- Page 1 Usage instructions for SPIKE adaptive bike Usage instructions Service booklet SPIKE adaptive bike...
-
Page 2: Table Of Contents
Usage instructions for SPIKE adaptive bike Contents 1 Preface ............................... 3 2 Legend ..............................3 3 Conformity/other information ......................3 3.1 Classification ..........................3 3.2 Conformity........................... 3 3.3 Manufacturer ..........................3 4 Scope of delivery and testing the product on receipt ................. 3 5 Introduction ............................ - Page 3 The following instructions are intended for and may only be carried out by the rehabilita- tion specialist dealer or PRO ACTIV. This document is available in PDF format at www.proactiv-gmbh.com for visually impaired people. Using the zoom function, the font can be increased as desired.
-
Page 4: Preface
Conformity/other information Classification Dear Customer, Congratulations on purchasing your new The SPIKE (referred to as a "product" below) is PRO ACTIV product. You have bought a quali- classified as a class I product. ty product that has been specially customised Conformity to meet your requirements. -
Page 5: Introduction
Usage instructions for SPIKE adaptive bike However, please check the product immediate- It is then vital that the advice from doc- ly upon receipt, preferably in the presence of tors, therapists and the rehabilitation specialist the freight company, for any damage which dealer on the necessary safety accessories may have occurred in transit. -
Page 6: Purpose And Indication
Usage instructions for SPIKE adaptive bike Purpose and indication Proper use This product is a manual adaptive bike that is This adaptive bike is designed to be used out- coupled to a human-powered wheelchair with doors on tarmac and adequately paved roads... -
Page 7: Technical Specifications
Usage instructions for SPIKE adaptive bike Obstacle height and turning circle Maximum drive-over/negotiable obstacle height: 10 cm (must be ensured through an appropriate adapter assembly/setting, caster wheels must be removed ( recommended equipment of the wheelchair: caster forks with quick-release axle)) -
Page 8: Rating Plate & Markings On The Product
Usage instructions for SPIKE adaptive bike Rating plate & markings on the the usage instructions and, if necessary, fur- ther accessories for your own use. It is rec- product ommended that you take along an assistant to The rating plate is located on the bottom the training so that, if required, they can assist you later when handling the product. -
Page 9: Safety Instructions - While Driving/Using
Usage instructions for SPIKE adaptive bike Before every trip, check the condition of To minimise the risk of suffering serious the wheels of the wheelchair-product combina- head injuries in the event of a fall, a helmet tion (e.g. visual inspection of the spokes and... - Page 10 Usage instructions for SPIKE adaptive bike You may only drive on slopes where the By performing regular checks, ensure that wheelchair-product combination can be safely the safety bolts of the adapter are always in controlled by steering and braking of the prod- the correct position while driving (see usage uct.
-
Page 11: Safety Instructions Regarding Obstacles
Usage instructions for SPIKE adaptive bike 14 Safety instructions regarding narrow and/or steeply sloping paths along main roads or near cliffs. obstacles routes that are covered in leaves, snow or Driving on steps and escalators with the ice. -
Page 12: Ending The Driving Operation
Usage instructions for SPIKE adaptive bike To check or correct the tyre pressure, pro- 16 Ending the driving operation ceed as follows: To make getting out of the wheelchair more 1. Secure the product to prevent it rolling simple, the product can be disconnected from away. -
Page 13: Functional Elements
Usage instructions for SPIKE adaptive bike Clamp lever Valve adapter Figure 5: Valve adapter and clamp lever of the compressor 19 Functional elements Figure 7: Parking stand in the active position 19.1 Parking stand 19.1.1 Active and passive positions By pressing down and turning the operating... -
Page 14: Bottom Bracket Support And Crank
Usage instructions for SPIKE adaptive bike ground to the upper edge of the insertion bolt The height of the parking stand is adjusted (on the product side). As soon as there is a by unscrewing the M6 oval head screw (AF... -
Page 15: Bottom Bracket Position
Usage instructions for SPIKE adaptive bike bottom bracket in this case is selected to be gle, tighten up the four M6 clamp screws slightly higher (chest height or higher). (AF 5 mm) to 7 Nm torque and secure them with thread lock fluid. -
Page 16: Crank Length And Grip Width
Usage instructions for SPIKE adaptive bike in its mount to the desired position. Then Bottom tighten the four M6 clamp screws (AF bracket shaft 5 mm) to 7 Nm torque and secure them Handle rotary with thread lock fluid. axle... -
Page 17: Gear Shift
Usage instructions for SPIKE adaptive bike 19.4 Gear shift Left control button 19.4.1 Hub gear The hub drive can be changed while driving and also when stationary. No crank movement is needed to change or only a small reduction in torque is needed while driving. -
Page 18: Rim Brake
Usage instructions for SPIKE adaptive bike Please note that the braking effect can be strongly reduced by one or all of the following Setting screw conditions: on the brake lever Worn tyre profile Soiled and wet tyres ... -
Page 19: Bell
Usage instructions for SPIKE adaptive bike Mountain Drive bottom bracket gearshift: www.haberstock-mobility.com Sigma: www.sigmasport.com/en/ Subject to changes to the links provided by the component manufacturers. 20 Storage Actuation button for the rear lights Store the product on an easy-to-clean surface... -
Page 20: Passenger Transport In Vehicles
Usage instructions for SPIKE adaptive bike 21.2 Passenger transport in vehicles The lashing straps used to secure the product in the transport vehicle may only be When transporting in vehicles, it fitted to the components of the vehicle provid- must be noted that the product is... -
Page 21: Maintenance
Usage instructions for SPIKE adaptive bike In case the product becomes wet when using, When maintaining the brakes and the please dry it after use. gear components, it is imperative that the us- age instructions from the manufacturer which Clean your product with water, solvent or were included in delivery are followed. -
Page 22: Proof Of Maintenance
Usage instructions for SPIKE adaptive bike In addition to these maintenance tasks/checks 25 Disposal and recycling by the user, PRO ACTIV has prescribed At the end of the service life, the product can maintenance tasks to be carried out by the... -
Page 23: Warranty
Usage instructions for SPIKE adaptive bike These preparations will be performed by 28 Liability PRO ACTIV or the rehabilitation specialist As the manufacturer of the product, dealer as part of the technical safety check. PRO ACTIV is not responsible for its safety if: This safety-related check must be initiated by the funding provider. -
Page 24: Appendix: Tightening Torques And Securing Details
Usage instructions for SPIKE adaptive bike 29 Appendix: Tightening torques and securing details The following table shows the torques for shaft screws with a metric control thread (valid providing the drawing, assembly, or usage instructions do not state different values!):... -
Page 25: Appendix: Medical Product Passport/Record Of Training
Usage instructions for SPIKE adaptive bike 30 Appendix: Medical product passport/record of training Product specifications: Serial number: Customer data: Surname, forename: Street: Postcode, city: Phone: Paying organisation: Training carried out by: Rehabilitation specialist dealer PRO ACTIV Field Representative/ Product adviser... -
Page 26: Appendix: Hand-Over Certificate
Usage instructions for SPIKE adaptive bike 31 Appendix: Hand-over certificate 31.1 Required compliance criteria to authorise use Completed/ Topics Remarks fulfilled The product is suitable for the customer based on their own judgement and the customer information received regarding the disability-related restrictions. -
Page 27: Check List For Training The User
Usage instructions for SPIKE adaptive bike 31.2 Check list for training the user Completed/ Topics fulfilled Advised of the applicable legal regulations when driving on public roads. All mechanical function control elements were explained and their function demonstrated. Adaptation of the adapter to the wheelchair and removing the adapter from the wheelchair have been demonstrated and then performed by the user themselves and/or an assistant. -
Page 28: Appendix: Inspection Lists
Usage instructions for SPIKE adaptive bike 32 Appendix: Inspection lists Initial inspection: After 200 km or 5 months Serial number: ______________________ carried not OK resolved Kilometre reading: ________________________ Check that all screws/fastening elements are firmly seated Functional and safety check of all lights (if fitted), steering and adapta-... - Page 29 Usage instructions for SPIKE adaptive bike Subsequent inspection: After another 1000 km or 1 year after the last inspection or after heavy use OK / Serial number: ______________________ carried not OK resolved Kilometre reading: ________________________ Check that all screws/fastening elements are firmly seated and replace, if...
- Page 30 Usage instructions for SPIKE adaptive bike Subsequent inspection: After another 1000 km or 1 year after the last inspection or after heavy use OK / Serial number: ______________________ carried not OK resolved Kilometre reading: ________________________ Check that all screws/fastening elements are firmly seated and replace, if...
- Page 31 Usage instructions for SPIKE adaptive bike Subsequent inspection: After another 1000 km or 1 year after the last inspection or after heavy use OK / Serial number: ______________________ carried not OK resolved Kilometre reading: ________________________ Check that all screws/fastening elements are firmly seated and replace, if...
- Page 32 Usage instructions for SPIKE adaptive bike Subsequent inspection: After another 1000 km or 1 year after the last inspection or after heavy use OK / Serial number: ______________________ carried not OK resolved Kilometre reading: ________________________ Check that all screws/fastening elements are firmly seated and replace, if...
- Page 33 Usage instructions for SPIKE adaptive bike Subsequent inspection: After another 1000 km or 1 year after the last inspection or after heavy use OK / Serial number: ______________________ carried not OK resolved Kilometre reading: ________________________ Check that all screws/fastening elements are firmly seated and replace, if...
- Page 34 Usage instructions for SPIKE adaptive bike Subsequent inspection: After another 1000 km or 1 year after the last inspection or after heavy use OK / Serial number: ______________________ carried not OK resolved Kilometre reading: ________________________ Check that all screws/fastening elements are firmly seated and replace, if...
- Page 35 Usage instructions for SPIKE adaptive bike Subsequent inspection: After another 1000 km or 1 year after the last inspection or after heavy use OK / Serial number: ______________________ carried not OK resolved Kilometre reading: ________________________ Check that all screws/fastening elements are firmly seated and replace, if...
- Page 36 Usage instructions for SPIKE adaptive bike Your rehabilitation specialist dealer: PRO ACTIV Reha-Technik GmbH Im Hofstätt 11 D-72359 Dotternhausen – Germany Phone +49 7427 9480-0 Fax +49 7427 9480-7025 Email: info@proactiv-gmbh.de www.proactiv-gmbh.com...
