Olympus LG-LSLED Instructions Manual

Led light source for light guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instructions
LG-LSLED
LED light source for light guide
Notes
Optical Microscope Accessory
This instruction manual is for the Olympus LED light source for light guide.
To ensure the safety, obtain optimum performance and to familiarize yourself fully with the use of
this product, we recommend that you study this manual thoroughly before operating this product,
and always keep this manual at hand when operating this product.
Retain this instruction manual in an easily accessible place near the work desk for future reference.
For details of products included in the configuration of this system, see page 8.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LG-LSLED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Olympus LG-LSLED

Summary of Contents for Olympus LG-LSLED

  • Page 1 Notes Optical Microscope Accessory This instruction manual is for the Olympus LED light source for light guide. To ensure the safety, obtain optimum performance and to familiarize yourself fully with the use of this product, we recommend that you study this manual thoroughly before operating this product, and always keep this manual at hand when operating this product.
  • Page 2 In accordance with European Directive on Waste Electrical and Electronic Equipment, this symbol indicates that the product must not be disposed of as unsorted municipal waste, but should be collected separately. Refer to your local Olympus distributor in EU for return and/or collection systems available in your country. For Korea only 이...

  • Page 3: Table Of Contents

    5 Specifications ............................13 6 Assembly ..............................15 6-1 Attaching the light guide ..........................15 Attaching the light guide to LG-LSLED (LED light source for light guide) ........ 15 Attaching LG-DFI (Dual combination light guide) ..................15 Attaching LG-R66 (Ring light guide) .......................... 16 Replacing the light guide socket to LG-KLADP (Socket for KL light guide) [Optional] ..

  • Page 5: Concept Of This Instruction Manual

    LG-LSLED Concept of this instruction manual This instruction manual describes only the contents related to LG-LSLED (LED light source for light guide). When using this product, read all the instruction manuals supplied with the products (option) you purchased together with this manual.

  • Page 6: Product Concept

    Product Concept Product outline Using this LG-LSLED (LED light source for light guide) in combination with the Olympus microscope via light guide allows you to illuminate the sample. Intended use This product is designed as the illumination unit for microscope.

  • Page 7: Safety Precautions

    As this product contains the cooling fan, if you insert metal fragments or similar, the fan may be damaged or fire may be caused. Electric safety · Always use the power cord provided by Olympus. CAUTION If the proper AC adapter and the power cord are not used, the electric safety and the EMC (Electromagnetic Compatibility) performance of the product cannot be assured.
  • Page 8 Do not stare at operating lamp. May be harmful to eyes. Light guide · When turning ON the LED unit, do not cover the hole of the light guide socket of LG-LSLED or the distal WARNING end of the light guide. Otherwise, it may cause fire or burns.
  • Page 9 Instructions in instruction Label position Label Page manual Back of LG-LSLED Caution for electric safety Warning and caution for LED Front of LG-LSLED High temperature When caution labels are dirty or peeled off, contact Olympus for replacement or inquiries.

  • Page 10: Handling Precautions

    Handling precautions General · This product is a precision instrument. Handle it with care and avoid subjecting it to a sudden or NOTE severe impact. · Never disassemble any part of the product. Otherwise, failure could be caused. · Do not use the product in areas where it may be subjected to direct sunlight, high temperature and/or humidity, dust or vibrations.

  • Page 11: Maintenance And Storage

    LG-LSLED Maintenance and storage Cleaning of each unit Do not leave stains or fingerprints on the lenses and filters. If they get dirty, blow away dust with a commercially available blower and gently wipe the lens or filter with a piece of cleaning paper (or clean gauze).

  • Page 12: System Diagram

    (SCHOTT Co.) Refer to the instruction manual provided separately. This adapter is necessary for attaching LG-R66 (Ring light LG-LSLED guide) to SZX7 and SZX10. (LED light source for light guide) LG-R66 (Ring light guide) can be attached to SZX16 directly.

  • Page 13: Nomenclature Of Main Operating Portions

    LG-LSLED Nomenclature of main operating portions This section describes the nomenclature of main operating portions of the product. Lock screw (P.15) Light intensity adjustment knob (P.10) Filter slider (P.10) Filter slider (P.10) Main switch (P.10) (ON) / (OFF) Carrying handle...

  • Page 14: Operating Procedures

    If you set the light intensity level to scale 0, the light is NOTE not emitted, but the power of the LG-LSLED is ON (The indicator C is ON). To turn OFF the power, set the main switch A to (OFF).

  • Page 15: Adjusting Lg-Di/Lg-Dfi (Dual Light Guide/Dual Light Guide)

    LG-LSLED Insert the filter slider A into LG-LSLED completely to the end. During operation, keep the filter slider inserted completely NOTE or pulled out to the click position. If you operate LG-LSLED with the filter slider placed at the position other than two positions described above, the cooling in LG-LSLED may be impacted adversely or the filter slider may be damaged.

  • Page 16: Troubleshooting

    This section describes the possible problems of this product and their remedies. If problems occur, please review the following list and take remedial action as needed. If you cannot solve the problem after checking the entire list, please contact Olympus for assistance. Problem...

  • Page 17: Specifications

    LG-LSLED Specifications This section describes detail specifications, such as shape, functions and performances, etc. of this product. LG-LSLED Item Specifications Power supply Use AC adapter. Input voltage range: AC 100-240 V 50-60 Hz Input current: Max: 1.4 A Output voltage: DC 24 V Output current: 2.71 A...
  • Page 18 28LBA15 (LBA filter) [Optional] Item Specifications Filter type Color temperature conversion filter Color temperature conversion 15 decamired capability Dimension Ø28 mm / Thickness: 2 mm Weight Approx. 4 g LG-KLADP (Socket for KL light guide) [Optional] Item Specifications Attachable light guide SCHOTT light guide for KL1600LED Dimension Ø23 mm / Length: 39.3 mm...

  • Page 19: Assembly

    This light guide must be attached to SZX-FO (SZX coarse focusing unit) or SZX-FOF (SZX coarse/fine focusing unit) as well when attaching to LG-LSLED (LED light source for light guide). Align the mount holes A at the center of the light guide with the screw holes B of SZX-FOF, and attach them with the provided clamping screws C (2 pcs.) using the Allen screwdriver provided with the...

  • Page 20: Attaching Lg-R66 (Ring Light Guide)

    Attaching LG-R66 (Ring light guide) SZX16 Loosen the clamping knob B of LG-R66 (Ring light guide) A . Insert LG-R66 A upward until it contacts the objective bottom surface C , and tighten the clamping knob B . SZX10, SZX7 Loosen the clamping knob B of LG-R66 (Ring light guide) A .

  • Page 21: Replacing The Light Guide Socket To Lg-Kladp (Socket For Kl Light Guide) [Optional]

    LG-LSLED Replacing the light guide socket to LG-KLADP (Socket for KL light guide) [Optional] To use the light guide for KL1600LED (SCHOTT Co.), you must replace the light guide socket with optional LG-KLADP (Socket for KL light guide). Before replacing the light guide socket, be sure to set the power to...

  • Page 22: 6-2 Connecting The Ac Adapter And The Power Cord

    6-2 Connecting the AC adapter and the power cord · Always use the AC adapter and the power cord provided by Olympus. If the proper AC adapter and the CAUTION power cord are not used, the electric safety and the EMC (Electromagnetic Compatibility) performance of the product cannot be assured.
  • Page 23 If no power supply cord is provided, please select the proper power supply cord for the equipment by referring to “Specifications” and “Certified Cord” below: Caution : In case you use a non-approved power supply cord for Olympus products, Olympus can no longer warrant the electrical safety of the equipment.
  • Page 24 Table 2 HAR flexible cord Approval organizations and cordage harmonization marking methods Alternative marking utilizing Printed or embossed black-red-yellow thread (Length of harmonization marking (May be color section in mm) Approval organization located on jacket or insulation of internal wiring) Black Yellow Comite Electrotechnique Belge...
  • Page 25 LG-LSLED MEMO...
  • Page 26 MEMO...
  • Page 28 Manufactured by Shinjuku Monolith, 2-3-1 Nishi-Shinjuku, Shinjuku-ku, Tokyo 163-0914, Japan Distributed by AX9376 04 Issued in March, 2019...
