Summary of Contents for spok GenA Pager
- Page 1 Version 01/22...
-
Page 2: Table Of Contents
Set Message Zoom ..........................23 Set Reminder ............................23 Set Lock Code ............................24 Set Do Not Disturb ..........................27 Key Vibe..............................28 Inbox Size ..............................28 About ............................... 29 Spok, Inc. – Copyright 2022 P a g e | 2 v01/22... -
Page 3: Purpose
GenA User Guide PURPOSE This user manual is intended to provide detailed user interface and operating instructions for the Spok GenA™ pager. The GenA™ pager is offered exclusively by Spok. FEATURES • Device • High resolution E-Paper display with auto-on front-light •... -
Page 4: Device Design
• Replace the battery cover by inserting and aligning the dots. Then slide the cover closed and slide the battery cover lock into place Alignment dots Battery Placement Spok, Inc. – Copyright 2022 P a g e | 4 v01/22... -
Page 5: Description Of Screen Indicators & Icons
General Navigation Indicators Current Setting Indicator Before page indicator Next page indicator Message Status Icons Unread Message Indicator Duplicate Message Indicator Locked Message Indicator Unread & Duplicate Message Indicator Spok, Inc. – Copyright 2022 P a g e | 5 v01/22... -
Page 6: Control Buttons
Used to move Up or Down a message line by line in a message view screen. • Used to change values in the Date & time, Alarm and Do not disturb time setting functions. Spok, Inc. – Copyright 2022 P a g e | 6 v01/22... -
Page 7: Main Device Screens
30 seconds. • It shows the date and time, the device screen name, and the device status icons in the bottom row Spok, Inc. – Copyright 2022 P a g e | 7 v01/22... -
Page 8: Turning The Pager On And Off
Turn Off Popup • Press the Up button to select Turn Off and press the Enter button to turn off the pager. • The Pager Off screen will appear Spok, Inc. – Copyright 2022 P a g e | 8 v01/22... -
Page 9: Special Pager Power Off Screens
New Message Do Not Disturb Active Battery Status Press the buttons to move the highlight between the Inbox/Group/Saved and Settings folders. Press the button to select the highlighted folder. Spok, Inc. – Copyright 2022 P a g e | 9 v01/22... -
Page 10: Main Screen Folders
Settings folder • Shows the current alert setting. Audible, vibrate or off Alert Setting • The alert settings are set up from the Settings folder Spok, Inc. – Copyright 2022 P a g e | 10 v01/22... -
Page 11: Message Operations
(wrap-around). • Press the button to view the message in the message read screen. • Press the button for 2 sec, to bring up the message list popup. Spok, Inc. – Copyright 2022 P a g e | 11 v01/22... -
Page 12: Messages List Popup
Locked messages will not be automatically deleted unless first unlocked. Messages List Screen (Saved Folder) Received time & date of Messages List Screen highlighted message Page continuation icon Message number Message text preview Spok, Inc. – Copyright 2022 P a g e | 12 v01/22... -
Page 13: Messages List Action Popup (Saved Folder)
Action Popup ACTION DESCRIPTION Delete The highlighted message is deleted. Cancel The action popup is cleared. This item is highlighted by default Spok, Inc. – Copyright 2022 P a g e | 13 v01/22... -
Page 14: Message Read Screen (Inbox, Groups And Saved)
Pressing Enter again will bring up the message action popup. NOTES: The Message Source text that appears below the message content is programmed within the pager. It indicates which pager address the message was received on. Spok, Inc. – Copyright 2022 P a g e | 14 v01/22... -
Page 15: Read Messages Action Popup
Up to half of max message number can be locked. The saved folder does not have a lock function. • Press the button to navigate through the popup menu. • Press the button to execute the action. Spok, Inc. – Copyright 2022 P a g e | 15 v01/22... -
Page 16: Group Folder Sub-Folder Screen (Groups)
3. Different alerts can be set for each sub-folder. 4. The sub-folder alert status is displayed on the right side of the folder according to the set alert. Spok, Inc. – Copyright 2022 P a g e | 16 v01/22... -
Page 17: Messages List Popup
• The standard alert and Alerts 1-6 will alert for 15 seconds • Alert 7 will alert continuously until a button is pressed Spok, Inc. – Copyright 2022 P a g e | 17 v01/22... -
Page 18: Settings
The Lock Now, Change Lock Code and Disable Lock Code items only appear if the Lock feature is enabled on the pager. Spok, Inc. – Copyright 2022 P a g e | 18 v01/22... -
Page 19: Quiet Mode
When setting the Quiet mode to on, all alerts are set to vibrate (silent). The alert status on the Main screen will show as • The current setting is indicated by the icon. Spok, Inc. – Copyright 2022 P a g e | 19 v01/22... -
Page 20: Set Date & Time
The date, hours or AM/PM values of the pager clock must be set by the user. Set Date Format Screen • The format of the date value used throughout the pager can be selected. Spok, Inc. – Copyright 2022 P a g e | 20 v01/22... -
Page 21: Set Alarm
• The alarm will automatically end after 5 minutes. • You can cancel the alarm by pressing the button. Spok, Inc. – Copyright 2022 P a g e | 21 v01/22... -
Page 22: Set Inbox Alert
Front Light will flash along with the alert when a message is received. • The Flash alert is universal for all messages received in both the Inbox and any Groups sub-folder. Spok, Inc. – Copyright 2022 P a g e | 22 v01/22... -
Page 23: Set Message Zoom
Set Reminder Alert Popup • If there is one or more unread messages, a double chirp will alert every two minutes. • The current setting is indicated by the icon. Spok, Inc. – Copyright 2022 P a g e | 23 v01/22... -
Page 24: Set Lock Code
Lock Now Option • Normally, when the Lock function is enabled, the Lock function operates after 5 minutes of inactivity. The Lock Now function allows it to be set immediately. Spok, Inc. – Copyright 2022 P a g e | 24 v01/22... - Page 25 When the Lock Code is enabled, the ‘Disable Lock Code’ function is available. • When the Lock Code is correct, press button to disable the Lock feature. Pressing button cancels the action. Spok, Inc. – Copyright 2022 P a g e | 25 v01/22...
- Page 26 If Lock Code is correct Screen If Lock Code is incorrect Screen If you forget your lock code and can’t access your pager, contact your company’s pager administrator to get it remotely reset. Spok, Inc. – Copyright 2022 P a g e | 26 v01/22...
-
Page 27: Set Do Not Disturb
• Select No if the pager should not alert at the end of the do not disturb period if a message was received Spok, Inc. – Copyright 2022 P a g e | 27 v01/22... -
Page 28: Key Vibe
The Inbox Size value also controls how many messages can be stored in a Groups sub-folder. The Groups folder has a capacity of 99 messages across all the subfolders that may be programmed into the pager. Spok, Inc. – Copyright 2022 P a g e | 28... -
Page 29: About
About Screen The About screen lists the following information: • Date of firmware release • Firmware version • Device serial number • Programmed device addresses with source text Spok, Inc. – Copyright 2022 P a g e | 29 v01/22...
