenna Antenna connectors...

  • Page 43: Packing System

    ME910C1 mPCIe HW Design Guide PACKING SYSTEM Tray The ME910X1-mPCIe modules are packaged on trays of 20 pieces each: Modules per Tray Trays per Envelope Modules per Envelope Envelopes per Carton Box Modules per Box 5 + 1 empty Table 23 Tray Packing...
  • Page 44 ME910C1 mPCIe HW Design Guide Tray organization is shown in the figure below Figure 17 ME910X1-mPCIe Tray organization 1VV0301642 Rev. 2 Page 44 of 56 2022-01-14 Not Subject to NDA...

  • Page 45: Tray Drawing

    ME910C1 mPCIe HW Design Guide Tray Drawing Figure 18 ME910X1-mPCIe Tray Drawing Warning: These trays can withstand a maximum temperature of 65 ℃. 1VV0301642 Rev. 2 Page 45 of 56 2022-01-14 Not Subject to NDA...

  • Page 46: Moisture Sensitivity

    ME910C1 mPCIe HW Design Guide Moisture Sensitivity The ME910X1-mPCIe is a Moisture Sensitive Device level 3, in accordance with the standard IPC/JEDEC J-STD-020, take care all the relatives requirements for using this kind of components. Moreover, the customer has to take care of the following conditions: a) Calculated shelf life in sealed bag: 12 months at <40°C and <90% relative humidity...

  • Page 47: Conformity Assessment Issues

    ME910C1 mPCIe HW Design Guide CONFORMITY ASSESSMENT ISSUES Declaration of Conformity Hereby, Telit Communications S.p.A declares that the ME910C1-mPCIe is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet https://www.telit.com/red address: 1VV0301642 Rev.

  • Page 48: Reference Table Of Rf Bands Characteristics

    ME910C1 mPCIe HW Design Guide REFERENCE TABLE OF RF BANDS CHARACTERISTICS Mode Freq. Tx (MHz) Freq. Rx (MHz) Channels Tx-Rx Offset PCS 1900 1850.2 ~ 1909.8 1930.2 ~ 1989.8 512 ~ 810 80 MHz DCS 1800 1710 ~ 1785 1805 ~ 1880 512 ~ 885 95 MHz GSM 850...
  • Page 49 ME910C1 mPCIe HW Design Guide Mode Freq. Tx (MHz) Freq. Rx (MHz) Channels Tx-Rx Offset Tx: 26690 ~ 27039 LTE 850+ – B26 814 ~ 849 859 ~ 894 45 MHz Rx: 8690 ~ 9039 27210 27510 LTE 700 – B28A 703 ~ 733 758 ~ 788 55 MHz...

  • Page 50: Product And Safety Information

    ME910C1 mPCIe HW Design Guide 14. PRODUCT AND SAFETY INFORMATION Copyrights and Other Notices SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Although reasonable efforts have been made to ensure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from the use of the information contained herein.

  • Page 51: Usage And Disclosure Restrictions

    ME910C1 mPCIe HW Design Guide reproduce in any form the copyrighted products. Accordingly, any copyrighted computer programs contained in Telit’s products described in this instruction manual shall not be copied (reverse engineered) or reproduced in any manner without the express written permission of the copyright owner, being Telit or the Third Party software supplier.

  • Page 52: Third Party Rights

    ME910C1 mPCIe HW Design Guide 14.2.5. Third Party Rights The software may include Third Party’s software Rights. In this case the user agrees to comply with all terms and conditions imposed in respect of such separate software rights. In addition to Third Party Terms, the disclaimer of warranty and limitation of liability provisions in this License, shall apply to the Third Party Rights software as well.
  • Page 53 ME910C1 mPCIe HW Design Guide • it can interfere with other electronic devices, particularly in environments such as hospitals, airports, aircrafts, etc. • there is a risk of explosion such as gasoline stations, oil refineries, etc. It is the responsibility of the user to enforce the country regulation and the specific environment regulation.

  • Page 54: Glossary

    ME910C1 mPCIe HW Design Guide GLOSSARY Analog – Digital Converter ESD – Charged Device Model Clock CMOS Complementary Metal – Oxide Semiconductor Chip Select Digital – Analog Converter Data Terminal Equipment Equivalent Series Resistance GPIO General Purpose Input Output ESD – Human Body Model High Speed HSDPA High Speed Downlink Packet Access...

  • Page 55: Document History

    ME910C1 mPCIe HW Design Guide DOCUMENT HISTORY Revision Date Changes 2022-01-14 Minor changes on the languagand updated to the new template Legal Notices updated 2020-02-11 Document revision 2019-12-17 First issue 1VV0301642 Rev. 2 Page 55 of 56 2022-01-14 Not Subject to NDA...
