AVR-S700W (1 of 3)

MODEL INFO. INDEX

Protection History Mode records and displays an event in which the THERMAL, CURRENT, ASO or DC protection was activated.

TUNER PRESET CH-

TUNER PRESET CH+

POWER

TUNE-

Procedure to enter the "Protection History Display Mode".

1. Hold down buttons "TUNER PRESET CH-", "TUNE-" and "TUNER PRESET CH+" at the same time and press the power button to turn on the power.

2. Select "PROTECTION" using the "TUNER PRESET CH+/-" button, and press the "STATUS" button.

3. Press the "STATUS" button again and the unit will display the Protection History condition.

MODEL INFO. INDEX

PROTECTION HISTORY DISPLAY MODE

CLEARING THE PROTECTION HISTORY

Page 1 AVR-S700W (1 of 3) MODEL INFO. INDEX Protection History Mode records and displays an event in which the THERMAL, CURRENT, ASO or DC protection was activated. TUNER PRESET CH- TUNER PRESET CH+ POWER TUNE- Procedure to enter the “Protection History Display Mode”.
Page 2 AVR-S700W (2 of 3) MODEL INFO. INDEX 1. If no protections have occurred, “No Protect” is displayed 2. if last protection was ASO/DC, “ASO/DC” is displayed. Cause: A short circuit occurred between the speaker terminals, or speakers with an impedance outside the rating were connected.
Page 3 AVR-S700W (3 of 3) MODEL INFO. INDEX Clearing the Protection History If the unit is in “Protection History Display Mode”, just press and hold the “ENTER” button for 3 seconds. Note: If you do not mind erasing your settings from this unit, you can also “Initialized/Micro Reset the unit to clear the Protection History from the unit’s memory.
