Upgrading the Firmware for the D200
The D200 has two sets of firmware, A and B, which must be updated separately. After
updating the A firmware, repeat steps 4–5, below, to upgrade the B firmware.
Important
The camera may be damaged if power is interrupted or camera controls are operated during the
update. Do not turn the camera off, remove or disconnect the power source, or operate camera
controls during the update. If the update is not completed successfully and the camera becomes
inoperable, take the camera to a Nikon-authorized service representative for inspection.
Get ready
To upgrade the camera firmware, you will need:
The camera
A UC-E4 USB cable or a memory card reader (do not use JumpShot cables provided
with Lexar Media cards)
One of the following power sources:
An EH-6 AC adapter
A fully-charged EN-EL3e rechargeable Li-ion battery
file:///K|/d200_firmup_En/En/d200ab_win_en_ABF.html (1 of 9) [6/18/2010 4:02:15 PM]
Upgrading the Firmware for the
Windows
Thank you for choosing a Nikon product. This guide describes how to
upgrade the camera firmware for the D200.
If you are not confident that you can perform the update
successfully, the update can be performed by a Nikon-authorized
service representative.
D200

Advertisement

loading
Need help?

Need help?

Do you have a question about the D200 and is the answer not in the manual?

Questions and answers

Related Manuals for Nikon D200

Summary of Contents for Nikon D200

  • Page 1 Nikon-authorized service representative. The D200 has two sets of firmware, A and B, which must be updated separately. After updating the A firmware, repeat steps 4–5, below, to upgrade the B firmware.
  • Page 2 Upgrading the Firmware for the D200 A Nikon-approved memory card that has been formatted in the camera (note that all data on the memory card will be deleted when the card is formatted; before formatting the card, back up any data you wish to keep to a computer or other device).
  • Page 3 Upgrading the Firmware for the D200 Right-click the I agree - Begin download link on the download site and select Save Target As. Save the file to the folder created in Step 3-1. Open the folder created in Step 3-1 and double-click F-D200-V201W.exe.

  • Page 4: Direct Usb Connection

    Upgrading the Firmware for the D200 Copy the firmware to the memory card The firmware can be copied to the camera memory card either by connecting the computer directly to the camera using the USB cable, or by removing the memory card from the camera and inserting it in a card reader.
  • Page 5 Upgrading the Firmware for the D200 If Nikon Transfer is installed, it will start automatically; to exit, select Exit from the File menu. If PictureProject is installed, it will start automatically; click Cancel to exit. Windows Vista Under Windows Vista, an AutoPlay dialog may be displayed.

  • Page 6: Card Reader

    Card Reader Connect the card reader to the computer and insert a formatted memory card. If Nikon Transfer is installed, it will start automatically; to exit, select Exit from the File menu. If PictureProject is installed, it will start automatically; click Cancel to exit.
  • Page 7 Upgrading the Firmware for the D200 Windows XP Under Windows XP, a Removable Disk dialog may be displayed. Click Cancel. The memory card will appear in “Computer” (Windows Vista) or “My Computer” (Windows XP) as a removable disk. Copy the firmware to the removable disk as described in Step5 of “Direct USB Connection.”...
  • Page 8 Upgrading the Firmware for the D200 Insert the memory card containing the firmware into the camera. Turn the camera on. Press the MENU button and select Firmware Version in the setup menu. *Illustration shows dialog displayed when both A and B firmware have been updated to version 2.00 or...
  • Page 9 Upgrading the Firmware for the D200 The message shown at right will be displayed when the update is complete. Confirm that the update was completed successfully. 8-1.Turn the camera off and remove the memory card. 8-2.Check the camera firmware version as described in Step2, “Check the current camera firmware version.”...
