Ceiling or wall mount outdoor/indoor intrusion detector with curtain field-of-view two pir sensors + microwave sensor + anti-masking + waterproof. (8 pages)
Summary of Contents for MAXIMUM Security CURTAIN-FLT
Page 1
CURTAIN-FLT Operating Guide MAXIMUM Security (1984) Ltd. Page of 7 www.maximum.co.il...
Page 2
• Two "Optomos" relays for lifetime operation. CONGRATULATIONS We thank you for choosing a product of MAXIMUM Security (1984) Ltd. Based on over 30 years experience in R&D and in production of advanced security systems, we are proud to introduce to you the best Outdoor / Indoor motion detector ever presented, for industrial, commercial and residential security.
Page 3
CURTAIN-FLT is waterproof and can be installed outdoors or indoors. In addition to an unprecedented amazing and reliable detection capability, CURTAIN-FLT is equipped with excellent protection against any attempt to disable its operation by blocking (masking) its near field-of-view, whether the alarm system is Armed or Disarmed (Anti-masking protection).
Page 4
MOUNTING TERMINAL BLOCK WIRING DIP switch and trimmers for adjustments. See page No. _4_ 12V DC TAMPER (Relay-1) (Relay-2) ALARM ANTI-MASKING RELAY MAXIMUM Security (1984) Ltd. Page of 7 www.maximum.co.il...
Page 5
ADJUSTMENTS Remove cover to adjust Horizontal inclination adjustment of up to +/-5 The procedure 1. Unscrew. 2. Incline to the desired angle. 3. Screw tightly. Microwave Detection Sensitivity Detection Sensitivity High High adjustment adjustment DIP SWITCH ADJUSTMENT Remote Control LEDs Mode Sensitivity Not in use...
Page 6
ANTI-MASKING LEARNING PROCEDURE- PREPARING THE MASKING CHANNEL FOR OPERATION (Obligatory for proper Anti-masking operation!!!) To enable proper operation of the masking detection (Anti-masking), it is necessary to allow the detector to automatically study and analyze the environmental conditions of its protected area. This is an obligatory action that should be performed by the installer, ensuring proper operation of the Anti-masking channel!!! Study Procedure to be performed in two cases:...
Page 7
SPECIFICATIONS * Power supply……………………………...…………...12V to 14V DC * Current drain…...… Standby: 20mA (Max.); Operation: 40 mA (Max.) * Alarm relay contacts endurance………………...…… 15V DC / 20 mA * Anti-masking relay contacts endurance……………… 15V DC / 20 mA * TAMPER Switch endurance………………………..24V DC / 20 mA * Warm-up time………………………………..………….……...
