OPERATING INSTRUCTIONS
for the vinyl cutters
Secabo C60 V, C120 V
S60 II, S120 II
Congratulations on the purchase of your Secabo vinyl cutter!
Please read the operating manual carefully to easily integrate your unit into your production
environment.
Any type of reproduction of this operating manual requires the written permission of Secabo
GmbH. Changes and errors in the technical data and the product characteristics are reserved.
The Secabo GmbH is not liable for any direct or indirect damages occurring as a result of the use
of this product.
Version 2.0 (21.06.2016)
Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com
www.secabo.com
1
Advertisement
Table of Contents
Related Manuals for Secabo C60 V
Summary of Contents for Secabo C60 V
- Page 1 Any type of reproduction of this operating manual requires the written permission of Secabo GmbH. Changes and errors in the technical data and the product characteristics are reserved. The Secabo GmbH is not liable for any direct or indirect damages occurring as a result of the use of this product.
-
Page 2: Safety Measures
● Always place the unit on a stable base to prevent it from falling down. ● Do not operate the unit during thunderstorms; it can be damaged or destroyed by lightning. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 3: Items Included
Before starting work, please check whether the following items are all present: Article Quantity Vinyl cutter Power cable USB connection cable Blade holder Pen holder 30° Drag knife Pen head DrawCut LITE license certificate Floor stand with roll holder Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... - Page 4 The catch basket is not part of the scope of delivery of the S II series cutters, but can be ordered as an accessory. Assembly of the floor stand Your Secabo vinyl cutter's floor stand (60 and 120 models) is easy to assemble using the supplied parts. Simply follow these steps: Step 1 and 2:...
- Page 5 Blade holder d) Pressure lever for all pinch rollers (w/out fig.) e) USB interface f) Roll mount g) Pinch rollers h) Floor stand Power supply and power switch (w/out fig.) Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 6 Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
-
Page 7: Control Panel
● Now you can use DrawCut LITE. Installation of your Secabo vinyl cutter in DrawCut Please keep in mind that your Secabo vinyl cutter can only be operated under Windows XP, Windows Vista, Windows 7, Windows 8, Windows 8.1 and Windows 10. Operation with an older version of Windows is not possible. - Page 8 ● Next, open the "Vinyl Spooler" in Drawcut. ● Now click on the "Connections" tab. ● Next, add your vinyl cutter by pressing the "Add" button (a Secabo S60 is used in the example), select your model and click "Install".
-
Page 9: Initial Operation Of The Device
● Click on the button labeled "Search device" and follow the instructions in the installation wizard. Confirm the message regarding successful installation by simply clicking on the button labeled "Done". Now you can control your Secabo vinyl cutter using DrawCut. Initial operation of the device Make sure that there is sufficient space for the film transport in front of and behind the device. -
Page 10: Installing And Adjusting The Blade
● Pull the film up to the cutting bar to correctly set the zero point. ● If inserting a roll instead of a film sheet, you can use the supplied holder integrated into the base to ensure the film is rolled off cleanly. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 11: Cutting Test
● Now, the "Vinyl Spooler" opens and displays a preview of the cut job on the right side. Now click on "Cut" and confirm the question with "Yes". ● Start the cutting process! Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 12: Settings And Operation
To set the correct starting point for cutting, move the cutting head and film using the arrow keys, so that the knife is located in the front right corner of the film. Now confirm this zero point by pressing "OK". Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 13: Other Settings
Use the up and down arrow keys to cycle through the menu options. Left and right arrow keys allow you to adjust the relevant values. Press the "OK" button to leave the configuration menu at any time. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... - Page 14 Before the first use of LAPOS, the cutter requires an initial calibration to determine the correct laser offset. DrawCut provides two procedures to achieve this, one fast and one detailed option. ● The first step is to open the "Vinyl Spooler". Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 15 ● First, create a logo with the text tool or import any vector graphics. ● Open the Contour Cut Wizard from the DrawCut header. ● Create an outline using the desired parameters under "Create a cutting contour". Confirm it by clicking "OK". Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 16 ● First, print out the created graphics including crop marks. Ensure that the printer is configured to print using the actual size. ● Once the print job has completed, press the "Cut" button. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 17 Method" to achieve the maximum possible accuracy. Place the prinout inside the vinyl cutter exactly as seen in the depiction in the DrawCut application. Now click on the "Next" button and follow the instructions in the alignment wizard to start the contour cutting. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
-
Page 18: Drag Knifes
● For thicker materials, use knives specially suited for it (e.g. flock knife for flock). ● Frayed edges after cutting the foil indicate a blunt drag knife. Replace worn blades immediately! Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 19: Technical Data
AC 90V - 240V / 50Hz - 60Hz Environment +5°C - +35°C / 30% - 70% relative humidity Weight without packaging 15kg Weight with packaging 25kg Dimensions (W x H x D) 920 x 260 x 260mm Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... - Page 20 AC 90V - 240V / 50Hz - 60Hz Environment +5°C - +35°C / 30% - 70% relative humidity Weight without packaging 30kg Weight with packaging 41kg Dimensions (W x H x D) 1600 x 260 x 260mm Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
