Page 6: Chapter 1 - Introduction
All manuals and user guides at all-guides.com Chapter 1 - Introduction 1.1 Features and Specifications 1.1.1 Features Chipset • VIA Apollo MVP3 AGP system chipset ® Processor The system board is equipped with a switching voltage regulator that supports 2.0V to 3.5V core voltage for various processors. •... - Page 7 All manuals and user guides at all-guides.com...
- Page 8 All manuals and user guides at all-guides.com ®...
- Page 9 All manuals and user guides at all-guides.com...
- Page 10 All manuals and user guides at all-guides.com þ þ þ þ þ...
-
Page 11: Chapter 2 - Hardware Installation
All manuals and user guides at all-guides.com Chapter 2 - Hardware Installation... - Page 12 All manuals and user guides at all-guides.com...
- Page 13 All manuals and user guides at all-guides.com Hardware Installation DIP Switch Settings for Intel Processors Intel Processors SW2: 1-6 SW2: 1-6 Intel Processors 90MHz - 166MHz - 60MHz - 1.5x 66MHz - 2.5x 200MHz - 100MHz - 66MHz - 3x 66MHz - 1.5x 120MHz - MMX166MHz* -...
- Page 14 All manuals and user guides at all-guides.com Hardware Installation DIP Switch Settings for AMD Processors AMD Processors SW2: 1-6 AMD Processors SW2: 1-6 K6-2/250 - K5 PR90 - 100MHz - 2.5x 60MHz - 1.5x K6-2/266 - K5 PR100 - 66MHz - 4x 66MHz - 1.5x K5 PR120 - K6-2/300 -...
- Page 15 All manuals and user guides at all-guides.com Hardware Installation DIP Switch Settings for IBM Processors IBM Processors SW2: 1-6 SW2: 1-6 IBM Processors 6x86MX-PR200 - 6x86MX-PR300 - 66MHz - 2.5x 66MHz - 3.5x 6x86MX-PR300 - 6x86MX-PR233 - 75MHz - 3x 75MHz - 2.5x 6x86MX-PR266 - 6x86MX-PR333 -...
- Page 16 All manuals and user guides at all-guides.com Hardware Installation External System Bus Clock SW2: 4-6 External System Bus Clock SW2: 4-6 60MHz 83MHz 66MHz 95MHz 75MHz 100MHz Warning: We do not guarantee that 75MHz, 83MHz, 95MHz and 100MHz external system bus clock processors will work with all types of add-in cards, DIMM modules or other devices.
- Page 17 All manuals and user guides at all-guides.com...
- Page 18 All manuals and user guides at all-guides.com...
- Page 19 All manuals and user guides at all-guides.com...
- Page 20 All manuals and user guides at all-guides.com...
- Page 21 All manuals and user guides at all-guides.com...
- Page 22 All manuals and user guides at all-guides.com...
- Page 23 All manuals and user guides at all-guides.com...
- Page 24 All manuals and user guides at all-guides.com...
- Page 25 All manuals and user guides at all-guides.com...
- Page 26 All manuals and user guides at all-guides.com...
- Page 27 All manuals and user guides at all-guides.com...
-
Page 28: Chapter 3 - Award Bios Setup Utility
All manuals and user guides at all-guides.com Chapter 3 - Award BIOS Setup Utility ROM PCI/ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP SUPERVISOR PASSWORD CHIPSET FEATURES SETUP USER PASSWORD POWER MANAGEMENT SETUP IDE HDD AUTO DETECTION SAVE &... -
Page 29: Hard Disks
All manuals and user guides at all-guides.com ROM PCI/ISA BIOS STANDARD CMOS SETUP AWARD SOFTWARE, INC. Date (mm:dd:yy) : Fri, Jul 17 1998 Time (hh:mm:ss) : 13: 27: 50 HARD DISKS TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Primary Master Auto Auto Primary Slave... - Page 30 All manuals and user guides at all-guides.com...
- Page 31 All manuals and user guides at all-guides.com...
- Page 32 All manuals and user guides at all-guides.com ROM PCI/ISA BIOS BIOS FEATURES SETUP AWARD SOFTWARE, INC. Virus Warning : Disabled Video BIOS Shadow : Enabled CPU Internal Cache : Enabled C8000-CBFFF Shadow : Disabled External Cache : Enabled CC000-CFFFF Shadow : Disabled Quick Power On Self Test : Enabled...
- Page 33 All manuals and user guides at all-guides.com...
- Page 34 All manuals and user guides at all-guides.com...
- Page 35 All manuals and user guides at all-guides.com...
- Page 36 All manuals and user guides at all-guides.com ROM PCI/ISA BIOS CHIPSET FEATURES SETUP AWARD SOFTWARE, INC. DIMM 1 DRAM Timing : Normal AGP Master 1 WS Read : Disabled DIMM 2 DRAM Timing : Normal **** System Health Monitor **** DIMM 3 DRAM Timing : Normal Current CPU Temperature...
- Page 37 All manuals and user guides at all-guides.com...
-
Page 38: Soft-Off By Pwrbtn
All manuals and user guides at all-guides.com ® ROM PCI/ISA BIOS POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. Power Management : User Define ** PM Events ** PM Control by APM : Yes IRQ3 (COM 2) : Primary : Primary IRQ4 (COM 1) Video Off Method : DPMS... - Page 39 All manuals and user guides at all-guides.com...
- Page 40 All manuals and user guides at all-guides.com...
- Page 41 All manuals and user guides at all-guides.com ROM PCI/ISA BIOS PNP/PCI CONFIGURATION AWARD SOFTWARE, INC. Resources Controlled By : Auto PCI IRQ Actived By : Level Reset Configuration Data : Disabled Assign IRQ for VGA : Enabled PCI Slot 1 Use IRQ : Auto PCI Slot 2 Use IRQ : Auto...
- Page 42 All manuals and user guides at all-guides.com ®...
- Page 43 All manuals and user guides at all-guides.com ROM PCI/ISA BIOS INTEGRATED PERIPHERALS AWARD SOFTWARE, INC. Onboard Primary PCI IDE : Enabled Onboard FDC Controller : Enabled Onboard Secondary PCI IDE : Enabled Onboard UART 1 : 3F8/IRQ4 IDE Prefetch Mode : Enabled Onboard UART 2 : 2F8/IRQ3...
- Page 44 All manuals and user guides at all-guides.com...
- Page 45 All manuals and user guides at all-guides.com...
- Page 46 All manuals and user guides at all-guides.com...
- Page 47 All manuals and user guides at all-guides.com...
- Page 48 All manuals and user guides at all-guides.com ROM PCI/ISA BIOS CMOS SETUP UTILITY AWARD SOFTWARE, INC. HARD DISKS TYPE SIZE CYLS HEAD RECOMP LANDZ SECTOR MODE Primary Master: Select Primary Master Option (N=Skip): N OPTIONS SIZE CYLS HEAD RECOMP LANDZ SECTOR MODE 2 (Y)
- Page 49 All manuals and user guides at all-guides.com...
-
Page 50: Chapter 4 - Supported Softwares
All manuals and user guides at all-guides.com Chapter 4 - Supported Softwares... - Page 51 All manuals and user guides at all-guides.com Award DMI Configuration Utility Copyright Award Software Inc, 1996 [Edit DMI] [Add DMI] [Load DMI File] [Save DMI File] BIOS *** BIOS Auto Detect *** System Enclosure/Chassis Type : BIOS Information Processor Handle : 0000 Memory Controller Vendor Name : Memory Module...
- Page 52 All manuals and user guides at all-guides.com ← → ↑ ↓ ← → ← →...
- Page 53 All manuals and user guides at all-guides.com Genesys Logic System Health Monitor Rev.A (for VIA) Update w/o Save The time interval for Polling Interval: 4 Seconds monitoring Update and Save the system Temperature User Setting CPU Over-Heat Temperature: Celsius temperature limit CPU Hysterisis Temperature: 75 Fahrenheit...
-
Page 54: Installing The Utility
All manuals and user guides at all-guides.com Supported Softwares Important: Once this utility is installed, the system will ignore the settings in the “System Health Monitor” field of the Chipset Features Setup. If you are using Windows 95 or Windows NT 4.0, you may ®... -
Page 55: Appendix A - Identifying Processors
All manuals and user guides at all-guides.com Appendix A - Identifying Processors... - Page 56 All manuals and user guides at all-guides.com...
-
Page 57: Appendix B - System Error Message
All manuals and user guides at all-guides.com Appendix B - System Error Message... - Page 58 All manuals and user guides at all-guides.com...
-
Page 59: Appendix C - Troubleshooting
All manuals and user guides at all-guides.com Appendix C - Troubleshooting... - Page 60 All manuals and user guides at all-guides.com...
- Page 61 All manuals and user guides at all-guides.com...
- Page 62 All manuals and user guides at all-guides.com...
