M60 - URU Beam Clamp
Patent Pending
Made in Canada from a solid block of Aluminium
Markings and/or symbols
URU
EYOLF: name of the manufacturer
M60 - Beam Clamp
M60 URU Beam Clamp: name of device
Patent Pending
MBS: Minimum Breaking Strength declared
MBS: 1) 15kN - 3600lbf
11-2020: month and year of manufacturing
2) 22kN - 5000lbf
Batch 10174 (example): serial number
Batch: 10174
11-2020
: Pictogram that advices to read instructions
Read the manual
EYOLF Inc.
PO Box 418
Fergus ON
N1M3E2 Canada
Tel: +1 519 787 1581
Email: info@eyolf.ca
www.eyolf.ca
50 - 0%
o
90 - 71%
o
120 - 100%
o
150 - 193%
o
o
160 - 288%
170 - 574%
o
270 degrees
2
1
4
3
5
6
Advertisement
Related Manuals for Eyolf M60
Summary of Contents for Eyolf M60
- Page 1 Made in Canada from a solid block of Aluminium Markings and/or symbols EYOLF: name of the manufacturer M60 - Beam Clamp M60 URU Beam Clamp: name of device Patent Pending MBS: Minimum Breaking Strength declared MBS: 1) 15kN - 3600lbf...
- Page 2 Product specific information The URU Beam Clamp has been designed to create anchor points on steel I-beams. They are designed and tested to work with fall protection systems and specifically developed for rope access. Diagram 1: Rigging angles, sharing the two anchor eyes can help with increasing security and strength.
- Page 3 EN 365:2004 Thank you for using an Eyolf product. We have done everything possible to ensure that the information provided in this manual is accurate at the time of publication. However, we do not guarantee that this information will remain up to date, as many products and techniques change over time.
-
Page 4: Maintenance
Compatibility Make sure that each item in an assembly can be used together and work as a system. Compatibility needs to be checked prior to use. Check individual manuals for each item and see if they can be used together. Safe use When working at height or other related activities such as rope access: never rely on a single piece of equipment always make sure you have an equal redundant back-up system. - Page 5 Lubrication When lubrication is needed a silicon or Teflon based spray can be used. Do not excessively spray the lubricant over the buckle or gate. Wipe off any excess and protect any webbing or rope from being sprayed. Storage - Transportation After cleaning, store unpacked in a cool, dry, and dark place away from direct sunlight, as UV will cause damage to the webbing over time, excessive heat sources, sharp edges, vibration or other possible caus- es of damage.
-
Page 6: Warranty
(see label on product). Upon notice in writing, Eyolf Inc. will promptly repair or replace all defective items. Eyolf Inc. reserves the right to elect to have any defective item returned to its plant for inspection before making a repair or replacement. This warranty does not cover equipment damages resulting from abuse, damage in transit, or other damage beyond the control of Eyolf Inc.
