CNC R
P
PRO Series 4848 Leg Kit
A
I
Version 2016Q1.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO Series and is the answer not in the manual?

Questions and answers

Related Manuals for CNC Router Parts PRO Series

Summary of Contents for CNC Router Parts PRO Series

  • Page 1 CNC R PRO Series 4848 Leg Kit Version 2016Q1.1...

  • Page 2: Bill Of Materials

    PRO Series 4848 Leg Kit Assembly Bill of Materials The following parts and bags will be used: • (4) 45” Steel Tube • (4) 30” Steel Tube • (8) [CRP113-07] Leg Kit Gusset • (4) [CRP113-09] Leg to Extrusion Bracket •...
  • Page 3 PRO Series 4848 Leg Kit Assembly • Attach the CRP113-09 Machine Connection Bracket to the top of the 30” steel tubes as shown. • Thread the M16 Leveling Feet into the bottom of the tube. PRO Series 4848 Leg Kit Assembly Version 2016Q1.1...
  • Page 4 PRO Series 4848 Leg Kit Assembly • Loosely attach the CRP113-07 gussets to the remaining tubes. Note: The sides of the gussets with 4 slots should be vertical. PRO Series 4848 Leg Kit Assembly Version 2016Q1.1 Copyright©2016 CNC Router Parts LLC.
  • Page 5 PRO Series 4848 Leg Kit Assembly • Attach the 45 inch tubes to the legs as shown. • Repeat this step for both sets of legs. PRO Series 4848 Leg Kit Assembly Version 2016Q1.1 Copyright©2016 CNC Router Parts LLC. All Rights Reserved.
  • Page 6 PRO Series 4848 Leg Kit Assembly • Ensure that the end of the crossmember tube is flush with the side of the leg tube. • Fully tighten the highlighted fasteners. • Repeat this step for all 4 gussets. PRO Series 4848 Leg Kit Assembly Version 2016Q1.1...
  • Page 7 PRO Series 4848 Leg Kit Assembly • Use the remaining tubes to complete the frame. PRO Series 4848 Leg Kit Assembly Version 2016Q1.1 Copyright©2016 CNC Router Parts LLC. All Rights Reserved.
  • Page 8 PRO Series 4848 Leg Kit Assembly • Ensure that the end of the crossmember tube is flush with the side of the leg tube. • Fully tighten the highlighted fasteners. • Repeat this step for remaining gussets. PRO Series 4848 Leg Kit Assembly Version 2016Q1.1...
  • Page 9 PRO Series 4848 Leg Kit Assembly • Attach the socket heads and hex nuts to the Leg to Extrusion Bracket. PRO Series 4848 Leg Kit Assembly Version 2016Q1.1 Copyright©2016 CNC Router Parts LLC. All Rights Reserved.
  • Page 10 PRO Series 4848 Leg Kit Assembly • The axis extrusion of your machine will be supported by the socket heads. The remaining T-nuts and flat head screws will be used to attach the extrusion. PRO Series 4848 Leg Kit Assembly Version 2016Q1.1...
