- Page 1 技术要求： 1.该手册印刷颜色均为黑色 : PANTONE BLACK C 2.纸张规格为A 5 3.如果供应商的排版需要加空白页，请加在封底之前 用户手册 CMDW2SL/BK/GD 6720602018 /BLUE/ORG(2601) COOKOLOGY 英国 标记 处数 分区 更改文件号 签 名 日 期 阶 段 标 记 比 例 80G双胶 REV. 00 校对 编 制 性能 数 量 重 量...
- Page 2 C MDW2ORG C MDW2SL C MDW2BLUE C MDW2BK C MDW2GD Please keep this manual for future reference...
- Page 3 QUICK USER GUIDE Please read the below instructions before use Connected to power supplies The power supply is 220-240VAC 50 Hz the specification of the socket is 10 A 250 VAC For connection of the drainpipe: Put end of the drain into a sink or bucket. Fix the drainpipe to the back pipe of the machine.
- Page 4 Open the door, placing the dishes and adding detergent Stack by size and from the two sides to the middle. All cutlery should be tilted to improve cleaning performance. Please check nothing is blocking the arm from spinning for best cleaning results Pull open Left...
-
Page 5: Table Of Contents
CONTENTS Please carefully read this manual before using the dishwasher, it will help you use and maintain the dishwasher properly. IMPORTANT SAFETY INSTRUCTIONS GETTING TO KNOW YOUR APPLIANCE Dishwasher features Control panel USING YOUR DISHWASHER Loading the salt into the softener Adjusting Salt Consumption Loading the dishwasher baskets Filling the dispenser... -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WANING When using your dishwasher, follow the precautions listed below: This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments;... - Page 7 experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. (For IEC60335-1) This appliance is for indoor use only, for household use only. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.
- Page 8 Do not modify the plug provided with the appliance; If it does not fit the outlet. Have a proper outlet installed by a qualified electrician. Improper connection of the equipment-earthing conductor can result in the risk of an electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly earthed.
- Page 9 Do not wash plastic items unless they are marked dishwasher safe or the equivalent. For plastic items without mark, check the manufacturer's recommendations. Use only detergent additives designed for an automatic dishwasher. Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
- Page 10 Disposal For disposing of package and the appliance please go to a recycling center. Therefore, cut off the power supply cable and make the door closing device unusable. Cardboard packaging is manufactured from recycled paper and should be disposed in the wastepaper collection for recycling.
-
Page 11: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE IMPORTANT: Before using this dishwasher for the first time and to get the best performance, read these instructions. Dishwasher features Handle Control panel Kick board Upper spray arm Cap of water tank Lower spray arm Salt container Filter The place to... -
Page 12: Control Panel
Control panel To turn on and off. Power Program Button: Press the button to select wash cycles Program P1(ECO ) -P2 (1 hour ) -P3 (rapid ). ECO (Steam Add in Storage Get rid of the smell, damp and mildew proofing. Function Extra dry To select the extra dry function. -
Page 13: Using Your Dishwasher
USING YOUR DISHWASHER NOTE If your model has no water softener, you may skip this section. Loading the salt into the softener Always use salt intended for use with dishwasher. The salt container is located beneath the basket and should be filled as follows: WANING Only use salt specifically designed for dishwashers use! Every other type of salt not specifically designed for dishwasher use,... -
Page 14: Adjusting Salt Consumption
E. Usually, the salt warning light will be cease to be illuminated within 2-6 days after the salt container has been filled with salt. F. Immediately after filling the salt into the salt container, a washing program should be started (Suggest choosing rapid program). Otherwise filter system, pump or other important parts of the machine may be damaged by salty water. -
Page 15: Loading The Dishwasher Baskets
There are 6 levels of salt consumption in all. It is recommended to select the level according to below table: WATER HARDNESS Setting on the Digital display stalls Salt consumption(gram/cycle) water softener Mmol/l 0 - 0.94 0 - 5 1.0 - 2.0 6 - 11 2.1 - 3.0 12 - 17... - Page 16 Suitability of use in the dishwasher Not suitable for use: Limited suitability: Cutlery with wooden, horn, china or Some glasses can become dull mother-of-pearl handles after a large number of washes. Plastic items that are not heat resistant Silver and aluminum tend to Older cutlery with glued parts that are discolor during washing.
- Page 17 Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the basket. Please do not overload your dishwasher. This is important for good results and for reasonable energy consumption. Loading basket Position the dishes and cookware so that they will not get moved by the spray of water.
- Page 18 Loading the cutlery basket Number Item Knife Soup spoon Fork Dessert spoon Teaspoon Serving spoon Serving fork Gravy ladle For personal safety and a top quality clean, make sure place the silverware in the basket as follows: They do not nest together. Place silverware with handles-down.
- Page 19 Filling the detergent WANING Only use detergent specifically for dishwashers. Never use any other detergents. This will damage the appliance. Dishwasher detergent is corrosive! Keep dishwasher detergent out of the reach of children. Concentrated Detergent Based on their chemical composition, detergents can be split in two basic types: Conventional, alkaline detergents with caustic components.
- Page 20 Adding detergent The place to add the detergent (Do not use detergent for the fruit washing program)
-
Page 21: Programming The Dishwasher
PROGRAMMING THE DISHWASHER Wash cycle table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. Cycle Selection Description Program Detergent Time Energy Water... -
Page 22: Turning On The Appliance
NOTE EN 50242: This program is the test cycle. The information for comparability test in accordance with EN 50242, are as follows: The power consumption of off-mode is 0.49W, left-on mode is 0.49W Turning on the appliance Starting a wash cycle... Draw out the basket (see the section entitled "Loading the Dishwasher"). -
Page 23: Forget To Add A Dish
Press Start/Pause Button to pause the machine when the door is closed, Press Program Button more than three seconds the machine will be in stand by state, then you can change the program to the desired cycle setting (see the section entitled " Starting a wash program”). The Display window shows the state of the dishwasher: a) Display window shows "-:--"... -
Page 24: At The End Of The Wash Cycle
At the end of the Wash Cycle When the working cycle has finished, the buzzer of dishwasher will sound 8 seconds, then stop. Turn off the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher. Wait a few minutes before unloading the dishwasher to avoid scald, the dishes and utensils are still hot and more susceptible to breakage. -
Page 25: Maintenance And Cleaning
MAINTENANCE AND CLEANING Filter system WANING Never use the dishwasher without filters! Make sure the filter is properly assembled. The performance may be affected and dishes and utensils could become damaged. The filter efficiently removes food particles from the wash water, allowing it to be recycled during the cycle. -
Page 26: Caring For The Dishwasher
NOTE To replace the cleaned filters, do steps 2 and 1 in reverse. The entire filter assembly should be cleaned once a week. Inspect the filters for blockages every time the dishwasher has been used. By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water. - Page 27 Protect against freezing please take frost protection measures on the dishwasher in winter. Each time after washing cycles, please operate as follows. 1. Cut off electrical power to the dishwasher. 2. Turn off the water supply and disconnect the water inlet pipe from the water valve.
- Page 28 How to keep your dishwasher in shape After every wash After every wash, turn off the water supply to the appliance and leave the door slightly open so that moisture and odors are not trapped inside. Remove the plug Before cleaning or performing maintenance, always remove the plug from the socket. No solvents or abrasive cleaning To clean the exterior and rubber parts of the dishwasher, do not use solvents or abrasive cleaning products.
-
Page 29: Installation Preparation
INSTALLATION WANING Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. Attention The installation of the pipes and electrical equipment’s should be done by professionals. Installation preparation The installation position of dishwasher should be near the existing water inlet tap and drain outlet and power socket. -
Page 30: About Power Connection
About Power Connection WANING For personal safety: Do not use an extension cord or an adapter plug with this appliance. Do not, under any circumstances, cut or remove the earthing connection from the power cord. Electrical Requirements Please look at the rating label to know the rating voltage and connect the dishwasher to the appropriate power supply. - Page 31 Connection of drain hoses Fix the drainpipe with the back pipe of the machine. The interface is fitted with clamps and tightened with a screwdriver. Fix the drainpipe with suction cups The connection of the drainpipe: Put end of the drain into a sink or bucket. How to Drain Excess Water From Hoses If the sink is more than1000 mm higher than the floor, the excess water in hoses cannot be drained directly into the sink.
-
Page 32: Troubleshooting Tips
TROUBLESHOOTING TIPS Before calling for service Reviewing the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Fuse blown, or the Replace fuse or reset circuit breaker. start circuit break tripped. Remove any other appliances sharing the same circuit with the dishwasher. - Page 33 Problem Possible Causes What To Do Stained tub interior Detergent with Make sure that the detergent has no colorant may colorant. have been used. White film on Hard water minerals. To clean the interior, use a damp inside surface sponge with dishwasher detergent and wear rubber gloves.
- Page 34 Problem Possible Causes What To Do The dishes Not enough detergent Use more detergent or change are not clean. was dispensed. your detergent. Items are blocking Rearrange the items so that the spray the movement of can rotate freely. the spray arms. The filter combination Clean and/or fit the filter correctly.
-
Page 35: Error Codes
Problem Possible Causes What To Do The dishes are Wrong program has With a short program, the washing not drying been selected. temperature is lower, decreasing cleaning performance. Choose a program with a long washing time. Use of cutlery with a Water drainage is more difficult with low-quality coating. -
Page 36: Technical Information
Technical information 4 2 0 4 2 0 Height 435mm Width 420mm Depth 435mm see rating label Voltage connected Load 0.04 - 1.0MPa Water pressure see rating label Power supply 2 place settings Capacity...
