PC-12/47E AMM Doc No 02300, ISSUE 01 REVISION 27 MSN 545, 1001-1719, 1721-1942

SCHEDULED / UNSCHEDULED MAINTENANCE

Table of Contents

SCHEDULED / UNSCHEDULED MAINTENANCE - INTRODUCTION.....................................

1

2

2.1

2.2

3

3.1

3.2

3.3

3.4

4

4.1

4.2

4.3

5

5.1

5.2

5.3

5.4

Index of Tables

1

Data module/Technical publication

12-B-05-10-00-00A-018A-A

12-B-05-10-10-00A-281A-A

12-B-05-10-20-00A-281A-A

12-B-05-20-00-00A-018A-A

12-B-05-40-00-00A-000B-A

12-B-05-50-00-00A-018A-A

Effectivity: All

UNCLASSIFIED

INTRODUCTION

General...................................................................................................................

How to Transition to the New Maintenance Program.............................................

100 Hour and Annual Inspection Program.............................................................

Progressive Inspection Program............................................................................

New Maintenance Program With Increased Interval Extension.............................

Time Limits.............................................................................................................

Scheduled Maintenance Check Lists.....................................................................

Scheduled Maintenance Checks............................................................................

Unscheduled Maintenance Checks........................................................................

Definition of Terminology........................................................................................

Flying Hours (FH)...................................................................................................

Months....................................................................................................................

Landings.................................................................................................................

Permissible Tolerances...........................................................................................

Flying Hour Based Intervals...................................................................................

Calendar Time Based Intervals..............................................................................

Landing Based Intervals.........................................................................................

Examples................................................................................................................

References.............................................................................................................

References

Table 1 References

UNCLASSIFIED

Title

TIME LIMITS - INTRODUCTION

OVERHAUL AND REPLACEMENT SCHEDULE - SCHED-

ULED INSPECTIONS

TIME LIMITED INSPECTION REQUIREMENTS

SCHEDULED MAINTENANCE CHECKS - INTRODUCTION

MASTER MAINTENANCE PLAN

UNSCHEDULED MAINTENANCE CHECKS - INTRODUC-

TION

12-B-AM-00-00-00-I

Page

Page

12-B-05-00-00-00A-018A-A

19.11.2019 Page 1

1

2

2

2

2

2

2

3

3

3

3

3

3

3

4

4

4

4

4
