Compact-Pro 60 & 80
Réf. 30900 / 30967
EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36
SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510
Edition of 16/12/2021
More information on www.euromair.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Compact-Pro 60 and is the answer not in the manual?

Questions and answers

Related Manuals for EUROPRO Compact-Pro 60

Summary of Contents for EUROPRO Compact-Pro 60

  • Page 1 User manual Compact-Pro 60 & 80 Réf. 30900 / 30967 EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36 SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510 Edition of 16/12/2021 More information on www.euromair.com...

  • Page 2: Table Of Contents

    7. SAFETY CARD RUNNING ..........p.20 8. VOLUME SCHEME ............p.23 9. ELECTRICAL SCHEMES ..........p.24 10. DECLARATION OF CONFORMITY ......... p.31 11. WARRANTY CONDITIONS ..........p.32 12. FOLLOW-UP OF REVISIONS ........p.35 User manual - Compact-Pro 60 & 80 202006-438A-ENG...

  • Page 3: User Manual

    - people in charge of the use of the machine - people in charge of the cleaning and maintenance of the machine - people in charge of the final destruction of the machine 202006-438A-ENG User manual - Compact-Pro 60 & 80...

  • Page 4: Warning

    • For any replacement of parts, only use genuine parts. • Do not modify the machine. • Do not cut or dismantle the protection grids. • Do not open the electric box. User manual - Compact-Pro 60 & 80 202006-438A-ENG...
  • Page 5 • After every use, necessarily grease the pump with a mixture of water + storage liquid to avoid it blocking up. The storage of a not greased pump can damage it seriously. IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL MODIFICATION WITHOUT ADVANCED NOTICE. 202006-438A-ENG User manual - Compact-Pro 60 & 80...
  • Page 6 - Command panel lamps must be lighted-up (green = correct / red = default). - Engage the starter with the contact key. - Resume spraying procedure. IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL MODIFICATION WITHOUT ADVANCED NOTICE. User manual - Compact-Pro 60 & 80 202006-438A-ENG...

  • Page 7: Transport

    It is imperative to collide this cable on the harness of the vehicle. Compact-Pro 60 and 80 are not transport trailers, it is strictly forbidden to transport people or products related to the application of the machine.

  • Page 8: Your Machine

    3. YOUR MACHINE 3.1. DESCRIPTION Compact-Pro 60 and 80 are equipped with a liquid-cooled diesel engine that drives a double gear pump that provides the hydraulic flows required by the equipment. The 400 L/min, 4 bar compressor is positioned on a plate for easy adjustment of the drive belt tension.

  • Page 9: Identification Of The Components

    Jockey wheel Compressor oil level Product pressure control manometer Electric circuit breaker Pump outlet Hopper bearing lubricator Hood clips Mixer bearing lubricator Emergency stop Motor bearing lubricator Air valve Mixer grid roller lubricator 202006-438A-ENG User manual - Compact-Pro 60 & 80...
  • Page 10 Descent: right position with spring return to the centre. Handle On (right position) / Off (left position) HP washer Mixer rotation control handle Reverse: right position maintained. Stop: centre position. Forward: left position maintained. User manual - Compact-Pro 60 & 80 202006-438A-ENG...

  • Page 11: Use Of The Machine

    In some cases, it will be necessary to use a pump that generates a higher pressure to compensate for this loss. Whenever possible, a dilution of the product and a higher pump pressure will allow a better flow in the hoses. 202006-438A-ENG User manual - Compact-Pro 60 & 80...

  • Page 12: Machine Starting Up

    Never run the screw without product or water. The screw rotation control handle has a preferential direction characterized by a held position. Reverse rotation is possible by holding the handle manually in the LEFT position. User manual - Compact-Pro 60 & 80 202006-438A-ENG...

  • Page 13: High Pressure Washer Prerequisites

    Under pressure outlet Remember to clean the suction filter very regularly (at least once a week) to avoid cavitation of the pump. The filter is located just behind the water inlet connection. 202006-438A-ENG User manual - Compact-Pro 60 & 80...

  • Page 14: High Pressure Washer Starting Up

    For transporting the machine, the mixing tank must be in the low position. After cleaning, return the mixing container to the lowered position on its rubber pads and remove the drain plugs. User manual - Compact-Pro 60 & 80 202006-438A-ENG...

  • Page 15: Water Doser

    • Pressing the +WATER button (B3) will cause water to flow for as long as the button is held down. The display (A1) adds the volume of water added to the displayed volume. This function is only possible outside of the automatic water dosing cycle seen above. 202006-438A-ENG User manual - Compact-Pro 60 & 80...

  • Page 16: Defects And Remedies

    Check engine oil level and texture ("mayonnaise"). Check engine oil level. If low level contact technical service. The diesel engine smokes black Check the injection / Clean the injection Contact technical service. User manual - Compact-Pro 60 & 80 202006-438A-ENG...
  • Page 17 The hose must not be pinched and the Check the water supply. water valve open. HP washer does not work Check the filter for clogging. Clean the supply filter before each use. Hydraulic problem. Contact a dealer. 202006-438A-ENG User manual - Compact-Pro 60 & 80...

  • Page 18: Maintenance

    In order to guarantee a long-lasting operation of the machine, we invite you to contact your dealer for any maintenance intervention. He will carefully carry out the operations and check the various points we recommend. User manual - Compact-Pro 60 & 80 202006-438A-ENG...
  • Page 19 Adjust valve clearance Tare and clean injector Clean radiator (outside) Clean radiator (inside) Clean fuel tank Clean hydraulic tank Check tightening of screws and hoses Check pump, seals and flectors At every use 202006-438A-ENG User manual - Compact-Pro 60 & 80...

  • Page 20: Safety Card Running

    Open the air valve on the spray lance. not closed. Air problem Check the condition of the flow meter. Remove the flow meter for cleaning. The flow meter is out of order. Contact technical service. User manual - Compact-Pro 60 & 80 202006-438A-ENG...
  • Page 21 The safety sensor of the mixer grid does Contact technical service. not function. 7.4. BOTH RED LIGHTS ARE ON Defect To check Remedies See 7.2 and 7.3 202006-438A-ENG User manual - Compact-Pro 60 & 80...
  • Page 22 The power supply circuit must be cut Contact the technical service. somewhere. The protective fuses on the card. Change the faulty fuse. User manual - Compact-Pro 60 & 80 202006-438A-ENG...

  • Page 23: Volume Scheme

    8. VOLUME SCHEME 202006-438A-ENG User manual - Compact-Pro 60 & 80...

  • Page 24: Electrical Schemes

    9. ELECTRICAL SCHEMES User manual - Compact-Pro 60 & 80 202006-438A-ENG...
  • Page 25 9. ELECTRICAL SCHEMES (continued) 202006-438A-ENG User manual - Compact-Pro 60 & 80...
  • Page 26 9. ELECTRICAL SCHEMES (continued) User manual - Compact-Pro 60 & 80 202006-438A-ENG...
  • Page 27 9. ELECTRICAL SCHEMES (continued) 202006-438A-ENG User manual - Compact-Pro 60 & 80...
  • Page 28 9. ELECTRICAL SCHEMES (continued) User manual - Compact-Pro 60 & 80 202006-438A-ENG...
  • Page 29 9. ELECTRICAL SCHEMES (continued) 202006-438A-ENG User manual - Compact-Pro 60 & 80...
  • Page 30 User manual - Compact-Pro 60 & 80 202006-438A-ENG...

  • Page 31: Declaration Of Conformity

    Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36 SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510 202006-438A-ENG User manual - Compact-Pro 60 & 80...

  • Page 32: Warranty Conditions

    We exclude all liability for indirect damages suffered by the customer, such as, but not limited to, loss of income, turnover, loss of profits, loss of image, of any kind whatever. User manual - Compact-Pro 60 & 80 202006-438A-ENG...
  • Page 33 As this principle also applies to batteries, our supplier Parts Holding Europe, or one of its sister companies, remains your contact for your requests (https://www. partsholdingeurope.com/). 202006-438A-ENG User manual - Compact-Pro 60 & 80...
  • Page 34 User manual - Compact-Pro 60 & 80 202006-438A-ENG...

  • Page 35: Follow-Up Of Revisions

    For any intervention on the engine, consult the maintenance manual supplied with the machine. Date Signature Stamp 50 hours 250 hours 500 hours 750 hours 1000 hours 202006-438A-ENG User manual - Compact-Pro 60 & 80...
