First Steps with your Secabo CIII vinyl cutter
Installation Secabo FlexiStarter
Version 8.5 of the FlexiStarter cutting software is supplied with your Secabo vinyl cutter. To con-
trol the vinyl cutter with your PC, install the software as described below.
• Insert the FlexiStarter CD supplied.
• Select the desired language in setup and click continue .
• Read the software license agreement and accept.
• Follow the instructions of the installation assistant.
• Make sure that the sentinel system driver is also
• Enter your 32-digit password, you can find it on the back of the software cover.
• Select the desired language again.
• Wait until the installation process is finished and click finish.
• Plug the USB dongle (copy protection plug) supplied into the USB port
(installation is accomplished automatically).
If you have a Flexi Starter Version with online activation, please refer to the manual supplied on the
Secabo CIII CD.
Installation of the Secabo CIII with the installation assistent
• For the complete installation of your Secabo CIII vinyl cutter, you have to install FlexiSTARTER
prior to this installation assistant.
• Turn off the cutter and unplug the USB cable.
• Insert the Secabo CIII-CD in your CD drive.
• The setup program will start automatically.
> if the setup refuses to start, run the setup.exe provided on the CD.
• The Secabo CIII installation assistent will be set up. Microsoft .NET 2.0 is needed on your
system. If .NET 2.0 is not yet in included in your Windows operating system, it will be in
stalled automatically. You only need to accept the Microsoft license agreement.
• The Secabo CIII installation assistent starts automatically. Follow accurately the instuctions
of the assistent and in 5 easy to do steps, your Secabo CIII vinyl cutter will be installed and
ready to use.
Manual installation of the USB driver
If it is not possible to execute the installation assistent on your PC, you can
install the USB driver manual. Follow the instuctions below.
• Please install the USB drivers before connecting the plotter with the PC.
• Insert the Secabo CIII-CD in your CD drive.
• Run the CIII-USB-driver.exe provided on the CD.
• Click install
Click install
Click
.
r
r is also
selected in the choosing features window.
www.secabo.com
Advertisement
Table of Contents
Related Manuals for Secabo CIII
Summary of Contents for Secabo CIII
- Page 1 You only need to accept the Microsoft license agreement. • The Secabo CIII installation assistent starts automatically. Follow accurately the instuctions of the assistent and in 5 easy to do steps, your Secabo CIII vinyl cutter will be installed and ready to use.
- Page 2 • The Choose Production Manager Window appears. Select On this PC (local) Press OK . • Wait until the Production Manager has started. • Select your Secabo vinyl cutter model C30III, C60III or C30III, C60III or C30III, C60III C120III .
-
Page 3: Troubleshooting
An imported job (EPS) is plotted a number of times at the same position. Possible causes: > File may be corrupted and should be checked. Straight lines are cut zigzag Possible causes: > Blade adjustment and/or contact pressure incorrect and should be checked. www.secabo.com... - Page 4 Machine Operation The following figure shows the menu of the Secabo CIII vinyl cutter. A detailed description of every point can be found on the following page. Idle State turn on machine change x: chance s: press change y: change f...
- Page 5 Then press the button to confirm the origin. Pause To pause a cutting job just press the button. The cutting job will conti- nue when pressing the button again. www.secabo.com www.secabo.com...
- Page 6 This mode enables you to calibrate the X and Y axis oft he machine. This is only required, if the output is not correctly sized. Reset By pressing the button the vinyl cutter will be reset to factory defaults. www.secabo.com www.secabo.com...
