- Page 1 User manual X-Screed D60 Réf. 40100 EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36 SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510 Edition of 26/09/2023 More information on www.euromair.com...
-
Page 2: Table Of Contents
5.10. High pressure washer prerequisites ......p.26 5.11. High pressure washer starting up ......p.27 5.12. Work finalisation ............p.27 5.13. Malfunctions in the conveying of material ....p.29 5.14. Malfunctions in road transport .........p.30 5.15. Operation in winter ..........p.30 User manual - X-SCREED D60 202206-601-ENG... - Page 3 8. DEFECTS AND REMEDIES ..........p.43 9. VOLUME SCHEME ............p.45 10. ELECTRICAL SCHEME ..........p.46 11. HYDRAULIC SCHEME ..........p.47 12. DECLARATION OF CONFORMITY ......... p.49 13. WARRANTY CONDITIONS ..........p.51 14. FOLLOW-UP OF REVISIONS ........p.54 202206-601-ENG User manual - X-SCREED D60...
-
Page 4: User Manual
- people in charge of the transport of the machine - people in charge of the use of the machine - people in charge of the cleaning and maintenance of the machine - people in charge of the final destruction of the machine User manual - X-SCREED D60 202206-601-ENG... -
Page 5: Warning
• In case of needed After-Sale Service, always specify the machine model and its serial number. • For any replacement of parts, only use genuine parts. • Do not modify the machine. • Do not cut or dismantle the protection grids. • Do not open the electric box. 202206-601-ENG User manual - X-SCREED D60... - Page 6 • After every use, necessarily grease the pump with a mixture of water + storage liquid to avoid it blocking up. The storage of a not greased pump can damage it seriously. IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL MODIFICATION WITHOUT ADVANCED NOTICE. User manual - X-SCREED D60 202206-601-ENG...
- Page 7 - Command panel lamps must be lighted-up (green = correct / red = default). - Engage the starter with the contact key. - Resume spraying or pumping procedure. IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL MODIFICATION WITHOUT ADVANCED NOTICE. 202206-601-ENG User manual - X-SCREED D60...
-
Page 8: Transport
It is imperative to collide this cable on the harness of the vehicle. X-Screed D60 is not a transport trailer, it is strictly forbidden to transport people or products related to the application of the machine. - Page 9 The safety hitch is absolutely necessary. It must be replaced in the event of loss or wear. Check the condition of the brake cable of the overrunning hitch and the safety cable at regular intervals. 202206-601-ENG User manual - X-SCREED D60...
- Page 10 The wheel brakes comply with the regulations for toxic substances and EU regulations. BRAKE SUPPORT AND CHOCKS Secure the wheels with both brake chocks, both on level ground and on slopes, to prevent the vehicle from rolling away. User manual - X-SCREED D60 202206-601-ENG...
- Page 11 • Be careful with the load and do not work with too much momentum. Acceleration and deceleration should be kept within moderate limits. • Do not leave the load hanging on the lift. • Ensure that no one is in the danger zone around the load. Optional kit 202206-601-ENG User manual - X-SCREED D60...
-
Page 12: End-Of-Life Of The Product
For any further information, please contact our hotline +33 4 42 29 08 96 or conseil@euromair.com. User manual - X-SCREED D60 202206-601-ENG... -
Page 13: Your Machine
Overall length with tow bar 5,23 m Overall width 1,58 m Height at the highest point 1,55 m Height at the highest point with optional tank 2,20 m Weight when full with oil and diesel 1960 kg 202206-601-ENG User manual - X-SCREED D60... -
Page 14: Identification Of The Components
Hydraulic oil level Hopper cylinder safety lock Engine oil level Jockey wheel Motor flange lubricator Loading hopper (optional) Diesel tank cap Removable light plates Automatic lubrication unit Tank drainage Air system valves Shovel (optional) User manual - X-SCREED D60 202206-601-ENG... - Page 15 Hopper raising control Mixing paddle rotation control switch Mixing circuit manometer Tank grid safety indicator Tank air control selector - Left position: AUTO - Right position: MANUAL (blows air continuously) Pressure circuit manometer Compressor temperature indicator 202206-601-ENG User manual - X-SCREED D60...
-
Page 16: Prerequisites
• Check hoses and couplings regularly for wear and tear (abrasion and ageing, see safety check sheet for optimum condition). For safe operation, it is essential that only original EUROMAIR conveying hoses and couplings are used (or couplings approved by the manufacturer). User manual - X-SCREED D60 202206-601-ENG... -
Page 17: Conveying Hoses And Couplings
• The conveying hoses must be able to withstand an operating pressure of 10 bar for fluid screed machines and 40 bar for plastering or pump and spray machines. 202206-601-ENG User manual - X-SCREED D60... -
Page 18: Operation In Confined Spaces
Before removing the plug on the oil filler, make sure that the pressure has been vented. • Check that the fuel tank level is optimal for operation. • Remove dust from the air filters by pressing the valve on the air filters. User manual - X-SCREED D60 202206-601-ENG... -
Page 19: Operation
16 mm grain size. The use of other materials is only possible after prior agreement and consultation with the manufacturer. Any improper use of the machine is prohibited. 202206-601-ENG User manual - X-SCREED D60... -
Page 20: Safety Instructions For Normal Operation
1. Check once or twice a year whether the lifting mechanism opens properly. To do so, turn the valve cap counter-clockwise. 2. Check once a year the pressure setting in accordance with local regulations. This test should not be performed on the compressor but in a suitable test room. User manual - X-SCREED D60 202206-601-ENG... -
Page 21: Checking Before Starting
15 mm Only fill the mixing tank to within 15 mm of the bottom edge of the filler neck. Otherwise, the service life of the mixing tank and its wearing parts will be considerably reduced. 202206-601-ENG User manual - X-SCREED D60... -
Page 22: Conveying Or Pumping
Never open the lid if it is under pressure! Clean the edges of the tank. Replace the rubber gasket immediately if it has major cracks or if material has penetrated the gasket. User manual - X-SCREED D60 202206-601-ENG... -
Page 23: Appropriate Conveying Pressure
The optimum transport pressure is around 3 to 4 bar. For this reason, the conveying hoses must be raised at regular intervals depending on the distance to be covered and the fluidity of the product (see figure further). 202206-601-ENG User manual - X-SCREED D60... -
Page 24: Automatic Lubrication
• The machine is equipped with an automatic lubrication device that allows greasing the lubrication points without the operator having to do it manually. This function is provided by a lubrication programmer integrated in the machine. User manual - X-SCREED D60 202206-601-ENG... -
Page 25: Loading Hopper (Optional)
PIN 1 of the connector, the blue wire to PIN 2 and the earth wire to PIN 3, matching the numbers at both ends of the cable and with the corresponding numbering. 202206-601-ENG User manual - X-SCREED D60... -
Page 26: High Pressure Washer Prerequisites
Water inlet with Gardena type connection Under pressure outlet Remember to clean the suction filter very regularly (at least once a week) to avoid cavitation of the pump. The filter is located just behind the water inlet connection. User manual - X-SCREED D60 202206-601-ENG... -
Page 27: High Pressure Washer Starting Up
• Do not use aggressive detergents or diesel fuels for cleaning and use only lint-free cleaning cloths. • Do not use flammable or caustic solvents as they may damage parts of the machine. 202206-601-ENG User manual - X-SCREED D60... - Page 28 • Disconnect the air inlet and outlet hoses from the mixing tank and clean them with water. For this operation, make sure that there is no pressure left in the air hoses. User manual - X-SCREED D60 202206-601-ENG...
-
Page 29: Malfunctions In The Conveying Of Material
If material comes into contact with the eyes despite wearing protective glasses, immediately rinse the eyes with plenty of cold water. Hydraulic aggregates are aggressive and can damage the eyes. Consult a specialist immediately. 202206-601-ENG User manual - X-SCREED D60... -
Page 30: Malfunctions In Road Transport
• In case of extreme temperatures, it is recommended to remove the battery at night and store it in a warm place. • In the case of batteries that are not maintenance-free, ensure that the acid level is correct. User manual - X-SCREED D60 202206-601-ENG... -
Page 31: Maintenance
• Never smoke near a battery that is being charged or has just been charged. Charging creates an explosive atmosphere and is therefore dangerous for the user for several hours. • Never disconnect the battery while the machine is running. This can cause sparks. 202206-601-ENG User manual - X-SCREED D60... -
Page 32: Automatic Greasing
• Once a day, grease the air release valve of the mixing tank lid (H). WEEKLY • Machine with optional loading hopper: grease the manual grease points on the hopper lifting cylinder (J). EVERY SIX MONTHS • Grease the drawbar and hand brake (I). User manual - X-SCREED D60 202206-601-ENG... -
Page 33: Preventive Maintenance
• It is recommended to keep a record of all maintenance operations and replacement of parts carried out on the machine. If in doubt about any maintenance operation, do not carry it out! Contact an approved after-sales service or our hotline: +33 4 42 29 08 96. 202206-601-ENG User manual - X-SCREED D60... - Page 34 (4) These indications refer to the most important engine maintenance operations. For any work on the motor, consult the manual supplied with this one first. Some substances must be recycled. There are specialised waste disposal companies for this purpose. User manual - X-SCREED D60 202206-601-ENG...
-
Page 35: Maintenance Of The Motor-Compressor Unit
• The oil filter must also be changed when the oil is changed for the first time. • If used at pressures above 10 bar or at oil temperatures above 100°C, oil life will be reduced. For used oil, always comply with the applicable regulations on the disposal of pollutants. 202206-601-ENG User manual - X-SCREED D60... - Page 36 If any oil is spilt on the ground during the oil change operation, take great care when cleaning up to avoid possible falls. ENGINE OIL CHANGE Refer to the engine operating manual for recommended viscosity and oil change intervals. User manual - X-SCREED D60 202206-601-ENG...
- Page 37 • Loosen the spring clips (K), remove the dust collector (L) and clean it. • Remove the filter unit (N) from the housing (O). • Reassemble the parts in reverse order. • Check and tighten all air inlet ducts. 202206-601-ENG User manual - X-SCREED D60...
- Page 38 • After stopping and depressurising the machine, open the radiator volute and blow out any impurities with compressed air. • Depending on the conditions and frequency of use of the machine, repeat this operation more frequently. User manual - X-SCREED D60 202206-601-ENG...
-
Page 39: Additional Maintenance
• After 50 km, retighten the wheel nuts. If the optional hopper and shovel are equipped: • Check that the hopper is securely fastened using the locking device provided. • Check that the shovel is firmly attached to the hopper. 202206-601-ENG User manual - X-SCREED D60... - Page 40 • Check wear plates and blades on tank mixer and replace if necessary. • Clean the diesel tank filter. • Replace PVC fuel filter. • Check wheel bearing. • Replace tank lid gasket. • Replace air filters and inner cartridges. User manual - X-SCREED D60 202206-601-ENG...
- Page 41 • Grease all moving parts of the chassis. After changing tyres or on a new machine, it is advisable to retighten the wheel nuts after the machine has been moving for a few metres. 202206-601-ENG User manual - X-SCREED D60...
-
Page 42: Lubricants
• Lithium grease KL Never mix different types of oil or grease! This can impair their effectiveness. Used oil is harmful to the machine. With good quality oil, the machine will work better and last longer. User manual - X-SCREED D60 202206-601-ENG... -
Page 43: Defects And Remedies
Dismantle the cylinder and check for After running at idle, the Suction cylinder clogged. clogging, replace if necessary. motor-pump unit does not return to load. Solenoid valve on suction unit faulty. Replace solenoid valve. 202206-601-ENG User manual - X-SCREED D60... - Page 44 Position the machine so that the Blocked air inlet to the machine cold air inlet is not obstructed and and/or recirculation of hot air. avoid any recirculation of hot air to the cold air inlet. User manual - X-SCREED D60 202206-601-ENG...
-
Page 45: Volume Scheme
9. VOLUME SCHEME 202206-601-ENG User manual - X-SCREED D60... -
Page 46: Electrical Scheme
10. ELECTRICAL SCHEME User manual - X-SCREED D60 202206-601-ENG... -
Page 47: Hydraulic Scheme
11. HYDRAULIC SCHEME 202206-601-ENG User manual - X-SCREED D60... - Page 48 User manual - X-SCREED D60 202206-601-ENG...
-
Page 49: Declaration Of Conformity
Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36 SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510 202206-601-ENG User manual - X-SCREED D60... - Page 50 User manual - X-SCREED D60 202206-601-ENG...
-
Page 51: Warranty Conditions
We exclude all liability for indirect damages suffered by the customer, such as, but not limited to, loss of income, turnover, loss of profits, loss of image, of any kind whatever. 202206-601-ENG User manual - X-SCREED D60... - Page 52 The Euromair, Euromair MPC or Mixer service centres may be considered as the manufacturer’s representatives if they are the closest. As this principle also applies to batteries, our supplier Parts Holding Europe, or one of its sister companies, remains your contact for your requests (https://www. partsholdingeurope.com/). User manual - X-SCREED D60 202206-601-ENG...
- Page 53 202206-601-ENG User manual - X-SCREED D60...
-
Page 54: Follow-Up Of Revisions
The recommendations given in this manual are indicative and are not a substitute for those recommended by the engine manufacturer. For any intervention on the engine, consult the maintenance manual supplied with the machine. Date Signature Stamp 50 hours 250 hours 500 hours 750 hours 1000 hours User manual - X-SCREED D60 202206-601-ENG... - Page 55 EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36 SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510 More information on www.euromair.com 202206-601-ENG User manual - X-SCREED D60...
