RS-SERIES LOUDSPEAKERS
RS-308 • RS-310 • RS-312 • RS-315

Specifications

Frequency Response
Respuesta Frecuencia | Bande passante | Frequenzgang
Dimensions
Dimensiones | Dimensions | Abmessungen
Net Weight
Peso Neto | Poids net | Gewicht
High Frequency Driver
Driver de agudos | Haut-parleur hautes fréquence | Hochtontreiber
Low Frequency Driver
Altavoz de graves | Haut-parleur Basses | Bass-Chassis
Input
Entrada | Entrée | Eingang
Impedance
Impedancia | Impedance | Impedanz
Peak Power
Potencia de pico | Peak | Peak
RMS
RMS | RMS | RMS
Note: 308, 310, 312, and 315 have similiar back panels.
Nota: 308, 310, 312 y 315 tienen paneles traseros similares.
Note: 308, 310, 312 et 315 disposent d'une face arrière identique.
Wichtig: 308,310, 312 und 315 haben identische Rückseiten.
RS-308
RS-310
80Hz ~ 18kHz
70Hz ~ 20kHz
11.4" x 8.7" x 16.1"
14" x 10.6" x 19.7"
(290mm x 220mm x 410mm)
(355mm x 270mm x 500mm)
14.8 lbs (6.7 kg)
22.7 lbs (10.3 kg)
1"
Titanium 1,35"
8"
10"
Speakon
Speakon
8Ω
8Ω
480W
640W
120W
160W
ESPECIFICACIONES • CARACTÉRISTIQUES TECHNIQUES • TECHNISCHE DATEN
RS-312
RS-315
45Hz ~ 20kHz
45Hz ~ 18kHz
16.5" x 12.2" x 22.83"
17.9" x 15.8" x 27"
(420mm x 310mm x
(455mm x 400mm x 685mm)
580mm)
32 lbs (14.5 kg)
44.5 lbs (20.2 kg)
Titanium 1,35"
Titanium 1,75"
12"
15"
Speakon
Speakon
8Ω
8Ω
800W
1200W
200W
300W
SPECIFICATIONS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-SERIES LOUDSPEAKERS RS-308 and is the answer not in the manual?

Questions and answers

Stan
January 31, 2025

How do I hook 308 Gemini speaker up

1 comments:
Mr. Anderson
February 10, 2025

To connect the Gemini RS-308 loudspeakers, follow these steps:

1. Connect the Speakers First: Ensure all speakers are properly connected before turning on the amplifier.
2. Chain-Link Setup: If using a chain-link setup, only one additional speaker can be added per speaker.
3. Normal Setup: Follow the normal setup steps after connecting the speakers. The amplifier should compensate for additional speakers.
4. Turn on the Mixer and Amplifier: Set the mixer volume to a reasonable level, then turn on the amplifier and adjust the volume or gain as recommended in the amplifier’s user manual.
5. Play Audio Source: Start playing from a connected turntable, CD player, microphone, or other sources, and adjust the mixer volume accordingly.

Ensure the speakers are not exposed to direct sunlight, heat sources, or water. Clean only with a damp cloth.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Gemini RS-SERIES LOUDSPEAKERS RS-308

  • Page 1: Specifications

    RS-SERIES LOUDSPEAKERS RS-308 • RS-310 • RS-312 • RS-315 Specifications Frequency Response Respuesta Frecuencia | Bande passante | Frequenzgang Dimensions Dimensiones | Dimensions | Abmessungen Net Weight Peso Neto | Poids net | Gewicht High Frequency Driver Driver de agudos | Haut-parleur hautes fréquence | Hochtontreiber Low Frequency Driver Altavoz de graves | Haut-parleur Basses | Bass-Chassis Input...
  • Page 2 - If you use a stand, check the stand’s specifications and make sure that it is sturdy enough to support • LOCALIZACION the weight of the speaker. You may ne-ed to limit the number of people around the placed stand, in – Si utiliza un soporte, compruebe las especificaciones del soporte y asegúrese de que es order to avoid toppling the device or causing damage to the internal components.
  • Page 3: Operation

    NORMAL setup, your AMPLIFIER should compensate for the extra speakers. INTRODUCCIÓN: Felicidades por su compra de un altavoz de la SERIE-RS, diseñado y fabricado por Gemini Sound Products. Este altavoz avanzado está amparado con una garantía de uno año. PRECAUCIONES: 1.
  • Page 4: Betrieb

    INTRODUCTION: Félicitations concernant l’achat d’une enceinte Gemini de la RS-SÉRIE. Avec un entretien & un us- age adéquat, ce produit vous apportera satisfaction durant de nombreuses années. Cet appareil professionnel bénéficie d’une garantie durant 1 an. MISES EN GARDE: 1. Avant toute utilisation, nous vous recommandons de prendre connaissance des instructions qui suivent.
  • Page 5: Suspended Installation

    4. DO NOT suspend a speaker from an other suspended speaker. indica abajo en el detalle de la fotografía.
  • Page 6 You will be responsible for shipping charges A. Gemini guarantees its products to be free from de- to Gemini UK, and Gemini UK will pay to return the fects in materials and workmanship for One (1) year unit to you if it is considered under warranty.
  • Page 7 In the USA: if you experience problems with this unit, call 732-346-0061 for GCI Technologies customer service. Do not attempt to return this equipment to your dealer. Parts of the design of this product may be protected by worldwide patents. Information in this manual is subject to change without notice and does not represent a commitment on the part of the vendor.
